StarTech.com Thunderbolt 4 Multi-Display Docking Station, Quad/Triple/Dual Monitor Dock, 2x HDMI/2x DP, 7x USB Hub, 2.5Gb Ethernet, 98W PD

Flexible High-Performance Video Supporting up to Quad-Monitor 4K 60Hz

The dock is equipped with 2x HDMI and 2x DisplayPort video outputs for connecting multiple monitors to the host computer. The dock offers video flexibility, supporting single, dual, triple, or quad monitor configurations. With an Intel 12th Gen processor or higher that supports DP 1.4 with DSC, the docking station can support a quad-monitor configuration with resolutions up to 4K 60Hz. Quad displays are also available at lower resolutions or refresh rates on computers without DSC or with earlier Intel revisions. In addition, the dock supports a single 8K 60Hz display on either of the HDMI output ports.

Apple computers equipped with M1, M2, or M3 Max/Pro processors support dual displays. For Apple computers featuring the M1, M2, or M3 base processor, as well as iPad Pros with M1 or later processors, a single display is supported.

Port Connectivity

The docking station utilizes the high 40Gbps throughput available from your computer's Thunderbolt 4, Thunderbolt 3, or USB4 port to provide a wide range of port connectivity to suit a variety of applications.

The dock features:

• 2x HDMI ports to connect displays

• 2x DisplayPort ports to connect displays

• 3x USB 3.2 Gen 2 (10Gbps) Type-A ports to connect USB peripheral devices

• 1x USB 3.2 Gen 2 (10Gbps) Type-C ports to connect USB peripheral devices

• 2x USB 3.2 Gen 1 (5Gbps) Type-A ports to connect USB peripheral devices

• 1x USB 2.0 (480Mbps) Type-A port that supports BC 1.2 with 7.5W (1.5A) for charging battery powered USB devices

• 1x 2.5 Gigabit Ethernet port with PXE boot and WoL to connect to a wired Local Area Network (LAN)

• 1x Secure Digital (SD) 4.0/UHS-II card reader to externally access SD, SDHC and SDXC memory cards

• 1x Micro Secure Digital (microSD) 4.0/UHS-II card reader to externally access mSD, mSDHC and mSDXC memory cards

• 1x 3.5mm 4-position TRRS Audio Jack to connect a 3.5mm headset

98W USB Power Delivery Certified

The Thunderbolt 4 docking station includes a 180W power adapter and supports 98W USB power delivery. This enables the dock to charge the laptop, with enough additional power for the downstream USB 2.0 port to support BC 1.2 with 7W (1.5A) for charging tablets, smartphones or other battery-powered USB devices.

Thunderbolt Certified

This certification ensures the dock will be fully compatible with Intel Evo/Tiger Lake (11th gen & up) Thunderbolt 4 laptops including: Dell Precision 5560/5760, XPS 13 9310, HP EliteBook 850 G8, ProBook 450 G8, and Lenovo X1 Carbon 9th Gen. The dock is also compatible with M1/M2/M3 Pro/Max MacBooks.

• microSD
• SD
• Micro Size MultiMediaCard (MMC)
• SDHC
• SDXC
• microSDHC
• microSDXC

• PXE Boot
• Wake-on-LAN
• MAC Address Pass-through

• 8K
• 4K @ 60Hz

• 3840 x 2160
• 7680 x 4320

• Windows 11
• Windows 10
• macOS Big Sur
• macOS Monterey
• macOS Ventura
• macOS Sonoma
• Ubuntu

• 120 V AC
• 230 V AC

• Docking Station
• 1 x 3ft (1m) Thunderbolt 4 Host Cable
• 1 x Universal Power Adapter (North America)
• 1 x Quick-Start Guide

Compatible Devices:

• Apple iPad Pros with M1 or later processors
• Intel Evo/Tiger Lake (11th gen & up) Thunderbolt 4 laptops
• Dell Precision 5560 Mobile Workstation
• Dell Precision 5760 Mobile Workstation
• Dell XPS 13 9310 2 in 1 Laptop
• HP EliteBook 850 G8 Notebook PC
• HP ProBook 450 G8 Notebook PC
• Lenovo X1 Carbon 9th Gen Laptop
• Apple M1/M2/M3 Pro/Max MacBooks
• Apple MacBook Air
• Apple iPad Pro M1
• All Thunderbolt 4/3 and USB4 laptops

• Intel
• HP
• Dell
• Lenovo
• Apple
