Tripp Lite by Eaton HP J4859C Compatible SFP Transceiver 1000Base-LX DDM Singlemode LC 1310 nm 10 km

Name: Tripp Lite by Eaton HP J4859C Compatible SFP Transceiver 1000Base-LX DDM Singlemode LC 1310 nm 10 km
Brand: TRIPP LITE
SKU: 8E2633
Price: 52.77 USD
Availability: InStock

TRIPP LITE

PCN#

8E2633

MFG#

N286-01GLX-SLX

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$52.77

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $23.99

1-Year $17.99

Estimated Shipment:

Product Highlights:

For Optical Network, Data Networking 1 LC Female Duplex 1000Base
LX Network
Optical Fiber9/125 µm
Single
mode
10 Gigabit Ethernet
1000Base
LX
Hot
pluggable

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 1 lbs.

Tripp Lite by Eaton HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310 nm, 10 km

Overview

Tech Specs

Specifications

Manufacturer	Tripp Lite by Eaton
Manufacturer Part Number	N286-01GLX-SLX
Manufacturer Website Address	https://tripplite.eaton.com/
Brand Name	Tripp Lite by Eaton
Product Model	N286-01GLX-SLX
Product Name	HP N286-01GLX-SLX SFP (mini-GBIC) Module
Marketing Information	The N286-01GLX-SLX HP J4859C Compatible 1000Base-LX LC SFP Transceiver with a duplex LC female connector functions just like the HP J4859C transceiver module and is designed to operate with HP networking equipment. It also meets or exceeds the J4859C's original specifications and complies with MSA (Multi-Source Agreement) standards. This 1000Base-LX transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 1 Gbps with 1310 nm wavelength signaling. It transmits across six miles (10 kilometers) of 9/125 SMF cabling. The N286-01GLX-SLX also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification.
Product Type	SFP (mini-GBIC)

Technical Information

Application/Usage

Optical Network
Data Networking

Interfaces/Ports

Total Number of Ports	1
Connector Type	LC
Interfaces/Ports Details	1 x LC Duplex 1000Base-LX Network

Media & Performance

Media Type Supported	Optical Fiber
Fiber Mode Supported	Single-mode
Ethernet Technology	10 Gigabit Ethernet
Network Technology	1000Base-LX

Physical Characteristics

Form Factor	Hot-pluggable
Height	0.3"
Width	0.5"
Depth	2.2"
Weight (Approximate)	0.05 lb

Miscellaneous

Package Contents	HP N286-01GLX-SLX SFP (mini-GBIC) Module Owner's manual
Compatibility	MSA Compliant HP Switches: 2920 Switch Series-2920-24G (J9726A#ABA) 2920 Switch Series-2920-24G-PoE+ (J9727A#ABA) 2920 Switch Series-2920-48G (J9728A#ABA) 2920 Switch Series-2920-48G-PoE+ (J9729A#ABA) 5820-14XG-SFP+ 2-slot Switch (JC106A) 5820-24XG-SFP+ Switch (JC102A) 5820AF-24XG Switch (JG219A) HP 1810-8G v2 Smart Desktop Switch-J9802A#ABA HP 1910 Series Switch-1910-24G-PoE (365w)-(JE007AS#ABA) HP 1910-24G-PoE (170W) Switch-JE008AS#ABA HP 2530-24 Switch-J9782A#ABA HP 2530-24G Switch 2530 Series-J9776A#ABA HP 2530-24-PoE+ Ethernet Switch-J9779A#ABA HP 2530-48G Switch-J9775A#ABA HP 2530-48G-PoE+ Switch-J9772A#ABA HP 2920-48G-POE+ Switch-J9836A#ABA ProCurve 2610/E2610 Series Switch-2610-48 (J9088A) ProCurve 2610/E2610 Series Switch-2610-48-PWR (J9089A) Procurve 2615/E2615 Series Switch-2615-8-PoE (J9565A) ProCurve 2620/E2620 Series Switch-2620-24 (J9623A) ProCurve 2620/E2620 Series Switch-2620-24-PoE+ (J9625A#ABA) ProCurve 2620/E2620 Series Switch-2620-24-PPoE+ (J9624A#ABA) ProCurve 2620/E2620 Series Switch-2620-48 (J9626A) ProCurve 2620/E2620 Series Switch-2620-48-PoE+ (J9627A#ABA) ProCurve 2800/E2800 Series Switch-2824 (J4903A) ProCurve 2800/E2800 Series Switch-2848 (J4904A) ProCurve 2810/E2810 Series Switch-2810-24G (J9021A) ProCurve 2810/E2810 Series Switch-2810-48G (J9022A) ProCurve 2900/E2900 Series Switch-2900-24G (J9049A) ProCurve 2900/E2900 Series Switch-2900-48G (J9050A) ProCurve 2910al/E2910al Series Switch - 2910al-24G (J9145A) ProCurve 2910al/E2910al Series Switch - 2910al-24G-PoE+ (J9146A) ProCurve 2910al/E2910al Series Switch - 2910al-48G (J9147A) ProCurve 2910al/E2910al Series Switch - 2910al-48G-PoE+ (J9148A) Procurve 2915/E2915 Series Switch - 2915-8G-PoE (J9562A) ProCurve 3400cl/E3400cl Series Switch - 3400cl-24G (J4905A) ProCurve 3400cl/E3400cl Series Switch - 3400cl-48G (J4906A) Procurve 3500/E3500 Series Switch - 3500-24 Switch (J9470A) Procurve 3500/E3500 Series Switch - 3500-24-PoE+ Switch (J9471A) Procurve 3500/E3500 Series Switch - 3500-48 PoE Switch (J8692A) Procurve 3500/E3500 Series Switch - 3500-48 Switch (J9472A) ProCurve 3500yl/E3500yl Series Switch - 3500yl-24G-PoE+ Switch (J9310A) ProCurve 3500yl/E3500yl Series Switch - 3500yl-24G-PWR (J8692A) ProCurve 3500yl/E3500yl Series Switch - 3500yl-48G-PoE+ Switch (J9311A) ProCurve 3500yl/E3500yl Series Switch - 3500yl-48G-PWR (J8693A) Procurve 3800/E3800 Series Switch - 3800-24G-2SFP+ (J9575A) Procurve 3800/E3800 Series Switch - 3800-24G-PoE+-2SFP+ (J9573A) Procurve 3800/E3800 Series Switch - 3800-24SFP-2SFP+ (J9584A) Procurve 3800/E3800 Series Switch - 3800-48G-4SFP+ (J9576A) Procurve 3800/E3800 Series Switch - 3800-48G-PoE+-4SFP+ (J9574A#ABA) ProCurve 4100gl Series Switch - gl 20-Port 10/100/1000 Module (J4908A) ProCurve 4100gl Series Switch - gl 6-Port Mini-GBIC Module (J4893A) ProCurve 5300xl Series Switch - xl 16-Port 10/100/1000 Module (J4907A) ProCurve 5300xl Series Switch - xl 4-Port Mini-GBIC Module (J4878A/B) ProCurve 5400zl/E5400zl Series Switch - 12-Port Gig-T PoE+/12-Port SFP v2 zl (J9637A) ProCurve 5400zl/E5400zl Series Switch - 20-Port Gig-T PoE+/2-Port SFP+ v2 zl (J9536A) https://www.tripplite.com/shared/literature/Flyer/n286-01glx-slx-compatibility-list-en.pdf
Environmentally Friendly	Yes
Country of Origin	China

Warranty

Limited Warranty

3 Year
