Hanwha XNV-8083RX 6 Megapixel Indoor/Outdoor Network Camera - Color - Dome - Black

Name: Hanwha XNV-8083RX 6 Megapixel Indoor/Outdoor Network Camera - Color - Dome - Black
Brand: HANWHA TECHWIN AMERICA
SKU: 10NG55
Price: 909.86 USD
Availability: InStock

HANWHA TECHWIN AMERICA

PCN#

10NG55

MFG#

XNV-8083RX

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$909.86

Extended & Accidental Damage Protection Plans Available Details

2-Year $89.99

3-Year $120.99

Free Shipping

Estimated Shipment:

Product Highlights:

164.04 ft Infrared Night Vision
H.264, H.265, H.264M, H.265M, H.265H, H.264H, MJPEG
3328 x 1872
4.40 mm
9.30 mm Varifocal Lens
2.1x Optical
30 fps
CMOS
Gigabit Ethernet
USB
IK10+
IP66, IP67, IP6K9K

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 3 lbs.

Hanwha XNV-8083RX 6 Megapixel Indoor/Outdoor Network Camera - Color - Dome - Black

Overview

Tech Specs

Specifications

Manufacturer	Hanwha Group
Manufacturer Part Number	XNV8083RX
Manufacturer Website Address	http://www.hanwha.com
Brand Name	Hanwha
Product Series	X
Product Model	XNV-8083RX
Product Name	6MP IR Outdoor Vandal Dome AI Camera Module
Product Type	Network Camera

Technical Information

HD Recording	Yes
Night Vision	Yes
Night Vision Distance	164.04 ft
Night Vision Type	Infrared

Display & Graphics

Image Sensor Type	CMOS
Image Sensor Size	1/1.8"
Color Supported	Color
Field of View	H: 113°(Wide)~47°(Tele) V: 58°(Wide)~26°(Tele) D: 138°(Wide)~54°(Tele)
Effective Camera Resolution	6 Megapixel

Video

Video Formats	H.264 H.265 H.264M H.265M H.265H H.264H MJPEG
Maximum Video Resolution	3328 x 1872
Maximum Frame Rate	30 fps
Analog Video Signal Format	CVBS

Lens

Lens Type	Varifocal
Minimum Focal Length	4.40 mm
Maximum Focal Length	9.30 mm
Lens Included	Yes
Minimum Aperture	f/2.15
Maximum Aperture	f/1.3
Optical Zoom	2.1x

Exposure

Shortest Shutter Speed	1/12000 Second
Longest Shutter Speed	2 Second

Network & Communication

Connectivity Technology	Wired
Ethernet Technology	Gigabit Ethernet
Protocols	IPv4 IPv6 TCP/IP UDP/IP RTP UDP TCP RTCP RTSP NTP HTTP HTTPS SSL/TLS DHCP FTP SMTP ICMP IGMP SNMPv1/v2c/v3 (MIB2) ARP DNS DDNS QoS UPnP Bonjour LLDP SRTP
Remote Management	Yes

Storage

Storage Type

Memory Card

Interfaces/Ports

USB	Yes
Network (RJ-45)	Yes

Power Description

Input Voltage	12 V DC
Power Source Type	PoE+ DC

Physical Characteristics

Form Factor	Dome
Color Family	Black
Product Color	Black
Diameter	5.4"
Weight (Approximate)	1.65 lb

Environmental Conditions

Minimum Operating Temperature	-58°F (-50°C)
Maximum Operating Temperature	131°F (55°C)
Maximum Operating Humidity	95%

Miscellaneous

Features	Back Light Compensation (BLC) Highlight Compensation (HLC) Wide Dynamic Range PTZ White Balance Gain Control Privacy Masking Motion Detection Defog Digital Image Stabilization Digital Noise Reduction Day/Night
Indoor/Outdoor	Indoor/Outdoor
Impact Protection Rating	IK10+
Ingress Protection Rating	IP66 IP67 IP6K9K

Warranty

Limited Warranty

3 Year
