Shuttle XPC slim DH470 Barebone System - Slim PC - Socket LGA-1200 - 1 x Processor Support

Name: Shuttle XPC slim DH470 Barebone System - Slim PC - Socket LGA-1200 - 1 x Processor Support
Brand: SHUTTLE COMPUTER
SKU: 9BP168
Price: 319.49 USD
Availability: InStock

SHUTTLE COMPUTER

PCN#

9BP168

MFG#

DH470

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$319.49

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

Intel H470 Chip
64 GB DDR4 SDRAM DDR4
2933/PC4
23466 Maximum RAM Support
2.0 Total Memory Slots
Serial ATA/600 Controller
Intel HD Graphics Graphic(s)
1 SATA Interface(s)
Processor Support (Core i9, Core i7, Core i5, Core i3, Pentium Gold, Celeron)
Gigabit Ethernet
3 USB 3.2 Gen 1 Port(s)
90 W

Product Condition: New and Factory Fresh

Shipping Weight: 7 lbs.

Shuttle XPC slim DH470 Barebone System - Slim PC - Socket LGA-1200 - 1 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Shuttle, Inc
Manufacturer Part Number	DH470
Manufacturer Website Address	http://www.us.shuttle.com
Brand Name	Shuttle
Product Line	XPC slim
Product Model	DH470
Product Name	XPC slim DH470 Barebone System
Marketing Information	ROBUST 1.3-LITRE SLIMPC SUPPORTS INTEL "COMET LAKE-S" 10-CORE PROCESSORS AND THREE UHD DISPLAYS The Shuttle XPC slim Barebone DH470 with H470 chipset houses the performance of Intel's 10th generation Core desktop processors (codenamed Comet Lake-S) for socket LGA1200 in a compact 1.3-litre format. The DH470 allows for three Ultra HD displays to be operated at the same time via HDMI 2.0a and 2x DisplayPort. It also offers Dual Intel LAN, four USB 3.2 Gen 2 and COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.
Product Type	Barebone System

Processor

Number of Processors Supported	1
Processor Socket	Socket LGA-1200
Processor Supported	Core i9 Core i7 Core i5 Core i3 Pentium Gold Celeron
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	H470

Memory

Maximum Memory Supported	64 GB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2933/PC4-23466
Total Number of Memory Slots	2.0

Storage

Supported Storage Drive Types

Controllers

Controller Type

Serial ATA/600

Display & Graphics

Graphics Controller Manufacturer	Intel
Graphics Controller Model	HD Graphics
Graphics Memory Technology	DDR4 SDRAM
Graphics Memory Accessibility	Shared

Network & Communication

Ethernet Technology

Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays

Interfaces/Ports

HDMI (Rear)	Yes
Total Number of USB Ports	8
Number of USB 3.2 Gen 1 Ports	3
Number of USB 3.2 Gen 2 Ports	4
USB Type-C (Front)	Yes
USB Type-C Detail	1x Type-C
Number of SATA Interfaces	1

Operating System

Operating System Supported

Windows 10 x64
Linux

Power Description

Input Voltage	120 V AC 230 V AC
Maximum Power Supply Wattage	90 W

Physical Characteristics

Color Family	Black
Product Color	Black
Form Factor	Slim PC
Height	1.7"
Width	6.5"
Depth	7.5"
Weight (Approximate)	2.87 lb

Miscellaneous

Application/Usage	Business
Energy Star	Yes
