Tripp Lite by Eaton UPS 550VA 300W Line-Interactive UPS - 8 NEMA 5-15R Outlets AVR 120V 50/60 Hz USB Desktop/Wall Mount

Name: Tripp Lite by Eaton UPS 550VA 300W Line-Interactive UPS - 8 NEMA 5-15R Outlets AVR 120V 50/60 Hz USB Desktop/Wall Mount
Brand: TRIPP LITE
SKU: H29909
Price: 94.11 USD
Availability: InStock

TRIPP LITE

PCN#

H29909

MFG#

AVR550U

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$94.11

Extended & Accidental Damage Product Replacement Plan Available Details

1-Year $22.99

2-Year $29.99

Free Shipping

Estimated Shipment:

Product Highlights:

Ultra
compact Desktop/Tower/Wall Mount
AVR
8 Hour Recharge
2 Minute Stand
by
120 V AC Input
110 V AC, 115 V AC, 120 V AC Output
Single Phase
Pulse
width Modulated Sine Wave
USB
8 x NEMA 5
15R

Product Condition: New and Factory Fresh

Limited Warranty3 Year LifetimeAdditional Warranty Information2-year warranty. 100,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only).

Shipping Weight: 10 lbs.

Tripp Lite by Eaton 550VA 300W Line-Interactive UPS - 8 NEMA 5-15R Outlets, AVR, 120V, 50/60 Hz, USB, Desktop/Wall Mount Battery Backup

Overview

Tech Specs

Specifications

Manufacturer	Tripp Lite by Eaton
Manufacturer Part Number	AVR550U
Manufacturer Website Address	https://tripplite.eaton.com/
Brand Name	Tripp Lite by Eaton
Product Series	AVR
Product Model	AVR550U
Product Name	Desktop/Wall Mount Battery Backup Outlets
Marketing Information	AVR Series Line-Interactive UPS System offers 550VA ultra-compact line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space-saving right-angle input plug, four battery/surge-protected outlets and four additional surge-only outlets (8 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.
Packaged Quantity	1 Each
Product Type	Line-interactive UPS

Technical Information

AVR	Yes
AVR Range	Boost +18% / Buck -15%
Plug/Connector Type	NEMA 5-15P
Receptacle Type	NEMA 5-15R
Receptacle Detail	8 x NEMA 5-15R
Number of Battery & Surge Outlets	4
Number of Surge-only Outlets	4
Dataline Protection	RJ-11
Cord Length	6 ft
Transfer Time	6 ms
EMI/RFI Noise Filter	Yes
Phase	Single Phase
Energy Saving	Greater than 95% efficiency - GREEN UPS
Application/Usage	Printer Speaker Computer Router TV Blu-ray Player Gaming Console ATM Security System Digital Signage Media Center Home/Office Home Theater

Power Description

Load Capacity (VA)	550 VA
Load Capacity (Watt)	300 W
Input Voltage	120 V AC
Input Current	12 A
Output Voltage	110 V AC 115 V AC 120 V AC
Input Frequency	60 Hz
Output Frequency	60 Hz
Waveform Type	Pulse-width Modulated Sine Wave
Surge Energy Rating	316 J

Management

Alarm

Battery Backup
Low Battery
Overload
Replace Battery
Fault

Controls/Indicators

Status Indicators

2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low, overload, replace-battery and fault conditions

Interfaces/Ports

USB	Yes
USB (HID Compliant) Port	Yes

Battery Information

DC System Voltage	12 V DC
Backup/Run Time (Full Load)	2 Minute
Backup/Run Time (Half Load)	9 Minute
Battery Life	6 Year
Typical Battery Recharge Time	8 Hour
Replaceable Battery	Yes

Environmental Conditions

Maximum Operating Temperature	104°F (40°C)
Storage Temperature	5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation	10000 ft

Physical Characteristics

Color Family	Black
Product Color	Black
Height	4.3"
Width	6.4"
Depth	12"
Form Factor	Ultra-compact Desktop/Tower/Wall Mount
Weight (Approximate)	13.69 lb

Miscellaneous

Package Contents	Desktop/Wall Mount Battery Backup Outlets USB cable Owner's manual
Additional Information	Low voltage transfer to battery power: Switches to battery power as line voltage drops to 83V or lower / Resets to AC mode as line voltage increases to 87V or higher High voltage transfer to battery power: Switches to battery power as line voltage increases to 147V or higher / Resets to line power as line voltage drops to 143V or less Cold Start: Yes, inverter can be "cold started" to enable temporary AC output during a power failure Switches: Combination power off / on / self-test push button switch Typical Application: Basic PCs for home / home-office use, network workstations, audio/video equipment, home entertainment systems and other sensitive electronic devices. WatchDog compatibility: Yes, compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment - ideal for unattended kiosk applications Supports entry-level PC systems up to 17 minutes during blackout conditions Form factors supported: Ultra-compact desk/floor mount , mounting flanges enable wall-mount installation 8 output receptacles, 2 of which are widely spaced to accommodate large transformer plugs without blocking outlets 4 outlets feature full battery support and surge suppression, protecting computers, monitors and other vital system components from loss of power 4 additional outlets with surge suppression only are ideal for printers and other peripherals not requiring battery support HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows, Mac OS X and Linux
Certifications & Standards	Tested to UL1778 (USA) cUL1778 (Canada) NOM (Mexico) FCC Class B (Emissions) FCC Part 68 Industry Canada (Telecommunications)
Software Included	PowerAlert UPS monitoring software
Recycled	No
Assembly Required	No
Country of Origin	Vietnam

Warranty

Limited Warranty	3 Year Lifetime
Additional Warranty Information	2-year warranty. 100,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only).
