681 US WIRELESS AP ADVANCED 3Y (NO POE)

Enhanced user experienceSonicWave APs enhance the user experience in a number of ways. Not only are processor speeds faster, but beamforming allows for a more direct connection that is faster and more reliable than without beamforming. Improved power control methods help to avoid interference with nearby networks, making for a better experience. And Target Wake Time management helps preserve battery life in mobile devices. Best-in-class wireless securityMost SonicWave access points include a separate radio dedicated to security, which performs rogue AP detection, passive scanning and packet capturing.The SonicWave solution also integrates additional securityrelated features, including wireless intrusion detection and prevention, virtual AP segmentation, wireless guest services, RF monitoring and wireless packet capture. SonicWave APs also feature zero-wait DFS, which identifies and avoids interference with radar systems while eliminating the wait associated with being booted from one DFS channel and finding another to connect with. Intuitive cloud management and monitoring toolSonicWave APs are easy to set up and deploy. They integrate with SonicWall Wireless Network Manager, which is a highly intuitive, scalable and centralized Wi-Fi network management system capable of delivering rich wireless and switching analytics, as well as simplified, single-pane-ofglass onboarding via the cloud. The APs also integrate with WiFi Planner, a site survey tool that enables you to optimally design and deploy a wireless network, resulting in a reduced total cost of ownership. And with RF spectrum analysis, you can detect and identify the source of RF interference and monitor the health of a wireless system.Product TypeWireless Access PointTechnical InformationWireless LAN StandardIEEE 802.11 a/b/g/n/ac/axBluetooth StandardBluetooth 5Network BandDual BandFrequency Band

• 2.40 GHz
• 5 GHz

Total Number of Antennas12Number of Internal Antennas12Indoor/OutdoorIndoorMIMO TechnologyYesMIMO TypeMulti User MIMOBeamforming TechnologyYesData EncryptionYesEncryption Standard

• WPA3
• WPA2
• AES
• WPA2-ENT

High Availability SupportedYesInterfaces/PortsEthernet Technology

• 5 Gigabit Ethernet
• Gigabit Ethernet
• Fast Ethernet

Number of Network (RJ-45) Ports1PoE PD PortYesUSBYesUSB StandardUSB 3.0Management PortYesNetwork & CommunicationWi-Fi GenerationWi-Fi 6Communication Protocols

• RADIUS
• SSL

Power DescriptionPower Consumption34 WPhysical CharacteristicsForm FactorCeiling MountableAntenna Form FactorInternalHeight8.4"Width8.4"Depth1.5"Weight (Approximate)2.43 lbMiscellaneousPackage Contents

• SonicWave 681 Wireless Access Point
• Ceiling Mounting Kit

Certifications & Standards

• FCC/ICES Class B
• CE
• RCM/ACMA
• VCCI Class B
• TELEC
• BSMI
• NCC
• MSIP
• ANATEL
• Customs
• Union
• UL E211396
• UL 62368-1
• UL 60950-1 cUL CAN/CSA C22.2 No. 62368-1-14
• CAN/CSA C22.2 No. 62368-1-14
• EN 60950-1 Or EN 62368-1
• IEC 60950-1
• IEC 62368-1
• Europe
  EN 60950-1
• EN62368-1
• Taiwan
  CNS 1336-1
• USA
  FCC Part 15C 15E
• Canada
  ISED RSS-247
• Europe
  (RED) EN 300 328
• EN 301 893
• Aus/NZ
  AS/NZs 4268, Taiwan
  NCC LP002
• USA
  FCC P15B
• Canada
  ICES-003
• Europe
  EN 301 489-1, -17
• EN 55032
• EN 55024
• Aus/NZ
  CISPR 32
• Japan
  VCCI
• Taiwan
  CNS 13438
• USA
  FCC Part 2
• Canada
  RSS-102
• Europe
  EN 50385
• Aus/Nz
  ASNZS 2772

Environmental Compliance

• Waste Electrical and Electronic Equipment Directive (WEEE)
• Restriction of Hazardous Substances (RoHS)
• China Restriction of Hazardous Substances (China RoHS)
