Tripp Lite by Eaton Isobar Surge Protector Rackmount Metal 12 Outlet 15' Cord 1U RM

by
EATON
PCN#
114500
MFG#
ISOBAR12ULTRA
$167.42
cps

Extended & Accidental Damage Protection Plans Available Details

  Free Shipping
Estimated Shipment:

Calculating Shipping

Product Highlights:
  • Receptacles: 12 x NEMA 5
  • 15R
  • 3840J
Product Condition: New and Factory Fresh
Limited WarrantyLifetimeDirectly Connected Equipment Guarantee25000
Shipping Weight: 6 lbs.
Tripp Lite by Eaton Isobar Surge Protector Rackmount Metal 12 Outlet 15' Cord 1U RM
Tech Specs
Specifications

Manufacturer

Eaton Corporation

Manufacturer Part Number

ISOBAR12 ULTRA

Manufacturer Website Address

http://www.eaton.com

Brand Name

Tripp Lite series

Product Line

Isobar

Product Name

Isobar 12-Outlets 120V Surge Suppressor

Marketing Information

  • Tripp Lite's ISOBAR12ULTRA offers network-grade surge and noise suppression in a versatile all-metal multi-mount cabinet. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Features the highest level of AC surge and EMI/RFI noise suppression of all Tripp Lite rackmount surge suppressors. Outlets are arranged in exclusive isolated filter banks to limit noise interaction among connected items. Includes 12 outlets (2 front/10 rear), 15 ft AC power cord and guarded power switch to reduce the risk of accidental shutoff. Diagnostic LEDs indicate AC present, line fault and protection status. Lifetime warranty with

  • 25,000 Ultimate Lifetime Insurance (USA & Canada Only) coverage .PLUG/OUTLETS: Input: NEMA 5-15P/Output: 12 NEMA5-15R (2 front & 10 rear)ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle)FORMAT: Supports 19 in. rackmount (uses 1 rack space/1U), wallmount, under-counter and more

Product Type

Surge Suppressor/Protector
Technical Information

Plug/Connector Type

NEMA 5-15P

Receptacles

12 x NEMA 5-15R

Protection Type

Surge
Power Description

Input Voltage

120 V AC

Output Voltage

120 V AC

Maximum Line Current

15 A

Maximum Surge Current

96 kA

Power Handling

1800 VA

Surge Energy Rating

3840 J

Circuit Breaker

Yes
Controls/Indicators

Status Indicators

  • Line OK
  • Line fault
  • Protection present
  • Environmental Conditions

    Maximum Operating Temperature

    103°F (39.4°C)
    Physical Characteristics

    Color Family

    Black

    Product Color

    Black

    Product Material

    Metal

    Power Cord/Cable Length

    15 ft

    Height

    1.8"

    Width

    17.5"

    Depth

    4"

    Weight (Approximate)

    4.60 lb
    Miscellaneous

    Package Contents

  • Isobar 12-Outlets 120V Surge Suppressor
  • Rack-mounting brackets
  • Owner's manual
  • Additional Information

    • Transparent locking switch cover prevents accidental shutoff
    • 2 front and 10 rear receptacles

    Compatibility

    • Internetworking Equipment
    • Computers
    • Telecommunications Systems
    • Audio/Video Systems
    • Security & Sound Reinforcement

    Certifications & Standards

    • UL1449 (let through rating 330V)
    • UL1283
    • cUL
    • IEEE 587 category A and B

    Country of Origin

    Philippines

    Environmentally Friendly

    Yes

    Environmental Compliance

    Restriction of Hazardous Substances (RoHS)
    Warranty

    Limited Warranty

    Lifetime

    Directly Connected Equipment Guarantee

    • 25000
