64 CH NVR 88TB

Name: 64 CH NVR 88TB
Brand: HANWHA TECHWIN AMERICA
SKU: JQ8209
Price: 13428.14 USD
Availability: OutOfStock

HANWHA TECHWIN AMERICA

PCN#

JQ8209

MFG#

XRN-6420DB4-88TB

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Estimated Shipment:

Product Highlights:

Network Video Recorder
HDMI
8K Recording

Product Condition: New and Factory Fresh

Limited Warranty5 Year

Shipping Weight: 61 lbs.

Hanwha Techwin XRN-6420DB4 64CH NVR With 12th Gen. Intel Processor - 88 TB HDD

Overview

Tech Specs

Specifications

Manufacturer	Hanwha Group
Manufacturer Part Number	XRN-6420DB4-88TB
Manufacturer Website Address	http://www.hanwha.com
Brand Name	Hanwha Techwin
Product Model	XRN-6420DB4
Product Name	XRN-6420DB4 64CH NVR With 12th Gen. Intel Processor
Marketing Information	8K NVR (Intel based), 64Ch, No HDD, 16 SATA HDD bays (up to 10TB per HDD), H.265/H.264/MJPEG, SUNAPI, ONVIF, ARB (Automatic Recovery Backup) & Failover (N+1), Up To 520 Mbps Recording / Up To 200 Mbps Playback, Dual Stream Recording, iSCSI, WiseStream Support, HDMI(x2) Dual Display, Alarm I/O, 2-Way Audio, Maximum Camera Resolution of 32MP Recording/Display, Fisheye Dewarping (Local/CMS), AI Search (Wisenet AI Cameras Only), P2P QR Code, Support for RAID 5/6 (NOTE: Requires a minimum number of HDDs per RAID type), HDD Hot Swap is available in RAID Mode, Redundant Power Supply.
Product Type	Video Surveillance Station

Technical Information

Total Number of Channels	64
Connectivity Technology	Wired
Recording Formats	8K
HD Recording	Yes
System Components	Network Video Recorder
Features	Alarm Configuration Fisheye Dewarping PTZ Control Dual Stream Recording

Storage

Hard Drive Capacity

88 TB

Video

Video Formats	H.265 H.264 Motion JPEG
Maximum Resolution	32MP
Maximum Frame Rate	30 fps

Camera

AI-powered

Yes

Network & Communication

Ethernet	Yes
Remote Management	Yes

Interfaces/Ports

USB	Yes
USB Standard	USB 2.0/3.0
Number of USB Ports	4
Total Number of Audio Out Ports	1
HDMI	Yes

Software

Operating System Supported

Windows 10 or Higher
macOS 13.5.2 or Higher
Linux

Power Description

Power Consumption	265 W
Power Source	AC Supply

Physical Characteristics

Height	5.2"
Width	17.3"
Depth	22.5"
NVR Weight	33.29 lb

Environmental Conditions

Minimum Operating Temperature	32°F (0°C)
Maximum Operating Temperature	104°F (40°C)

Miscellaneous

Package Contents

XRN-6420DB4 64CH NVR With 12th Gen. Intel Processor
Mouse
Keyboard
Web, Controller

Warranty

Limited Warranty

5 Year
