1X4 2XHDI MULTI-VIEWER SWITCH

Name: 1X4 2XHDI MULTI-VIEWER SWITCH
Brand: MARSHALL ELECTRONICS
SKU: JV6298
Price: 1127.71 USD
Availability: InStock

MARSHALL ELECTRONICS

PCN#

JV6298

MFG#

VMV-402-3GSH

$1,127.71

Extended & Accidental Damage Protection Plans Available Details

3-Year $143.99

2-Year $107.99

Free Shipping

Estimated Shipment:

Product Highlights:

Product Condition: New and Factory Fresh

Shipping Weight: 1 lbs.

Marshall Seamless 4x Switch with Quadview Mode & Ethernet Control

Tech Specs

Specifications

Manufacturer	Marshall Electronics, Inc
Manufacturer Part Number	VMV-402-3GSH
Manufacturer Website Address	http://www.mars-cam.com
Brand Name	Marshall
Product Name	Seamless 4x Switch with Quadview Mode & Ethernet Control
Marketing Information	The Marshall VMV-402-3GSH is ideal for presentation systems, control rooms, and remote productions by providing seamless switching between four selectable inputs. Inputs can be a combination of mixed formats and frame rates. Simultaneous output is provided via 3G SDI and HDMI. The SDI output supports up to 1080p while the HDMI output may be scaled up to UHD. The Robust design makes the 402 at home on any rack mount or "throw-down box" application. The internal scaler accepts a wide range of input formats and frame rates and conforms them to the selected output format/frame rate. 4x 3GSDI inputs, inputs 1 & 2 support HDMI as well Full-time Quadview via HDMI UP and DOWN resolution/frame rate scaling Waveform and Vector scope overlay selectable All system setups via front panel or Ethernet browser. No separate app required. Input selection, quad labels via Ethernet or RS232
Product Type	Audio/Video Switchbox

Technical Information

Connectivity Technology	Cable
Device Supported	Display
Number of Displays Supported	4

Video

Maximum Video Resolution	3840 x 2160
Scan Format	1080p

Interfaces/Ports

HDMI In	Yes
HDMI Out	Yes
Connectivity (RJ-45)	Yes
Number of Connectivity (RJ-45) Ports	1
Number of HDMI Inputs	3
Number of HDMI Outputs	1
Number of SDI Inputs	4
Number of SDI Outputs	1

Media & Performance

Maximum Operating Distance

328.08 ft

Physical Characteristics

Miscellaneous

Application/Usage
