Tripp Lite by Eaton VGA over Cat5/6 Extender Kit Box-Style Transmitter/Receiver for Video Up to 1000 ft. (305 m) TAA

Name: Tripp Lite by Eaton VGA over Cat5/6 Extender Kit Box-Style Transmitter/Receiver for Video Up to 1000 ft. (305 m) TAA
Brand: TRIPP LITE
SKU: RY8834
Price: 125.96 USD
Availability: InStock

TRIPP LITE

PCN#

RY8834

MFG#

B130-101-2

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$125.96

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $32.99

1-Year $24.99

Free Shipping

Estimated Shipment:

Product Highlights:

1 Input Device
2 Output Device
1000 ft Range
2 x Network (RJ
45)
1 x VGA In
2 x VGA Out
1920 x 1440
Twisted Pair
Category 6
Wall Mountable, Rack
mountable, Pole
mountable
TAA Compliant

Product Condition: New and Factory Fresh

Limited Warranty1 Year

Shipping Weight: 2 lbs.

Tripp Lite by Eaton VGA over Cat5/6 Extender Kit, Box-Style Transmitter/Receiver for Video, Up to 1000 ft. (305 m), TAA

Overview

Tech Specs

Specifications

Manufacturer	Tripp Lite by Eaton
Manufacturer Part Number	B130-101-2
Manufacturer Website Address	https://tripplite.eaton.com/
Brand Name	Tripp Lite by Eaton
Product Name	VGA over Cat5 Extender Kit ( Transmitter + Receiver )
Marketing Information	Tripp Lite's B130-101-2 allows you to extend a 1920 x 1440 (60Hz) video signal up to 500 ft., or a 1024 x 768 (60Hz) video signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6). The range and number of monitors can be further expanded by adding B132-110 repeater units. Connect up to 3 repeaters, with the B130-101-2 receiver at the end of the chain, for a total of 4 monitors. A 1920 x 1440 (60Hz) signal can be extended up to 500 ft. from the first repeater in the chain to the last receiver. A 1024 x 768 (60Hz) signal can be extended up to 1,000 ft. from the first repeater in the chain to the last receiver. For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K. The transmitter unit features functionality that allows for the EDID information from a connected display to be copied and sent to the connected computer, providing optimal compatibility. The remote (Receiver) unit features built-in Equalization and Gain controls to adjust the video image. Includes mounting hardware for both local and remote units, allowing them to be wallmounted, rackmounted or pole mounted. Ideal for digital signage situations, such as retail, schools, churches, etc.
Product Type	Video Extender Transmitter/Receiver

Technical Information

Connectivity Technology	Wired
Number of Input Devices Supported	1
Number of Output Devices Supported	2
Maximum Operating Distance	1000 ft

Video

Maximum Video Resolution

1920 x 1440

Interfaces/Ports

Network (RJ-45)	Yes
VGA In	Yes
VGA Out	Yes
Number of Network (RJ-45) Ports	2
Number of VGA Inputs	1
Number of VGA Outputs	2

Media & Performance

Media Type Supported	Twisted Pair
Twisted Pair Cable Standard	Category 6

Power Description

Input Voltage

110 V AC
220 V AC

Physical Characteristics

Color Family	Multicolor
Product Color	Black
Form Factor	Wall Mountable Rack-mountable Pole-mountable

Miscellaneous

Package Contents	Local (Transmitter) Unit 1 x 4.5 x 2.5 (in.) Remote (Receiver) Unit 1 x 2.5 x 3.5 (in.) Mini-Screwdriver for EQ/Gain Adjustment 2 x Mounting Hardware Kits 2 x External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A) Owner's Manual
Certifications & Standards	TAA
Country of Origin	Taiwan
TAA Compliant	Yes
Environmentally Friendly	Yes
Environmental Certification	RoHS
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

1 Year
