Wasp WPL305 Thermal Label Printer

Name: Wasp WPL305 Thermal Label Printer
Brand: WASP
SKU: 8474BC
Price: 514.91 USD
Availability: InStock

WASP

PCN#

8474BC

MFG#

633808402006

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$514.91

Extended & Accidental Damage Protection Plans Available Details

2-Year $66.99

3-Year $89.99

Free Shipping

Estimated Shipment:

Product Highlights:

Monochrome
5 in/s Mono
203 dpi
USB, Serial, Parallel

Product Condition: New and Factory Fresh

Limited Warranty1 Year

Shipping Weight: 11 lbs.

WPL305 Barcode Printer

Overview

Tech Specs

Specifications

Manufacturer	Wasp Barcode Technologies
Manufacturer Part Number	633808402006
Manufacturer Website Address	http://www.waspbarcode.com
Brand Name	Wasp
Product Model	WPL305
Product Name	WPL305 Barcode Printer
Marketing Information	WPL305 Desktop Barcode Printer The Wasp WPL305 is a compact, powerful desktop barcode printer designed to meet your light- to medium-duty barcode printing requirements. Its durable construction, speed, and dual printing technologies make the WPL305 a leader in its class and one of the most popular printers in the Wasp line. Perfect for printing 4x6 shipping labels . The WPL305 offers both direct thermal and thermal transfer printing in one printer, reducing the need for additional printers for different printing processes. With print speeds up to 5" inches per second at 203 dpi resolution, the WPL305 is a cost effective way to print barcode labels of all types, including shipping labels, stock labels, asset tags, medical labels, and location labels. Print speed is supported by 8 MB of SDRAM, 4 MB of FLASH memory and multiple connectivity options including parallel, USB, and RS232. ZPL, EPL, and WPL emulation are also included to ensure application compatibility. The WPL305 includes a 2-year manufacturer's warranty covering material defects. If you would like to upgrade this coverage, WaspProtect extended service plans cover accidental breakage and can provide coverage beyond the original warranty. Part Numbers: 633808402006, 633808402020, 633808402013
Product Type	Direct Thermal/Thermal Transfer Printer

Technical Information

Recommended Use	Label Print
Print Color Capability	Monochrome
Maximum Mono Print Speed	5 in/s
Maximum Print Resolution (dpi)	203
Maximum Print Width	4.25"
Barcode Symbology Supported	Code 39 Code 39C Code 93 Code 128 UCC Code 128-A Code 128-B Code 128-C Code 11 Codabar Interleaved 2 of 5 EAN-8 EAN-13 UPC-A UPC-E MSI Plessey POSTNET PDF-417 Maxi Code Data Matrix Micro PDF-417
Application/Usage	Desktop
Print Technology	Direct Thermal /Thermal Transfer

Memory

Standard Memory	8 MB
Memory Technology	SDRAM
Flash Memory	4 MB

Interfaces/Ports

Parallel Port	Yes
Serial Port	Yes
USB	Yes

Media Types & Handling

Media Type	Label
Media Size	Custom Size - 4.40"
Media Sensor	Reflective Media Sensor
Maximum Roll Diameter	5"
Maximum Label Width	4.40"
Maximum Label Length	39"
Label Core Size	3"
Ribbon Core Size	1"

Fonts & Emulation

Language Emulation

Software

Operating System Supported

Windows 8
Windows 7
Windows Vista
Windows XP (SP3)
Windows 2000
Windows Server 2012
Windows Server 2008
Windows Server 2003

Power Description

Power Source	AC Supply
Input Voltage	110 V AC 220 V AC

Physical Characteristics

Height	7.4"
Width	8.4"
Depth	12.4"
Weight (Approximate)	6.61 lb

Miscellaneous

Additional Information	Compact Design Easy Media Supplies loading One Indicator LED (Two Color) WPL, ZPL emulation & EPL emulation Font Rotations: 0, 90, 180, 270 degrees Sensors: Label Gap Black Line Head Open Reflective (position adjustable)
Platform Supported	PC
Certifications & Standards	CE FCC TUV UL
Country of Origin	Taiwan

Warranty

Limited Warranty

1 Year
