RUCKUS/BROCADE BROCADE ICX 7750 WITH 48

Name: RUCKUS/BROCADE BROCADE ICX 7750 WITH 48
Brand: RUCKUS WIRELESS
SKU: 6768AE
Price: 19215.63 USD
Availability: InStock

RUCKUS WIRELESS

PCN#

6768AE

MFG#

ICX7750-48C

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$19,215.63

Extended & Accidental Damage Protection Plans Available Details

2-Year $1,784.99

3-Year $2,341.99

Free Shipping

Estimated Shipment:

Product Highlights:

48 Ports
Manageable
10 Gigabit Ethernet, 40 Gigabit Ethernet
40GBase
X, 10GBase
T
3 Layer Supported
Modular
586 W Power Consumption
Twisted Pair, Optical Fiber
1U High
Rack
mountable
Lifetime Limited Warranty

Product Condition: New and Factory Fresh

Limited WarrantyLifetime

Shipping Weight: 21 lbs.

RUCKUS ICX 7750 Enterprise-Class Aggregation/Core Switch

Overview

Tech Specs

Industry-Leading 10/40 GbE Port Density

32 ports of 40 GbE or 96 ports of 10 GbE
2.56 Tbps switching capacity

Increased Reliability and Availability Through Redundancy

Load-sharing, hot-swappable power supplies
Ruckus MCT eliminates single point of failure

Advanced L3 Routing Delivers Network Design Flexibility

OSPF, VRRP, PIM, PBR, BGP, VRRP, VRF

Market-Leading Stacking Scalability

Up to 12 switches per stack
Up to 10 km using standard optics or cables

Campus Fabric Reduces Cost of Operations, Increases Flexibility

Delivers the benefits of a chassis with the flexibility of stackables
Scales to over 1800 ports

Energy Efficient Use of Power and Cooling Lowers Opex CostsThe Ruckus® ICX® 7750 switch delivers industry-leading 10/40 GbE port density, advanced high-availability capabilities, and flexible stacking architecture, making it the most robust Ruckus aggregation and core distributed chassis switch offering for enterprise LANs. In addition to rich Layer 3 features, the Ruckus ICX 7750 scales to 12-unit distributed-chassis stacking and serves as the Control Bridge for Ruckus Campus Fabric technologyPart of the Ruckus ICX family of switches for campus LAN and classic Ethernet data center environments, the Ruckus ICX 7750 switch is a 1U high-performance solution that meets the needs of business-sensitive campus deployments and classic data center environments. With a low latency, cut-through, non-blocking architecture, the Ruckus ICX 7750 provides a cost-effective, robust solution for the most demanding deployments. Deployed as a standalone switch, a stack, or a network fabric, organizations reap the benefits of a flexible platform and the assurance that their investments are protected.Product TypeEthernet SwitchTechnical InformationFeatures

In-Service Software Upgrade (ISSU)
Hot-swappable
Access Control List
Energy Efficient

High Availability SupportedYesInterfaces/PortsTotal Number of Network Ports48Uplink PortYesModularYesStack PortYesNetwork (RJ-45)YesPort/Expansion Slot Details

48 x 10 Gigabit Ethernet Network
6 x 40 Gigabit Ethernet Expansion Slot
1 x Expansion Slot

Media & PerformanceMedia Type Supported

Twisted Pair
Optical Fiber

Ethernet Technology

10 Gigabit Ethernet
40 Gigabit Ethernet

Network Technology

40GBase-X
10GBase-T

I/O ExpansionsTotal Number of Expansion Slots6Expansion Slot TypeQSFPNumber of SFP+ Slots6Network & CommunicationLayer Supported3Networking Standards

IEEE 802.1s
IEEE 802.1x
IEEE 802.1p

Management & ProtocolsManageableYesData Link Protocols

HTTP
HTTPS

ReliabilityMTBF259199 HourPower DescriptionInput Voltage

120 V AC
230 V AC

Frequency

50 Hz
60 Hz

Power Source

Power Supply
AC/DC

Redundant Power Supply SupportedYesNumber of Power Supplies Supported2Number of Power Supplies Installed2Power Consumption586 WPlug/Connector TypeC14Physical CharacteristicsCompatible Rack Unit1UForm FactorRack-mountableHeight1.7"Width17.3"Depth17"Weight (Approximate)22.42 lbMiscellaneousApplication/Usage

Network
Enterprise
Campus
Small Business
Server
Data Center
Infrastructure

Certifications & Standards

FCC Class A (Part 15); EN 55022/CISPR-22 Class A; VCCI Class A; ICES-003 Electromagnetic Emission; AS/NZS 55022; EN 61000-3-2 Power Line Harmonics; EN 61000-3-3 Voltage Fluctuation and Flicker; EN 61000-6-3 Emission Standard (supersedes
EN 50081-1)
CAN/CSA-C22.2 NO. 60950-1-07; UL 60950-1 Second Edition; IEC 60950-1 Second Edition; EN 60950-1
2006 Safety of Information Technology Equipment; EN 60825-1 Safety of Laser Products-Part 1
Equipment Classification, Requirements and User's Guide; EN 60825-2 Safety of Laser Products-Part 2
Safety of Optical Fibre Communication Systems
EN 61000-6-1 Generic Immunity and Susceptibility (supersedes EN 50082-1); EN 55024 Immunity Characteristics (supersedes EN 61000-4-2 ESD); EN 61000-4-3 Radiated, Radio Frequency, Electromagnetic Field; EN 61000-4-4 Electrical Fast Transient; EN 61000-4-5 Surge; EN 61000-4-6 Conducted Disturbances Induced by Radio-Frequency Fields; EN 61000-4-8 Power Frequency Magnetic Field; EN 61000-4-11 Voltage Dips and Sags
IEC 68-2-36, IEC 68-2-6
IEC 68-2-27, IEC 68-2-32

Environmental Compliance

Restriction of Hazardous Substances (RoHS) 6
Waste Electrical and Electronic Equipment Directive (WEEE)

WarrantyLimited WarrantyLifetime
