Wasp WPL305 Thermal Label Printer

by
WASP
PCN#
8474BC
MFG#
633808402006
main product photo
fotorama-image
WASP Authorized Dealer
$514.91
cps

Extended & Accidental Damage Protection Plans Available Details

  Free Shipping
Estimated Shipment:

Calculating Shipping

Product Highlights:
  • Monochrome
  • 5 in/s Mono
  • 203 dpi

Show more

Product Condition: New and Factory Fresh
Limited Warranty1 Year
Shipping Weight: 11 lbs.
Wasp WPL305 Thermal Label Printer
Overview
Tech Specs
Specifications

Manufacturer

Wasp Barcode Technologies

Manufacturer Part Number

633808402006

Manufacturer Website Address

http://www.waspbarcode.com

Brand Name

Wasp

Product Model

WPL305

Product Name

WPL305 Thermal Label Printer

Marketing Information

WPL305 is user-friendly, and reliable desktop barcode printer in its class. Its desktop design great for limited office and warehouse space. Easy installation & media loading will have you printing in minutes.

Product Type

Direct Thermal/Thermal Transfer Printer
Technical Information

Recommended Use

Label Print

Print Color Capability

Monochrome

Maximum Mono Print Speed

5 in/s

Maximum Print Resolution (dpi)

203

Maximum Print Width

4.25"

Barcode Symbology Supported

  • Code 39
  • Code 39C
  • Code 93
  • Code 128 UCC
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • Code 11
  • Codabar
  • Interleaved 2 of 5
  • EAN-8
  • EAN-13
  • UPC-A
  • UPC-E
  • MSI
  • Plessey
  • POSTNET
  • PDF-417
  • Maxi Code
  • Data Matrix
  • Micro PDF-417

Application/Usage

Desktop

Print Technology

Direct Thermal /Thermal Transfer
Memory

Standard Memory

8 MB

Memory Technology

SDRAM

Flash Memory

4 MB
Interfaces/Ports

Parallel Port

Yes

Serial Port

Yes

USB

Yes
Media Types & Handling

Media Type

Label

Media Size

Custom Size - 4.40"

Media Sensor

Reflective Media Sensor

Maximum Roll Diameter

5"

Maximum Label Width

4.40"

Maximum Label Length

39"

Label Core Size

3"

Ribbon Core Size

1"
Fonts & Emulation

Language Emulation

  • WPL
  • EPL
  • ZPL
Software

Operating System Supported

  • Windows 8
  • Windows 7
  • Windows Vista
  • Windows XP (SP3)
  • Windows 2000
  • Windows Server 2012
  • Windows Server 2008
  • Windows Server 2003
Power Description

Power Source

AC Supply

Input Voltage

  • 110 V AC
  • 220 V AC
Physical Characteristics

Height

7.4"

Width

8.4"

Depth

12.4"

Weight (Approximate)

6.61 lb
Miscellaneous

Additional Information

  • Compact Design
  • Easy Media Supplies loading
  • One Indicator LED (Two Color)
  • WPL, ZPL emulation & EPL emulation
  • Font Rotations: 0, 90, 180, 270 degrees

Sensors:

  • Label Gap
  • Black Line
  • Head Open
  • Reflective (position adjustable)

Platform Supported

PC

Certifications & Standards

  • CE
  • FCC
  • TUV
  • UL

Country of Origin

Taiwan
Warranty

Limited Warranty

1 Year
