LSCB DVLED P1.56 384X216 SINGLE SMD 800 NIT

Name: LSCB DVLED P1.56 384X216 SINGLE SMD 800 NIT
Brand: LG
SKU: NT5654
Price: 2600 USD
Availability: InStock

PCN#

NT5654

MFG#

LSCB015-RKC

$2,600.00

Extended & Accidental Damage Protection Plans Available Details

2-Year $197.99

3-Year $263.99

Free Shipping

Estimated Shipment:

Product Highlights:

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 18 lbs.

LG LSCB015-RKC Digital Signage Display

Tech Specs

Specifications

Manufacturer	LG Electronics
Manufacturer Part Number	LSCB015-RKC
Manufacturer Website Address	https://solutions.lg.com/us
Brand Name	LG
Product Model	LSCB015-RKC
Product Name	LSCB015-RKC Digital Signage Display
Product Type	Digital Signage Display

Technical Information

Features	90° Corner Design Flame Resistant
Heat Dissipation	149.99 W
Average Heat Dissipation Per Cabinet	50 W
Ingress Protection (IP) Rating	IP30
Minimum Color Temperature	5300.3°F (2926.8°C)
Maximum Color Temperature	16280.3°F (9026.8°C)
Color Uniformity	±0.003 Cx, Cy
Service Access	Front

Display & Graphics

Display Resolution	384 x 216
High Dynamic Range (HDR)	Yes
High Dynamic Range (HDR) Type	HDR10 HDR10 Pro
Pixel Pitch	61.4 mil
Horizontal Viewing Angle	160°
Vertical Viewing Angle	160°
Cabinet Surface Area	2 Sq. ft.
Number of Modules Per Cabinet	2x2
Module Resolution	192 x 108
Maximum LED Life	11.4 Year
LED Type	Single SMD
Physical Pixel Density	409600 pixels/m²

Video

Power Description

Input Voltage

Environmental Conditions

Minimum Operating Temperature	14°F (-10°C)
Maximum Operating Temperature	113°F (45°C)
Minimum Operating Humidity	0%
Maximum Operating Humidity	80%

Physical Characteristics

Height	13.3"
Width	23.6"
Depth	1.3"
Module Height	6.60"
Module Width	11.80"
Weight per Module (Approximate)	12 oz
Weight per Cabinet (Approximate)	11.70 lb
Housing Material	Die-cast Aluminum
Weight per Square Meter (Approximate)	26200 g/m²

Miscellaneous

Additional Information	Brightness Uniformity : 97% Power Consumption per Cabinet (Max) : 150W Power Consumption per Cabinet (Avg.) : 50W Total Modules (per cabinet) : 4 Heat Dissipation per Unit Area (Max.) : 2,527.5 BTU/hr/m² Power Consumption per Unit Area (Max) : 740 W/m² Controller : CVCA Minimum Viewing Distance (5-7 mm per foot) : 8-11 feet
Certifications & Standards	CE FCC: EMC Class B cTUVus : No ETL (Regulatory): Yes
Environmentally Friendly	Yes
Environmental Certification	REACH
Environmental Compliance	Restriction of Hazardous Substances (RoHS) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
TAA Compliant	No

Warranty

Limited Warranty

3 Year
