Tripp Lite by Eaton HDMI Signal Booster / Extender Cable 1920 x 1200 (1080p) 60Hz Up to 125 ft. (38 m) (HDMI M/F) 1 ft TAA

Name: Tripp Lite by Eaton HDMI Signal Booster / Extender Cable 1920 x 1200 (1080p) 60Hz Up to 125 ft. (38 m) (HDMI M/F) 1 ft TAA
Brand: TRIPP LITE
SKU: PP7006
Price: 30.78 USD
Availability: InStock

TRIPP LITE

PCN#

PP7006

MFG#

B123-001-60

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$30.78

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $11.99

1-Year $8.99

Estimated Shipment:

Product Highlights:

HDMI for Audio/Video Device, Monitor, TV
1 ft
1 x HDMI Male Digital Audio/Video
1 x HDMI Female Digital Audio/Video"

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 1 lbs.

Tripp Lite by Eaton HDMI Signal Booster / Extender Cable, 1920 x 1200 (1080p) 60Hz, Up to 125 ft. (38 m), (HDMI M/F), 1 ft, TAA

Overview

Tech Specs

Specifications

Manufacturer	Tripp Lite by Eaton
Manufacturer Part Number	B12300160
Manufacturer Website Address	https://tripplite.eaton.com/
Brand Name	Tripp Lite by Eaton
Product Model	B123-001-60
Product Name	1-ft. HDMI Active Signal Extender Cable (HDMI M/F)
Marketing Information	Tripp Lite's B123-001-60 HDMI Signal Extender increases the distance a 1080p @ 60Hz(or 1920 x 1200) signal can be transmitted beyond the recommended 16 ft.(5 m.). It supports computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p @ 60Hz, at a maximum distance of 125 ft. from the source. Use P568-Series HDMI cables in most applications. When extending a 1080p @ 60Hz(or 1920 x 1200) signal more than 75 ft., use cable made with 24Awg wiring, such as the P568-100-HD.(Lengths over 100 ft. are available from Tripp Lite as a custom order) 24Awg HDMI cable is also needed when extending a 3D signal more than 50 ft.. A 3D signal can be extended up to 125 ft. using 24Awg HDMI cable. Simply connect the longer cable between the source and the B123-001-60, and the built-in cable between the adapter and the monitor/TV. Software or drivers are not required. HDCP compliant. Compliant with the Federal Trade Agreements Act(TAA) for GSA Schedule purchases. The B123-001-60 has been designed for use with Tripp Lite P568-Series HDMI cables. To ensure maximum distance and performance, it is recommended that you use Tripp Lite P568-Series HDMI cabling. For distances over 75-ft, 24AWG cable such as Tripp Lite's P568-100-HD is required. Although most installations will not require power, a Micro USB port is provided in the event power is needed. Using a Micro USB cable(such as Tripp Lite's UR05C-Series), connect the Micro USB port to a USB wall charger, the USB port on your monitor, or the USB port on a computer.
Product Type	A/V Cable

Technical Information

Cable Type	HDMI
Cable Length	1 ft
Connector Type on First End	HDMI Digital Audio/Video - Male
Connector on First End Details	1 x HDMI Digital Audio/Video - Male
Connector Type on Second End	HDMI Digital Audio/Video - Female
Connector on Second End Details	1 x HDMI Digital Audio/Video - Female
Conductor	Copper
Device Supported	Audio/Video Device Monitor TV
Features	Repeater

Physical Characteristics

Color Family	Black
Product Color	Black

Miscellaneous

Package Contents	1-ft. HDMI Active Signal Extender Cable (HDMI M/F) External Power Supply ( Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A ) Screwdriver for Equalization Adjustment
Compatibility	Tripp Lite P568-Series HDMI Cables
Certifications & Standards	TAA
Environmentally Friendly	Yes
Country of Origin	Taiwan
TAA Compliant	Yes

Warranty

Limited Warranty

3 Year
