FlexPoint 1000Mbps Gigabit Ethernet Fiber to Fiber Media Converter SC Multimode 550m to Single-Mode 34km

Name: FlexPoint 1000Mbps Gigabit Ethernet Fiber to Fiber Media Converter SC Multimode 550m to Single-Mode 34km
Brand: OMNITRON SYSTEMS
SKU: DY2732
Price: 414.46 USD
Availability: InStock

OMNITRON SYSTEMS

PCN#

DY2732

MFG#

4440-2

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$414.46

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

1 x 1000BASE
SX;1 x 1000BASE
LX;Univ. AC Powered;Lifetime Warranty

Product Condition: New and Factory Fresh

Limited WarrantyLifetime

Shipping Weight: 2 lbs.

FlexPoint 1000Mbps Gigabit Ethernet Fiber to Fiber Media Converter SC Multimode 550m to Single-Mode 34km

Overview

Tech Specs

Specifications

Manufacturer	Omnitron Systems
Manufacturer Part Number	4440-2
Manufacturer Website Address	http://www.omnitron-systems.com
Brand Name	Omnitron Systems
Product Line	FlexPoint
Product Series	1000FF
Product Model	4440-x
Product Name	FlexPoint 1000FF SC Multimode 550m to SC Single-Mode 34km Univ. AC Powered
Marketing Information	The FlexPoint 1000FF is a protocol-transparent fiber converter that provides reliable and cost-effective extension of network distances by connecting multimode fiber networks or devices over single-mode fiber cabling. The FlexPoint 1000FF is designed to operate with a constant rate signal between 500Mbps to 1250Mbps allowing the converter to be used in Ethernet networks as well as other fiber-to-fiber protocol applications. No manual configuration is required with the plug-and-play FlexPoint 1000FF. Connect the fiber cables to the appropriate interface and the installation is complete. The FlexPoint 1000FF features descriptions of the LED indicators on the label for easy in-the-field installation and maintenance. The LEDs report the availability of power and the detection of devices attached to the fiber ports. FlexPoint modules can be mounted utilizing optional wall-mounting hardware or with DIN-rail mounting brackets. They can also be rack-mounted in a 5-Module shelf or in a high-density 14-Module, power-redundant Powered Chassis.
Package Type	Retail
Product Type	Transceiver/Media Converter

Interfaces/Ports

Total Number of Ports	2
Number of SC Ports	2
SC Port Type	Duplex

Media & Performance

Media Type Supported	Optical Fiber
Fiber Mode Supported	Multi-mode Single-mode
Fiber Optic Wavelength	850 nm 1310 nm
Maximum Distance Supported	34.01 km
Fiber Optic Cable Core/Cladding Specification	100/140 µm 62.5/125 µm 50/125 µm 9/125 µm

Network & Communication

Ethernet Technology	Gigabit Ethernet
Network Technology	1000Base-SX 1000Base-LX

Power Description

Input Voltage

240 V AC

Physical Characteristics

Form Factor	Rack-mountable Desktop External Wall Mountable
Height	1"
Width	3"
Depth	4"
Weight (Approximate)	6 oz

Miscellaneous

Package Contents	FlexPoint 1000FF SC Multimode 550m to SC Single-Mode 34km Univ. AC Powered Univ. Power Supply - 100-240Volt / 50-60Hz User Manual
Additional Information	Input Voltage: 6-15VDC via 2.5mm barrel (0.2A @ 9VDC) 5VDC via Molex connector (0.5A @ 5VDC) 100-240 VAC/50-60 Hz (0.04A @ 120VAC)
Certifications & Standards	Compliance: UL CE FCC Class A IEEE 802.3z 1000BASE-X
Environmentally Friendly	Yes
Country of Origin	United States

Warranty

Limited Warranty

Lifetime
