Elo 1000 Series 1515L Touch Screen Monitor

by
ELO
PCN#
V21394
MFG#
E700813
$580.24
cps

Extended & Accidental Damage Protection Plans Available Details

  Free Shipping
Estimated Shipment:

Calculating Shipping

Product Highlights:
  • 15"
  • Surface Acoustic Wave
  • 1024 x 768

Show more

Product Condition: New and Factory Fresh
Limited Warranty3 Year
Shipping Weight: 15 lbs.
Elo 1000 Series 1515L Touch Screen Monitor
Tech Specs
Specifications

Manufacturer

Elo Touch Solutions, Inc

Manufacturer Part Number

E700813

Manufacturer Website Address

http://www.elotouch.com

Brand Name

Elo

Product Series

1000

Product Model

1515L

Product Name

1000 Series 1515L Touch Screen Monitor

Marketing Information

The 1515L touchmonitor is designed, developed and built to provide the most cost-effective touch solutions for system integrators and VARs. Aimed at the fast-changing retail POS and hospitality markets, they provide reliable, durable operation and come from the worldwide leader in touchmonitors, Elo TouchSystems.

Product Type

LCD Touchscreen Monitor
Technical Information

Screen Size Class

15"

Viewable Screen Size

15"

Screen Mode

XGA

Screen Surface

Anti-glare

Response Time

11.70 ms

Aspect Ratio

4:3

Horizontal Viewing Angle

140°

Vertical Viewing Angle

125°

Mount Type

  • Desk Mountable
  • Wall Mountable

Horizontal Frequency

60.20 Hz
Video

Maximum Resolution

1024 x 768

Standard Refresh Rate

75 Hz

Color Supported

16.2 Million Colors

Contrast Ratio

500:1

Brightness

230 Nit
Touchscreen Information

Touchscreen

Yes

Touchscreen Type

Surface Acoustic Wave
Interfaces/Ports

USB

Yes

VGA

Yes

Serial Port

Yes
Power Description

Input Voltage

220 V AC

Operating Power Consumption

30 W
Physical Characteristics

VESA Mount Compatible

Yes

VESA Mount Standard

75 x 75

Product Color

Dark Gray

Height with Stand

12.20"

Width with Stand

13.80"

Depth with Stand

6.90"

Weight (Approximate)

7.30 lb

Weight with Stand (Approximate)

10.60 lb
Miscellaneous

Package Contents

  • 1515L Desktop Touchscreen LCD Monitor
  • Detachable touch and video cables

Platform Supported

  • Mac
  • Sun

Energy Star

Yes

Environmentally Friendly

Yes
Warranty

Limited Warranty

3 Year
