Supermicro SuperServer 7049P-TRT Barebone System - 4U Tower - Socket P LGA-3647 - 2 x Processor Support

Name: Supermicro SuperServer 7049P-TRT Barebone System - 4U Tower - Socket P LGA-3647 - 2 x Processor Support
Brand: SUPERMICRO
SKU: 5CT415
Price: 2235.06 USD
Availability: OutOfStock

SUPERMICRO

PCN#

5CT415

MFG#

SYS-7049P-TRT

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Estimated Shipment:

Product Highlights:

Intel C622 Chip
2 TB DDR4 SDRAM DDR4
2666/PC4
21300 Maximum RAM Support
16 Total Memory Slots
Serial ATA/600 RAID Supported Controller
ASPEED AST2500 Graphic(s)
8 3.5" Bay(s)
8 SATA Interface(s)
Processor Support (Xeon Gold, Xeon Silver, Xeon Bronze, Xeon Platinum)
10 Gigabit Ethernet
2 USB 3.0 Port(s)
2 x 1280 W
3 Year

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 71 lbs.

Supermicro SuperServer 7049P-TRT Barebone System - 4U Tower - Socket P LGA-3647 - 2 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Supermicro Computer, Inc
Manufacturer Part Number	SYS-7049P-TRT
Manufacturer Website Address	http://www.supermicro.com
Brand Name	Supermicro
Product Line	SuperServer
Product Model	7049P-TRT
Product Name	SuperServer 7049P-TRT (Black)
Marketing Information	Supermicro's X11 DP/UP SuperServer^®, SuperWorkstation, SuperStorage, and SuperBlade^®solutions offer numerous advantages over previous generations and the highest levels of performance, efficiency, security and scalability in the industry. Supermicro X11 SuperServers support the latest Intel^® Xeon^® Scalable processors and offer 3TB ECC 3DS LRDIMM or RDIMM DDR4-2666MHz memory in 24 DIMMs, 7 PCI-E slots, SAS 3.0/SATA 3.0/NVMe hot-swap HDD/SSD support, 10GBase-T/10G SFP+/56Gbps FDR InfiniBand networking options, redundant Titanium Level (96%+) Digital power supplies, and IPMI 2.0 plus KVM with dedicated LAN. The SuperWorkstation systems offer in addition 7.1 HD Audio, SLI and Thunderbolt support, and up to 11 USB ports.
Product Type	Barebone System

Processor

Number of Processors Supported	2
Processor Socket	Socket P LGA-3647
Processor Supported	Xeon Gold Xeon Silver Xeon Bronze Xeon Platinum
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	C622

Memory

Maximum Memory Supported	2 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2666/PC4-21300
Number of Total Memory Slots	16

Controllers

Controller Type	Serial ATA/600
RAID Supported	Yes

Display & Graphics

Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	AST2500

Network & Communication

Ethernet Technology

10 Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	11
Number of External 5.25" Bays	3
Number of 3.5" Bays	8
Number of Total Expansion Slots	6
Number of PCI Express x8 Slots	2
Number of PCI Express x16 Slots	4

Interfaces/Ports

Total Number of USB Ports	7
Number of USB 3.0 Ports	2
Number of SATA Interfaces	8

Power Description

Input Voltage	120 V AC 230 V AC
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1280 W

Physical Characteristics

Product Color	Black
Form Factor	Tower
Rack Height	4U
Height	17.8"
Width	7"
Depth	25.5"
Weight (Approximate)	56 lb

Miscellaneous

Package Contents

SuperServer 7049P-TRT (Black)
1 x Super X11DPi-NT Motherboard
1 x 8-port 4U/Tower 3.5-inch SAS3/SAS2/SATA3 12Gbps backplane for SC743/SC745 chassis
2 x MINI SAS HD-MINI SAS,6G,INT,50CM,SB,30AWG
2 x MINI SAS HD-MINI SAS,6G,INT,50CM,SB,30AWG
1 x STD I/O shield for X9 socket R server MB with Gasket.
1 x SYS-7049P-TR/SYS-7049P-TRT, QRG
2 x 2U Passive CPU Heat Sink for X11 Purley Platform Equipped with a Narrow Retention Mechanism
2 x 1U 1280W, redundant single output power supply
1 x POWER DISTRIBUTOR FOR SC747 W/ GRAPHIC OUTPUT FEATURE
1 x CBL,FRONT CNTL,16 TO 16 PIN,Ribbon,50CM
2 x NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt)
3 x 4 PIN TO 4 PIN MIDDLE FAN POWER EXTENSION, 20cm. 24AWG(PWM)
1 x USB 3.0,INT,19 PIN/F TO 19PIN/F,2 CH,80CM,30/28/26AWG
2 x 80x80x38 mm, 9.4K RPM, Hot-swappable Rear Exhaust Fan for X11 Purley Platform Newly Enabled 4U Chassis
3 x 80x80x38 mm, 9.4K RPM, Hot-swappable Middle Cooling Fan for X11 Purley Platform Newly Enabled 4U Chassis
8 x Black Hot-swap 3.5inch HDD Tray (w/o logo)
1 x Plastic feet (4 pcs set) for 4U tower chassis, black color
1 x SC745 Intel DP X9, X8 PC air shroud 1368x13/12x13MB

Environmentally Friendly

Yes

Warranty

Limited Warranty

3 Year
