Gefen 4K Ultra HD HDBaseT Receiver w/ Audio De-Embedder and POH

Name: Gefen 4K Ultra HD HDBaseT Receiver w/ Audio De-Embedder and POH
Brand: GEFEN INC
SKU: 3281AN
Price: 266.68 USD
Availability: InStock

GEFEN INC

PCN#

3281AN

MFG#

EXT-UHDA-HBTL-RX

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$266.68

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

1 Output Device
230 ft Range
1 x Network (RJ
45)
1 x HDMI Out
4K
3840 x 2160
Twisted Pair
Category 5

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 2 lbs.

Gefen 4K Ultra HD HDBaseT Receiver w/ Audio De-Embedder and POH

Overview

Tech Specs

Specifications

Manufacturer	Gefen, Inc
Manufacturer Part Number	EXT-UHDA-HBTL-RX
Manufacturer Website Address	http://www.gefen.com
Brand Name	Gefen
Product Model	EXT-UHDA-HBTL-RX
Product Name	4K Ultra HD HDBaseT Receiver w/ Audio De-Embedder and POH
Marketing Information	Extend HDMI with audio breakout up to 70 meters/230 feet, over a single CAT-5 The Gefen EXT-UHDA-HBTL-RX is a high-performance HDBaseT™ Receiver that can extend HDMI up to 70 meters (230 feet) at 1080p and 40 meters (130 feet) at 4K, over a single CAT-5e cable. It also de-embeds analog L/R, TOSLINK® optical digital, and coaxial digital audio from the video for use with a separate audio system, enhancing the impact of presentations. This Receiver uses Gefen's implementation of the HDBaseT™ technology with enhanced functionality. It accommodates 10.2 Gbps of data throughput and 300 MHz TMDS Clock frequency, and supports HDMI 2.0 resolutions up to 4K Cinema-DCI (4096 x 2160 to 30 Hz 4:4:4) and 4K Ultra HD (3860 x 2160 to 60 Hz, 4:2:0, or 30 Hz 4:4:4), with HDCP 2.2 or 1.4. Highest performance multichannel digital audio including 7.1 channels of LPCM and HBR (High Bit Rate) digital audio formats, such as Dolby Atmos®, Dolby® TrueHD, DTS:X™, and DTS-HD Master Audio™ are passed through to the HDMI output. The EXT-UHDA-HBTL-RX also extends RS-232 and 2-way IR when used with a compatible Sender unit, facilitating the control of A/V sources placed near the Sender from the viewing location, and sending commands from the head end to control the display or another device placed near the Receiver unit. It can also send RS-232 commands from a third-party controller placed by the Receiver, for switching, scaler controls, and EDID management of a compatible Sender unit. Bi-Directional HDBaseT™ standard POH (Power Over HDBaseT™) technology can supply power remotely from the Receiver unit to a compatible Sender unit, or it can pass power from a compatible Sender unit to the Receiver, using the same CAT-5 cable that extends the HDMI signal. Only one of the two units will need a power supply. This feature simplifies installation in cases when an electrical outlet may not be available near the source or the display. The Receiver's small, ultra-low-profile enclosure can be securely surface-mounted and conveniently hidden away from sight behind the display. It also accommodates a Gefen locking power supply plug for secure connection.
Product Type	Video Extender Receiver

Technical Information

Connectivity Technology	Wired
Number of Output Devices Supported	1
Maximum Operating Distance	230 ft

Video

Graphics Modes	4K
Maximum Video Resolution	3840 x 2160

Interfaces/Ports

Network (RJ-45)	Yes
HDMI Out	Yes
Serial Port	Yes
Number of Network (RJ-45) Ports	1
Number of HDMI Outputs	1

Media & Performance

Media Type Supported	Twisted Pair
Twisted Pair Cable Standard	Category 5

Physical Characteristics

Receiver Height	0.65"
Receiver Width	6"
Receiver Depth	4"
Receiver Weight (Approximate)	9.60 oz

Miscellaneous

Package Contents

4K Ultra HD HDBaseT Receiver w/ Audio De-Embedder and POH
1 x 12V 3A Power Supply (EXT-PS12U3IP-LP21-6)
1 x 3-pin Phoenix Plug
2 x Mounting Brackets
1 x Quick Start Guide

Warranty

Limited Warranty

3 Year
