Elo 2494L 24" Class Open-frame LCD Touchscreen Monitor - 16:9 - 16 ms

by
ELO
PCN#
8VZ422
MFG#
E493782
$724.32
cps

Extended & Accidental Damage Protection Plans Available Details

  Free Shipping
Estimated Shipment:

Calculating Shipping

Product Highlights:
  • 23.8" Viewable
  • TouchPro Projected Capacitive
  • 10 Point(s) Multi

Show more

Product Condition: New and Factory Fresh
Limited Warranty3 Year
Shipping Weight: 19 lbs.
Elo 2494L 24" Class Open-frame LCD Touchscreen Monitor - 16:9 - 16 ms
Tech Specs
Specifications

Manufacturer

Elo Touch Solutions, Inc

Manufacturer Part Number

E493782

Manufacturer Website Address

http://www.elotouch.com

Brand Name

Elo

Product Series

90

Product Model

2494L

Product Name

2494L 23.8" Open Frame Touchscreen

Marketing Information

Elo 2494L Open Frame Touchscreen Display

The Elo 2494L 24-inch open frame touchscreen display delivers an industrial-grade solution that is cost-effective for OEMs and systems integrators requiring a reliable product for their customers. Designed with reliability from the start, Elo's open frames deliver outstanding image clarity and light transmission with stable, drift-free operation for accurate touch responses. The 90-Series product line is available in a wide range of sizes, touch technologies and brightness, offering the versatility needed for commercial kiosk applications from self-service and gaming to industrial automation and healthcare.

Enabling Partners to Build Smarter Kiosks

With EloView® and the Backpack, managing kiosks is EASY! The Elo Backpack is an Android powered compute engine capable of transforming Elo touchscreens into an affordable, scalable, single-architecture media platform. With its simplified content-delivery and remote-management capabilities via the EloView portal, the Backpack provides a low-power, solid-state, fan-less computing solution with the capability to simplify deployments and remotely manage kiosks out-of-the-box.

Flexibility for Your Install

Our commercial-grade open frames can be mounted in landscape, portrait, and face-up orientations providing optimal flexibility for mounting in any table, kiosk, or cabinet design. Whether viewing directly, at an angle, or from a distance, our open frames offer what you need while maintaining optimal clarity and the viewing experience you want to deliver.

Touch Thru Glass Enabled with PCAP

Our TouchPro® PCAP technology supports touch thru functionality for installations that require a front layer of glass with thickness's up to 6mm or solutions that require specific IP ratings. Whether you need a flush-mounted display or one that is
fully-encased behind a cover glass, our robust PCAP Open Frames are purpose-built for durability in various applications and environments: from self-service kiosks to highly used gaming cabinets to harsh industrial machines.

Built for Commercial Use

We pride ourselves on being one of the best manufacturers in the market - We design and build the complete solution, with touch integrated from the start. Our robust touchscreen solutions offer flexibility for diverse environments and have undergone rigorous testing to ensure the longest life possible for our product - maximizing your ROI.

Product Type

Open-frame LCD Touchscreen Monitor
Technical Information

Screen Size Class

24"

Viewable Screen Size

23.8"

Screen Mode

Full HD

Panel Technology

Thin Film Transistor (TFT)

Response Time

16 ms

Response Time Details

16ms Typical

Aspect Ratio

16:9

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Mount Type

  • Flush Mount
  • Rear Mount

Placement

Tabletop

Backlight Technology

LED

Features

  • OSD/Power Lock
  • On-screen Display (OSD)

Horizontal Frequency

30 kHz to 82 kHz

Vertical Frequency

50 Hz to 75 Hz
Video

Maximum Resolution

1920 x 1080

Color Supported

16.7 Million Colors

Native Contrast Ratio

3,000:1

Brightness

250 Nit
Touchscreen Information

Touchscreen Type

TouchPro Projected Capacitive

Multi-touch Screen

Yes

Number of Simultaneous Touchpoints

10
Interfaces/Ports

HDMI

Yes

USB

Yes

VGA

Yes

DisplayPort

Yes
Power Description

Operating Power Consumption

17.46 W
Physical Characteristics

VESA Mount Compatible

Yes

VESA Mount Standard

200 x 100

Color Family

Black

Product Color

Black

Height

13.4"

Width

22.4"

Depth

1.5"

Weight (Approximate)

13.60 lb
Miscellaneous

Package Contents

  • 2494L 23.8" Open Frame Touchscreen
  • HDMI cable
  • VGA Cable
  • RJ45 OSD Remote
  • Touch USB Cable
  • Quick Install Guide
  • Flush Mount Brackets w/Screws
  • EEI Label
  • Japan Class-B TM info sheet

Environmentally Friendly

Yes
Warranty

Limited Warranty

3 Year
