Kingston Server Premier 16GB DDR4 SDRAM Memory Module

Name: Kingston Server Premier 16GB DDR4 SDRAM Memory Module
Brand: KINGSTON
SKU: 9VU129
Price: 174.53 USD
Availability: OutOfStock

KINGSTON

PCN#

9VU129

MFG#

KSM32SES8/16HC

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Estimated Shipment:

Product Highlights:

For Server
16 GB (1 x 16GB)
DDR4
3200/PC4
25600 DDR4 SDRAM
3200 MHz Single
rank Memory
CL22
1.20 V
ECC
Unbuffered
260
pin
SODIMM
Lifetime Warranty

Product Condition: New and Factory Fresh

Limited WarrantyLifetime

Shipping Weight: 1 lbs.

Kingston 16GB 1Rx8 2G x 72-Bit PC4-3200 CL22 260-Pin ECC SODIMM

Overview

Tech Specs

Specifications

Manufacturer	Kingston Technology Company
Manufacturer Part Number	KSM32SES8/16HC
Manufacturer Website Address	http://www.kingston.com
Brand Name	Kingston
Product Line	Server Premier
Product Name	16GB 1Rx8 2G x 72-Bit PC4-3200 CL22 260-Pin ECC SODIMM
Marketing Information	FEATURESKingston's KSM32SES8/16HC is a 2G x 72-bit (16GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM) w/ parity, 1Rx8, ECC, memory module, based on nine 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 260-pin SODIMM uses gold contact fingers. The electrical and mechanical specifications are as follows: FEATURES Power Supply: VDD = 1.2V VDDQ = 1.2V VPP = 2.5V VDDSPD = 2.20V to 3.60V Functionality and operations comply with the DDR4 SDRAM datasheet 16 internal banks Bank Grouping is applied, and CAS to CAS latency (tCCD_L, tCCD_S) for the banks in the same or different bank group accesses are available Data transfer rates: PC4-3200, PC4-2933, PC4-2666, PC4-2400, PC4-2133, PC4-1866, PC4-1600 Bi-Directional Differential Data Strobe 8 bit pre-fetch Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop) Supports ECC error correction and detection On-Die Termination (ODT) Temperature sensor with integrated SPD This product is in compliance with the RoHS directive. Per DRAM Addressability is supported Internal Vref DQ level generation is available Write CRC is supported at all speed grades CA parity (Command/Address Parity) mode is supported RoHS Compliant and Halogen-Free
Product Type	RAM Module

Technical Information

Memory Size	16 GB
Memory Technology	DDR4 SDRAM
Memory Voltage	1.20 V
Number of Modules	1 x 16GB
Memory Speed	3200 MHz
Memory Standard	DDR4-3200/PC4-25600
Memory Rank	Single-rank
Error Checking	ECC
Signal Processing	Unbuffered
CAS Latency	CL22
Device Supported	Server

Physical Characteristics

Number of Pins	260-pin
Form Factor	SODIMM
Thickness	145.7 mil
Width	1.2"
Length	2.7"

Miscellaneous

Country of Origin	Taiwan
Environmentally Friendly	Yes
Environmental Certification	Hazard Assessment of Perfluorooctane Sulfonate (PFOS)
Environmental Compliance	Restriction of Hazardous Substances (RoHS) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Waste Electrical and Electronic Equipment Directive (WEEE)

Warranty

Limited Warranty

Lifetime
