StarTech.com 10/100 Fiber to Ethernet Media Converter Multi Mode SC 2 km

Name: StarTech.com 10/100 Fiber to Ethernet Media Converter Multi Mode SC 2 km
Brand: STARTECH
SKU: BH3945
Price: 70.42 USD
Availability: InStock

STARTECH

PCN#

BH3945

MFG#

MCM110SC2

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$70.42

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $23.99

1-Year $17.99

Estimated Shipment:

Product Highlights:

Convert and extend a 10/100 Mbps Ethernet connection up to 2 km over Multi Mode SC fiber
fiber converter
ethernet media converter
fibre converter
10/100 media converter
utp to fiber

Product Condition: New and Factory Fresh

Limited Warranty2 Year

Shipping Weight: 1 lbs.

StarTech 10/100 Fiber to Ethernet Media Converter Multi Mode SC 2 km, TAA

Overview

Tech Specs

Specifications

Manufacturer	StarTech.com
Manufacturer Part Number	MCM110SC2
Manufacturer Website Address	http://www.startech.com
Brand Name	StarTech.com
Product Name	10/100 Fiber to Ethernet Media Converter Multi Mode SC 2 km
Marketing Information	The MCM110SC2 10/100 Multi Mode Fiber Ethernet Media Converter SC 2 km creates an economical, cost-effective Ethernet-fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals to extend an Ethernet network connection over an SC terminated multimode fiber backbone. The converter supports a maximum multimode fiber optic cable distance of 2 kilometers (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using SC-terminated multimode fiber, while delivering solid network performance and scalability. This versatile Ethernet to Fiber converter is compatible with most 3COM™, Cisco™, Lucent™ and Nortel™ networks and fully complies with applicable IEEE 802.3 standards. Backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer
Packaged Quantity	1 Each
Product Type	Transceiver/Media Converter

Interfaces/Ports

Total Number of Ports	2
Network (RJ-45)	Yes
Number of Network (RJ-45) Ports	1
Number of SC Ports	1
SC Port Type	Duplex

Media & Performance

Media Type Supported	Optical Fiber Twisted Pair
Fiber Mode Supported	Multi-mode
Fiber Optic Cable Wavelength	1310 nm

Network & Communication

Ethernet Technology	Fast Ethernet
Network Technology	10Base-T 100Base-FX 100Base-TX

Power Description

Power Source	AC Adapter
Power Consumption	2.40 W
Plug/Connector Type	Type M

Physical Characteristics

Form Factor	External
Height	0.8"
Width	3"
Depth	3.7"
Weight (Approximate)	3 oz

Miscellaneous

Additional Information	Plug Type: M Fiber Operating Mode: Half/Full-Duplex
Environmentally Friendly	Yes
Environmental Certification	EU RoHS
Environmental Compliance	Restriction of Hazardous Substances (RoHS) 2 Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin	Taiwan
TAA Compliant	Yes
End of Life Manual Availability	Yes
EU RoHS Declaration URL	https://media.startech.com/cms/pdfs/mcm110sc2_rohs.pdf
REACH Declaration URL	https://media.startech.com/cms/pdfs/mcm110sc2_rohs.pdf
REACH free of SVHC	Yes
WEEE Statement	https://media.startech.com/cms/pdfs/mcm110sc2_weee.pdf

Warranty

Limited Warranty

2 Year
