Tripp Lite by Eaton Isobar 8-Outlet Surge Protector 25 ft. Cord with Right-Angle Plug 3840 Joules Diagnostic LEDs Metal Housing

by
TRIPP LITE
PCN#
N17914
MFG#
ISOBAR825ULTRA
$108.07
cps

Extended & Accidental Damage Product Replacement Plan Available Details

  Free Shipping
Estimated Shipment:

Calculating Shipping

Product Highlights:
  • Receptacles: 8 x NEMA 5
  • 15R
  • 3840J
Product Condition: New and Factory Fresh
Limited WarrantyLifetime
Shipping Weight: 6 lbs.
Tripp Lite by Eaton Isobar 8-Outlet Surge Protector, 25 ft. Cord with Right-Angle Plug, 3840 Joules, Diagnostic LEDs, Metal Housing
Tech Specs
Specifications

Manufacturer

Tripp Lite by Eaton

Manufacturer Part Number

ISOBAR825ULTRA

Manufacturer Website Address

https://tripplite.eaton.com/

Brand Name

Tripp Lite by Eaton

Product Line

Isobar

Product Model

ISOBAR825ULTRA

Product Name

Isobar ISOBAR825ULTRA 8-Outlet Surge Suppressor

Marketing Information

For more than 20 years, America's leading companies have trusted Tripp Lite's Isobar Premium surge and noise suppressors to protect sensitive computer, networking and telecom equipment. With more than 18 million satisfied customers, the Isobar remains the world's #1 selling premium surge suppressor. Loaded with a generous combination of high quality components, near indestructible all-metal case and unique noise filtration system, the Isobar offers the highest level of protection attainable in a multi-outlet strip. Robust surge suppression circuits with sine-wave tracking offer extreme levels of protection against the heaviest surge conditions exceeding IEEE 587 category A & B specifications and reducing 6,000V test surges to harmless levels under 35 volts. Isobar's unique protection system combines large toroidal chokes, ferrite rod-core inductors, HF/VHF capacitors and multiple layers of metal oxide varistors into exclusive isolated filter banks that remove EMI/RFI interference, even noise generated by other pieces of connected equipment. ISOBAR825ULTRA offers 8 outlets arranged in four filter banks to prevent system crashes, reboots and performance problems common as noisy system peripherals are powered off and on. Surge suppression rated at 3840 joules/97,000 amps offers network-grade protection. Widely spaced NEMA 5-15 outlets accommodate up to 4 large transformer plugs without blocking outlets. Diagnostic LEDs confirm power availability, line fault and protection status. Includes 25 foot AC line cord with space-saving angled input plug, keyhole mounting tabs and a set of 4 child safety covers.PLUG/OUTLETS: Input: NEMA 5-15P/Output: 8 NEMA5-15R/25-ft. AC line cordELECTRICAL: 120V AC, 50/60Hz (Requires NEMA 5-15R wall receptacle)SUPPRESSION: AC: 140V RMS Clamping/3840 joules/97,000 ampsFORMAT: Corded all-metal strip with transformer spaced outlets

Product Type

Surge Suppressor/Protector
Technical Information

Plug/Connector Type

NEMA 5-15P

Receptacles

8 x NEMA 5-15R
Power Description

Input Voltage

120 V AC

Output Voltage

120 V AC

Maximum Line Current

15 A

Maximum Surge Current

97 kA

Power Handling

1440 VA

Surge Energy Rating

3840 J
Physical Characteristics

Power Cord/Cable Length

25 ft

Height

2.5"

Width

9"

Depth

3.5"

Weight (Approximate)

3.30 lb
Miscellaneous

Package Contents

  • Isobar ISOBAR825ULTRA 8-Outlet Surge Suppressor
  • Set of 4 Outlet Safety Covers
  • Instruction Manual with Warranty Information

Compatibility

  • Computers
  • Networks
  • CAD/CAM/CAE Workstations
  • Internetworking Accessories
  • Telecommunications Systems
  • Point of Sale Equipment
  • Audio/Video & Home Theater Systems

Environmentally Friendly

Yes

Country of Origin

China
Warranty

Limited Warranty

Lifetime
