Gefen DVI KVM over IP w/ Local DVI Output - Sender Unit Package

Name: Gefen DVI KVM over IP w/ Local DVI Output - Sender Unit Package
Brand: GEFEN INC
SKU: 3211AN
Price: 331.52 USD
Availability: InStock

GEFEN INC

PCN#

3211AN

MFG#

EXT-DVIKVM-LAN-LTX

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$331.52

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

1 Computer(s)
1 x Network (RJ
45)
1 x USB
2 x DVI
5 V DC Input Voltage
Rack
mountable, Surface
mountable
1U

Product Condition: New and Factory Fresh

Shipping Weight: 5 lbs.

Gefen DVI KVM over IP w/ Local DVI Output - Sender Unit Package

Overview

Tech Specs

Specifications

Manufacturer	Gefen, Inc
Manufacturer Part Number	EXT-DVIKVM-LAN-LTX
Manufacturer Website Address	http://www.gefen.com
Brand Name	Gefen
Product Name	DVI KVM over IP w/ Local DVI Output - Sender Unit Package
Marketing Information	Video over IP solution for extending DVI, USB, RS-232, and audio The DVI KVM over IP extends DVI, USB, analog audio, and RS-232, over a Gigabit Local Area Network. Resolutions up to 1920 x 1200 (WUXGA) and 1080p Full HD are supported. HDMI digital audio is also supported when using HDMI sources and displays with HDMI to DVI adapters. Local monitoring of video is made possible by the DVI Local Output connector on the Sender unit. The Sender and Receiver units can be automatically or manually configured to unique IP addresses to allow the connection of multiple Senders and Receivers to the same network. Multiple Receiver units can simultaneously connect to any Sender unit within the network including the Gefen KVM over LAN products with HDMI, DVI, or VGA video, to create a virtual crosspoint matrix of just over 65,000 Sender and Receiver units total, depending on the network bandwidth and number of ports on the network switch (see Note). Each Receiver unit has a built in Ethernet switch and two additional RJ-45 Ethernet ports to allow for the connection of computers and other IP-enabled devices. Each Receiver unit allows the connection of four USB devices with up to 500mA current draw per port, providing access to keyboard, mouse, and other compatible devices. USB 2.0 data rates up to 480 Mbps are supported in addition to backward-compatibility with USB 1.1. Two Channel analog audio can be extended from each Sender to the Receiver units for use with headphones or powered speakers. RS-232 serial control can also be extended between each Sender and the Receivers. Built in web server interface makes set up and configuration simple and intuitive. Any combination of Gefen Video over IP HDMI, DVI, and VGA Senders and Receivers can be used together to create a" Virtual Matrix" , where each Sender can be accessed by multiple Receivers. The DVI KVM over IP is perfect for large scale remote workstation access and for digital signage applications.
Packaged Quantity	1
Product Type	KVM Extender

Technical Information

Connectivity Technology	Wired
Number of Computers Supported	1

Interfaces/Ports

Network (RJ-45)	Yes
USB	Yes
DVI	Yes
Number of Network (RJ-45) Ports	1
Number of USB Ports	1
Number of DVI Ports	2

Power Description

Input Voltage

5 V DC

Physical Characteristics

Rack Height	1U
Form Factor	Rack-mountable Surface-mountable
Transmitter Height	1.70"
Transmitter Width	8.40"
Transmitter Depth	4.50"

Miscellaneous

Package Contents

DVI KVM over IP w/ Local DVI Output - Sender Unit (EXT-DVIKVM-LAN-LS)
1 x 6 ft. DVI cable (M-M) (CAB-DVIC-DLN-06MM)
1 x 6 ft. USB Cable (CAB-USB-6)
1 x 6 ft. DB-9 cable (CAB-DB9-6MF)
1 x L-shaped Mounting Bracket with screws (EXT-MP-C01)
1 x 5V DC Power Supply (EXT-PS526AIP-LP)
1 x Quick-Start Guide (QSG-DVIKVM-LAN-LTX)
