55IN IPS 4K SURGICAL DISPLAY 3480X2160 HDMI DP DVI 12G-SDI

by
LG
PCN#
HJ5448
MFG#
55MH5K-W
$11,213.02
cps

Extended & Accidental Damage Protection Plans Available Details

Estimated Shipment:

Calculating Shipping

Product Highlights:
  • 55" Viewable
  • In
  • plane Switching (IPS) Technology

Show more

Product Condition: New and Factory Fresh
Shipping Weight: 94 lbs.
LG 55MH5K-W 55" Class 4K UHD LED Monitor - 16:9 - White
Tech Specs
Specifications

Manufacturer

LG Electronics

Manufacturer Part Number

55MH5K-W

Manufacturer Website Address

http://www.lg.com/us

Brand Name

LG

Product Model

55MH5K-W

Product Name

55'' 4K IPS Surgical Monitor

Marketing Information

4K Surgical Display | 4K Large Display for Surgery

Experience vivid images on LG's 55-inch 4K Display Surgical Monitor, equipped with an IPS panel that offers a wide 178° viewing angle.

HDR10

This 4K surgical monitor features HDR10, properly displaying HDR images clearly.

PBP, PIP & 12G-SDI Support | Multiple Signals on One Screen

55MH5K supports up to 4PBP, PIP and extended ports, allowing you to view multiple signals simultaneously on a single screen.

12G-SDI Support

The 55MH5K features a 55-inch 4K (3840x2160) IPS display with 12G-SDI Support, which enables long-distance transmission of 4K signals over a single coaxial cable without latency for stable surgery.

Failover Input Switch

When the main source is missing, the display will automatically switch to a failover (backup) source and restore the main source once the signal is back. You can set the main input and failover input in the setting menu of monitor.

Mirror & Rotation Mode

Conveniently flip and rotate the monitor to adjust to your surgery needs. Mirror & Rotation Modes allow you to select a convenient 180° rotated/mirror image.

IP 45& IP 32

With ratings of IP 45* on the front and IP 32* on the body except for front, this surgical monitor is protected against contact with solid objects and water.

Product Type

LED Monitor
Technical Information

Number of Screens

1

Screen Size Class

55"

Viewable Screen Size

55"

Screen Mode

4K UHD

Panel Technology

In-plane Switching (IPS) Technology

Response Time

5 ms

Response Time Details

5ms GTG (Fast)

Aspect Ratio

16:9

Pixel Pitch

12.4 mil

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Mount Type

Wall Mountable

Backlight Technology

Edge LED

HDCP Supported

Yes

Features

  • Mega Contrast
  • Anti-reflective
  • Black Stabilizer Technology
  • HDR10
  • Hardware Calibration
  • On-screen Display (OSD)
  • Picture by Picture
  • Picture in Picture
  • Smart Energy Saving
  • Super Resolution+
  • Power Switch
  • Wide Viewing Angle

Vertical Frequency

  • 56 Hz to 61 Hz - DisplayPort
  • 56 Hz to 61 Hz - DVI
  • 56 Hz to 61 Hz - HDMI

Ingress Protection (IP) Rating

  • IP45
  • IP32

Impact Protection (IK) Rating

IK06
Video

Maximum Resolution

3840 x 2160

Color Supported

1.07 Billion Colors

Native Contrast Ratio

1,100:1

Brightness

680 Nit

Color Gamut

86% DCI-P3 (CIE 1976)
Interfaces/Ports

HDMI

Yes

HDMI Version

2.0

USB

Yes

DisplayPort

Yes

Total Number of HDMI Ports

1

Number of USB Ports

2

Number of USB 3.0 Upstream Ports

1

Number of USB 3.0 Downstream Ports

1

Number of DisplayPorts

2

Number of DVI Ports

2

DVI-D

Yes

Number of HDMI 2.0 Ports

1
Power Description

Frequency

  • 50 Hz
  • 60 Hz
Physical Characteristics

VESA Mount Compatible

Yes

VESA Mount Standard

300 x 300

Color Family

White

Color

White

Height

30.3"

Width

50.5"

Depth

2.7"

Weight (Approximate)

76.72 lb
