Tripp Lite by Eaton PDU 1.9kW Single-Phase Switched Automatic Transfer Switch PDU 2 120V L5-20P / 5-20P Inputs 16 5-15/20R Outputs 1U TAA

Name: Tripp Lite by Eaton PDU 1.9kW Single-Phase Switched Automatic Transfer Switch PDU 2 120V L5-20P / 5-20P Inputs 16 5-15/20R Outputs 1U TAA
Brand: TRIPP LITE
SKU: L50013
Price: 630.91 USD
Availability: InStock

TRIPP LITE

PCN#

L50013

MFG#

PDUMH20ATNET

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$630.91

Extended & Accidental Damage Protection Plans Available Details

2-Year $66.99

3-Year $89.99

Free Shipping

Estimated Shipment:

Product Highlights:

16 x NEMA 5
15/20R
2.4kVA
1U Rack
mountable

Product Condition: New and Factory Fresh

Limited Warranty2 Year

Shipping Weight: 20 lbs.

Eaton Tripp Lite Series 1.9kW Single-Phase Switched Automatic Transfer Switch PDU, 2 120V L5-20P / 5-20P Inputs, 16 5-15/20R Outputs, 1U, TAA

Overview

Tech Specs

Specifications

Manufacturer	Tripp Lite by Eaton
Manufacturer Part Number	PDUMH20ATNET
Manufacturer Website Address	https://tripplite.eaton.com/
Brand Name	Tripp Lite by Eaton
Product Model	PDUMH20ATNET
Product Name	PDUMH20ATNET PDU Switched ATS 120V 20A 16 Outlet
Marketing Information	Tripp Lite Switched ATS / Auto Transfer Switch provides a redundant power option for single-corded network devices. Dual input cords support separate connection to PRIMARY and SECONDARY power sources. The ATS will normally maintain continuous output to all outlets as derived from the primary input cable. If the primary power source becomes unstable or fails altogether, the ATS will switch over to the secondary power source until the primary input is restored and stable. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, BOOTP and NTP. Switched PDU features include individually controllable output receptacles and built-in network interface. Super-fast switchover between primary and secondary power sources occurs within milliseconds. ATS functionality is supported by any two compatible AC power sources, regardless of phase angle, to support a variety of advanced redundant power networking applications. Enables fault tolerant hot-swappable UPS protection when used with a single UPS and fully redundant UPS protection when each cord is connected to a separate UPS system. In a two-UPS environment, the primary input cable must be supported by a full time sine wave UPS with zero transfer time. Tripp Lite SmartOnline series is highly recommended for use as the primary UPS in a two-UPS application. ATS configurations utilizing separate mains circuits, backup generators and even separate utility power grid feeds are fully supported. On-board ATS processor constantly evaluates power quality on both input sources to prevent transfer to the secondary source when unavailable or of lower quality than the primary source. Front input LED's display primary or secondary power availability.
Product Type	PDU

Technical Information

PDU Type	Switched
Plug/Connector Type	NEMA L5-20P
Plug/Connector Detail	2 x NEMA L5-20P
Receptacle Type	NEMA 5-15/20R
Receptacle Detail	16 x NEMA 5-15/20R

Power Description

Input Voltage	120 V AC
Output Voltage	120 V AC
Power Rating (VA)	2400 VA

Management

Integrated Automatic Transfer Switch (ATS) allows PDU to operate from secondary input source when primary input fails
Sequential outlet power-on prevents inrush-related equipment interaction on startup
Programmable or real-time monitoring and outlet power control via secure web/network interface

Physical Characteristics

Color Family	Black
Product Color	Black
Mount Type	Rack-mountable
Rack Height	1U
Number of Cord/Cable	2
Height	1.8"
Width	1.8"
Depth	14.5"
Weight (Approximate)	12.20 lb

Miscellaneous

Package Contents	PDUMH20ATNET PDU Switched ATS 120V 20A 16 Outlet PDU with attached L5-20P input power cord Detachable C19 to NEMA L5-20P 12 ft/3.6m power cord for optional secondary input Two NEMA L5-20R to NEMA 5-20P plug adapters User manual with warranty information
Certifications & Standards	60950 Class A TAA Compliant
Country of Origin	Taiwan
TAA Compliant	Yes
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

2 Year
