OMADA 8-PORT SMART POE+ SWITCH OMADA 8-PORT GIG SMART POE+ SWITCH

Name: OMADA 8-PORT SMART POE+ SWITCH OMADA 8-PORT GIG SMART POE+ SWITCH
Brand: TP-LINK SYSTEMS INC.
SKU: NK5104
Price: 114.99 USD
Availability: InStock

TP-LINK SYSTEMS INC.

PCN#

NK5104

MFG#

SG2210P

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$114.99

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $32.99

1-Year $24.99

Free Shipping

Estimated Shipment:

Product Highlights:

8 Ports
Manageable
Gigabit Ethernet
10/100/1000Base
T, 100/1000Base
X
2 Layer Supported
2 SFP Slots
77.80 W Power Consumption
61 W PoE Budget
Twisted Pair, Optical Fiber
PoE Ports
Desktop, Wall Mountable

Product Condition: New and Factory Fresh

Shipping Weight: 1 lbs.

Omada 10-Port Gigabit Smart Switch with 8-Port PoE+

Overview

Tech Specs

Specifications

Manufacturer	TP-LINK Technologies Co., Ltd
Manufacturer Part Number	SG2210P
Manufacturer Website Address	http://www.tp-link.com/us
Brand Name	Omada
Product Model	SG2210P
Product Name	10-Port Gigabit Smart Switch with 8-Port PoE+
Marketing Information	Omada 10-Port Gigabit Smart Switch with 8-Port PoE+ SG2210P 8× Gigabit PoE+ Ports, 2× Gigabit SFP Slots 61 W Total PoE Budget Fanless Design for Silent Operation Zero-Touch Provisioning Centralized Management Omada App Static Routing Traffic Separation Software Defined Networking (SDN) with Cloud Access Remotely manage your access points, switches, and gateways across multiple sites all from a single interface. Multiple Application Scenarios \| Surveillance Works with IP Cameras Conference Call Works with IP Phones Wi-Fi Coverage Works with Access Points Wired Connections Works with Non-PoE Devices such as PCs and Printers
Product Type	Ethernet Switch

Technical Information

Features

Virtual LAN (VLAN)
Access Control List
Quality of Service (QoS)
IGMP Snooping
Zero-Touch Provisioning (ZTP)
Fanless
Reset Button
Auto-negotiation
Broadcast Storm Control
Multicast Storm Control
Unicast Storm Control
DHCP Relay
Link Aggregation
Loopback Detection
Flow Control
Remote Monitoring (RMON)

Interfaces/Ports

Total Number of Network Ports	8
Network (RJ-45)	Yes
Port/Expansion Slot Details	8 x Gigabit Ethernet PoE+ 2 x Gigabit Ethernet Expansion Slot

Media & Performance

Media Type Supported	Twisted Pair Optical Fiber
Ethernet Technology	Gigabit Ethernet
Network Technology	10/100/1000Base-T 100/1000Base-X
Maximum Data Transfer Rate	128 MB/s

I/O Expansions

Total Number of Expansion Slots	2
Expansion Slot Type	SFP
Number of SFP Slots	2

Network & Communication

Layer Supported	2
Networking Standards	IEEE 802.3af IEEE 802.3at IEEE 802.1p IEEE 802.3x IEEE 802.1ab IEEE 802.1Q IEEE 802.1x

Management & Protocols

Manageable	Yes
Data Link Protocols	HTTP HTTPs

Power Description

PoE (RJ-45) Port	Yes
PoE Budget	61 W
Input Voltage	110 V
Frequency	60 Hz
Power Source	Power Adapter DC
Power Consumption	77.80 W

Physical Characteristics

Product Material	Metal
Form Factor	Desktop Wall Mountable
Height	1"
Width	8.2"
Depth	4.9"

Miscellaneous

Package Contents	10-Port Gigabit Smart Switch with 8-Port PoE+ Power Adapter Installation Guide Rubber Feet
Application/Usage	Network IP Camera IP Phone Wireless Access Point Printer PC Surveillance
Certifications & Standards	CE FCC
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
