LG GSCA046-GN Digital Signage Display

Name: LG GSCA046-GN Digital Signage Display
Brand: LG
SKU: NT5521
Price: 2793 USD
Availability: InStock

PCN#

NT5521

MFG#

GSCA046-GN

$2,793.00

Extended & Accidental Damage Protection Plans Available Details

2-Year $197.99

3-Year $263.99

Free Shipping

Estimated Shipment:

Product Highlights:

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 34 lbs.

LG GSCA046-GN Digital Signage Display

Tech Specs

Specifications

Manufacturer	LG Electronics
Manufacturer Part Number	GSCA046-GN
Manufacturer Website Address	https://solutions.lg.com/us
Brand Name	LG
Product Model	GSCA046-GN
Product Name	GSCA046-GN Digital Signage Display
Marketing Information	Fast Installation Various factors including magnets on the top and bottom, positioning pins, handles and fast locks help installers easily set up and dismantle the LED screens without additional tools. Easy Maintenance The GSCA series applied a simple Lock Fixing method which requires no additional tools, making it easier to replace LED modules or power/data units. It saves cost and time for maintenance. Two Cabinet Options The GSCA series offers two sizes of cabinets enabling a screen size configuration that fits perfectly with customer's demands. IP Rated Weatherproof & 90° Corner Design The cabinet is IP65 certified, allowing stable operation unaffected by weather and harsh outdoor environments. Also, if you add a 90° corner option, the GSCA series can deliver flawless content even when installed on the corners. Front or Rear Serviceability The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimises limitations in installation and maintenance.
Product Type	Digital Signage Display

Technical Information

Heat Dissipation	299.99 W
Average Heat Dissipation Per Cabinet	100 W
Ingress Protection (IP) Rating	IP65
Minimum Color Temperature	5300.3°F (2926.8°C)
Maximum Color Temperature	16280.3°F (9026.8°C)
Color Uniformity	±0.003 Cx, Cy
Service Access	Front Rear

Display & Graphics

Display Resolution	108 x 216
High Dynamic Range (HDR)	Yes
High Dynamic Range (HDR) Type	HDR10 HDR10 Pro
Pixel Pitch	0.18"
Horizontal Viewing Angle	160°
Vertical Viewing Angle	135°
Cabinet Surface Area	5 Sq. ft.
Number of Modules Per Cabinet	2x2
Module Resolution	54 x 108
Maximum LED Life	11.4 Year
LED Type	Single SMD
Physical Pixel Density	46656 pixels/m²

Video

Power Description

Input Voltage

Environmental Conditions

Minimum Operating Temperature	-22°F (-30°C)
Maximum Operating Temperature	122°F (50°C)
Minimum Operating Humidity	10%
Maximum Operating Humidity	99%

Physical Characteristics

Height	39.4"
Width	19.7"
Depth	2.6"
Module Height	19.70"
Module Width	9.80"
Weight per Module (Approximate)	3.10 lb
Weight per Cabinet (Approximate)	28 lb
Housing Material	Die-cast Magnesium
Weight per Square Meter (Approximate)	25400 g/m²

Miscellaneous

Additional Information	Brightness Uniformity : 97% Power Consumption per Cabinet (Max) : 300W Power Consumption per Cabinet (Avg.) : 100W 90 Degree Corner Cut : No Total Modules (per cabinet) : 4 Heat Dissipation per Unit Area (Max.) : 2,047.2 BTU/hr/m² Power Consumption per Unit Area (Max) : 600 W/m² Controller : CVCA Minimum Viewing Distance (5-7 mm per foot) : 23-32 feet
Certifications & Standards	CE FCC cTUVus : No ETL (Regulatory): Yes
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
TAA Compliant	No

Warranty

Limited Warranty

3 Year
