LAYER 2 UNMANAGED POE SWITCH 5 X GIGE (4 X POE) METAL CASE

Unmanaged Network Switches

The GWN7700 series are unmanaged network switches that provide a quick and cost-effective way to add high-speed Gigabit connectivity to home offices and small/medium businesses. It requires no configuration or installation, offers a desktop and wall-mountable design, and provides auto MDI/MDIX to eliminate the need for crossover cables. Each port supports auto-negotiation to allow the GWN7700 series to recognize the link speed of any 10/100/1000Mbps network device and intelligently adjust for compatibility and optimal performance. The PoE (Power-over-Ethernet) models provide ports with IEEE 802.3af/at compliant, smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points and other PoE endpoints. The plug-and-play GWN7700 series are the ideal unmanaged network switches for home offices and small-to medium businesses.

5/8/16/24/48 Gigabit RJ45 ports, 4 port PoE+ output (GWN7700P & GWN7701P), 8 port PoE+ output (GWN7701PA & GWN7702P)

Green technology reduces power consumption

LED Indicators; Per port: Link/Activity Per device: Power

Auto MDI/MDIX crossover for all ports

802.3 af/at compliant Up to 30W on each port, (GWN7700P/GWN7701P/ GWN7701PA/GWN7702P only)

Broadcast/Multicast/ Unicast Storm Control (fixed to 100Mbps) to monitor traffic levels

Supports long cable connection

QoS - Supports Default Strict Priority when present

• Plug and Play
• Broadcast Storm Control
• Multicast Storm Control
• Unicast Storm Control

• IEEE 802.3i
• IEEE 802.3u
• IEEE 802.3ab
• IEEE 802.3x
• IEEE 802.1p

• Desktop
• Wall Mountable

• GWN7700 Ethernet Switch
• 1 x Power Adapter
• 1 x QIG

• Home Office
• Business
• IP Phone
• IP Camera
• Wireless Access Point
• Network
• Small Business
• Medium Business

• FCC
• CE
• RCM
• IC
• UKCA
