iConverter 1000Mbps Gigabit Ethernet Fiber to Single-Fiber Media Converter SC Multimode 550m to Single-Mode BiDi 20km Module

Name: iConverter 1000Mbps Gigabit Ethernet Fiber to Single-Fiber Media Converter SC Multimode 550m to Single-Mode BiDi 20km Module
Brand: OMNITRON SYSTEMS
SKU: D85450
Price: 1570.62 USD
Availability: InStock

OMNITRON SYSTEMS

PCN#

D85450

MFG#

8651-1

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$1,570.62

Extended & Accidental Damage Protection Plans Available Details

2-Year $145.99

3-Year $194.99

Free Shipping

Estimated Shipment:

Product Highlights:

1 x 1000BASE
SX; 1 x 1000BASE
BX
D (1550/1310); Internal Module; Lifetime Warranty

Product Condition: New and Factory Fresh

Limited WarrantyLifetime

Shipping Weight: 1 lbs.

iConverter 1000Mbps Gigabit Ethernet Fiber to Single-Fiber Media Converter SC Multimode 550m to Single-Mode BiDi 20km Module

Overview

Tech Specs

Specifications

Manufacturer	Omnitron Systems
Manufacturer Part Number	8651-1
Manufacturer Website Address	http://www.omnitron-systems.com
Brand Name	Omnitron Systems
Product Line	iConverter
Product Series	1000FF
Product Model	8651-1-x
Product Name	iConverter 1000FF SC Multimode 550m to SC Single-Mode Single-Fiber 15/13 20km Plug-In Module
Marketing Information	The iConverter 1000FF media converter provides fiber extension, as well as multimode to single-mode and dual fiber to single fiber conversion. The 1000FF is a cost-effective solution for extending fiber network distances. iConverter 1000FF models are available with multimode, single-mode and single-fiber options. The single-mode fiber port supports ST or SC connectors and distances up to 80km. The multimode fiber port supports ST or SC connectors and distances up to 550m. The 1000FF features user-selectable Link Propagate and Remote Fault Detection modes to facilitate quick fault detection, isolation and reporting. The iConverter 1000FF is available as a compact, unmanaged standalone unit, or as a chassis plug-in module that can be managed with a management module installed in the chassis. The hot-swappable plug-in module can be mounted in a high-density 19 or 5-Module chassis with any combination of redundant AC and DC power supplies. It can also be mounted in a 2-Module AC or DC powered chassis, or in a 1-Module chassis with AC or DC power input. The standalone 1000FF can be wall-mounted and is DC powered. It can be ordered with an external AC/DC power adapter, or it can be directly powered using a 2-pin terminal connector.
Package Type	Retail
Product Type	Transceiver/Media Converter

Interfaces/Ports

Total Number of Ports	2
Number of SC Ports	2
SC Port Type	Duplex Simplex

Media & Performance

Media Type Supported	Optical Fiber
Fiber Mode Supported	Multi-mode Single-mode
Fiber Optic Wavelength	850 nm 1550 nm
Maximum Distance Supported	12.43 Mile

Network & Communication

Ethernet Technology	Gigabit Ethernet
Network Technology	1000Base-SX 1000Base-BX 1000Base-BX-D

Physical Characteristics

Form Factor	Rack-mountable Desktop Internal Wall Mountable
Height	2.8"
Width	0.9"
Depth	4.5"
Weight (Approximate)	8 oz

Miscellaneous

Package Contents	iConverter 1000FF SC Multimode 550m to SC Single-Mode Single-Fiber 15/13 20km Plug-In Module User Manual
Compatibility	iConverter 19-Module Chassis iConverter 5-Module Chassis iConverter 2-Module Chassis iConverter 1-Module Chassis
Certifications & Standards	Compliance: UL CE FCC Class A IEEE 802.3z 1000BASE-X
Environmentally Friendly	Yes
Country of Origin	United States

Warranty

Limited Warranty

Lifetime
