Ubiquiti UniFi Switch Aggregation

Name: Ubiquiti UniFi Switch Aggregation
Brand: UBIQUITI
SKU: 8LQ109
Price: 280.37 USD
Availability: InStock

UBIQUITI

PCN#

8LQ109

MFG#

USW-AGGREGATION

$280.37

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

Product Condition: New and Factory Fresh

Shipping Weight: 1 lbs.

Ubiquiti USW-AGGREGATION Ethernet Switch

Tech Specs

Specifications

Manufacturer	Ubiquiti Inc.
Manufacturer Part Number	USW-AGGREGATION
Manufacturer Website Address	http://www.ui.com
Brand Name	Ubiquiti
Product Model	USW-AGGREGATION
Product Name	USW-AGGREGATION Ethernet Switch
Product Type	Ethernet Switch

Technical Information

Features

Interfaces/Ports

Port/Expansion Slot Details

8 x 10 Gigabit Ethernet Expansion Slot

Media & Performance

I/O Expansions

Total Number of Expansion Slots	8
Expansion Slot Type	SFP+
Number of SFP+ Slots	8

Network & Communication

Layer Supported	2
Networking Standards	IEEE 802.1x

Management & Protocols

Manageable

Yes

Power Description

Physical Characteristics

Miscellaneous

Application/Usage	Network
Additional Information	Switching Capacity: 160 Gbps Total Non-Blocking Throughput: 80 Gbps Forwarding Rate: 119 Mpps Supported VLANs: 1,000 MAC Address Table Size: 16,000 Packet Buffer Size: 1.5 MB Management: Ethernet, AR Heat Dissipation: 102 BTU/hr Supported Rack Depth: 400~1200 mm (15.7-47.2") LCM Display: 1.3" touchscreen ESD Protection: Air: ± 16kV, contact: ± 12kV Ambient Operating Temperature: -5 to 40° C (23 to 104° F) Ambient Operating Humidity: 10 to 90% noncondensing NDAA Compliant: Yes LACP Port Aggregation: Yes STP & RSTP: Yes Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes MAC-Based ACLs & Device Isolation: Yes DHCP Snooping & Guarding: Yes Egress Rate Limit: Yes Storm Control: Yes Multicast & Broadcast Rate Limiting: Yes MAC Address Blocking: Yes IP-Based ACLs & Network Isolation: Yes MAC-Based Port Restriction: Yes Port Isolation: Yes Jumbo Frames: Yes LLDP-MED: Yes Voice VLAN: Yes Virtual Network Override: Yes
Certifications & Standards	CE FCC IC Anatel: 00593-21-08356
Environmental Compliance	Waste Electrical and Electronic Equipment Directive (WEEE)
