StarTech.com 4 Port PCI Express USB 3.0 Card - 3 External and 1 Internal - 5Gbps

by
STARTECH
PCN#
ZQ0763
MFG#
PEXUSB3S42
$37.70
cps

Extended & Accidental Damage Product Replacement Plan Available Details

Estimated Shipment:

Calculating Shipping

Product Highlights:
  • Add four USB 3.0 ports
  • three external and one internal port
  • to your computer

Show more

Product Condition: New and Factory Fresh
Limited Warranty2 Year
Shipping Weight: 1 lbs.
StarTech.com 4 Port PCI Express USB 3.0 Card - 3 External and 1 Internal - 5Gbps
Tech Specs
Specifications

Manufacturer

StarTech.com

Manufacturer Part Number

PEXUSB3S42

Manufacturer Website Address

http://www.startech.com

Brand Name

StarTech.com

Product Name

4-Port PCI Express USB 3.0 Card - 5Gbps

Marketing Information

Here's a cost-effective solution for adding USB 3.2 Gen 1 connectivity to your computer. This 4-port PCIe USB 3.2 Gen 1 card gives you three external ports and one internal port, for the ultimate connection flexibility.

With three external USB 3.2 Gen 1 ports you can connect more devices to your computer. The card provides easy access to commonly-used peripherals such as your tablet and external hard drive. It also features an internal USB port that lets you connect a device such as a flash drive inside your computer case, providing added security and convenience.

USB 3.2 Gen 1 gives you fast access to your files with data transfer rates up to 5 Gbps. Plus it's backward compatible with USB 2.0 and 1.x devices, which eliminates the cost and aggravation of upgrading your existing devices.

Setup is a breeze with native operating system support. The USB 3.2 Gen 1 adapter card automatically installs in Windows 8.1, 8 and 7.

For convenient installation, this PCI Express USB 3.2 Gen 1 card features a dual-profile design that can be installed in almost any type of computer. It comes equipped with a standard profile bracket and also includes a low-profile bracket for installation in small form-factor/half-height systems.

This high-performance USB 3.2 Gen 1 card is enhanced with UASP support, which can perform ~70% faster read speed and ~40% faster write speed over traditional USB 3.2 Gen 1, when paired with .

The PEXUSB3S42 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Note: UASP (USB Attached SCSI Protocol) is supported in Windows 8.1, 8, Server 2012 and Linux kernel 2.6.37 or later. Test results were obtained using an Intel Ivy Bridge system, StarTech.com add-on USB 3.2 Gen 1 cards, a UASP-enabled StarTech.com enclosure, and a SATA III solid state drive.

Packaged Quantity

1

Product Type

USB Adapter
Technical Information

Host Interface

PCI Express x1
Media & Performance

UASP Support

Yes
Interfaces/Ports

Total Number of USB Ports

4

Number of USB 3.2 Ports

4

Number of SATA Ports

1
Software

Operating System Supported

  • Windows XP
  • Windows Vista
  • Windows 7
  • Windows 8
  • Windows 8.1
  • Windows Server 2008 R2
  • Windows Server 2012
  • Windows Server 2016
  • Windows Server 2019
  • Linux
  • Windows 10
  • Windows 11
Physical Characteristics

Product Color

Black

Form Factor

Plug-in Card

Height

4.7"

Width

0.7"

Length

3.4"

Weight (Approximate)

1.90 oz
Miscellaneous

Package Contents

  • 4-Port PCI Express USB 3.0 Card - 5Gbps
  • 1 x Low-Profile Bracket
  • 1 x Driver CD
  • 1 x Instruction Manual

Additional Information

  • Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64)
  • Windows Server® 2012, 2008 R2
  • Linux 2.6.31 and later (tested up to 3.5)
  • Platform Supported

    • PC
    • Linux

    Environmentally Friendly

    Yes

    Country of Origin

    China
    Warranty

    Limited Warranty

    2 Year
