Tyan Transport HX TN83-B8251 Barebone System - 2U Rack-mountable - Socket SP3 - 2 x Processor Support

Name: Tyan Transport HX TN83-B8251 Barebone System - 2U Rack-mountable - Socket SP3 - 2 x Processor Support
Brand: TYAN COMPUTER
SKU: 7393AY
Price: 3305.82 USD
Availability: InStock

TYAN COMPUTER

PCN#

7393AY

MFG#

B8251T83E8HR-2T-N

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$3,305.82

Extended & Accidental Damage Protection Plans Available Details

3-Year $332.99

2-Year $265.99

Estimated Shipment:

Product Highlights:

4 TB DDR4 SDRAM DDR4
3200/PC4
25600 Maximum RAM Support
16.0 Total Memory Slots
Serial ATA/600, 12Gb/s SAS Controller
ASPEED AST2500 32 MB Graphic(s)
8 3.5" Bay(s)
8 SATA Interface(s)
Processor Support (EPYC)
10 Gigabit Ethernet
2 x 2200 W
3 Year

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 70 lbs.

Tyan Transport HX TN83-B8251 Barebone System - 2U Rack-mountable - Socket SP3 - 2 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Tyan Computer Corp
Manufacturer Part Number	B8251T83E8HR-2T-N
Manufacturer Website Address	http://www.tyan.com
Brand Name	Tyan
Product Line	Transport HX
Product Model	TN83-B8251
Product Name	Transport HX TN83-B8251 2U 4-GPU HPC Server
Packaged Quantity	1
Product Type	Barebone System

Processor

Number of Processors Supported	2
Processor Socket	Socket SP3
Processor Supported	EPYC
64-bit Processing	Yes

Memory

Maximum Memory Supported	4 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-3200/PC4-25600
Total Number of Memory Slots	16.0

Controllers

Controller Type

Serial ATA/600
12Gb/s SAS

Display & Graphics

Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2500
Graphics Memory Capacity	32 MB

Network & Communication

Ethernet Technology

10 Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	8
Number of 3.5" Bays	8
Total Number of Expansion Slots	6.0
Number of PCI Express x16 Slots	6

Interfaces/Ports

Total Number of USB Ports	5
Number of USB 3.1 Gen 1 Ports	5
Number of SATA Interfaces	8

Operating System

Operating System Supported

Windows Server 2016
Windows Server 2019
Red Hat Enterprise Linux 7.6 x64
Red Hat Enterprise Linux 8.0 x64
SuSE Linux Enterprise Server 12 x64
SuSE Linux Enterprise Server 15 x64
CentOS 7.7 x64
Ubuntu Desktop 19.04 x64
Red Hat Enterprise Linux 8.1 x64
Red Hat Enterprise Linux 7.7 x64

Power Description

Input Voltage	230 V AC
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	2200 W

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	2U
Height	3.4"
Width	17.3"
Depth	32.7"
Weight (Approximate)	44.80 lb

Miscellaneous

Package Contents	Transport HX TN83-B8251 2U 4-GPU HPC Server 1 x Quick Installation Guide
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

3 Year
