Elo 1291L Open-frame LCD Touchscreen Monitor - 4:3 - 25 ms

Name: Elo 1291L Open-frame LCD Touchscreen Monitor - 4:3 - 25 ms
Brand: ELO
SKU: 8K3224
Price: 626 USD
Availability: OutOfStock

ELO

PCN#

8K3224

MFG#

E329452

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Estimated Shipment:

Product Highlights:

12.1" Viewable
IntelliTouch Surface Wave
800 x 600
SVGA
16.2 Million Colors
1,500:1
450 Nit
LED Backlight
HDMI
USB
VGA
DisplayPort
Black
3 Year

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 1 lbs.

Elo 1291L Open-frame LCD Touchscreen Monitor - 4:3 - 25 ms

Overview

Tech Specs

Specifications

Manufacturer	Elo Touch Solutions, Inc
Manufacturer Part Number	E329452
Manufacturer Website Address	http://www.elotouch.com
Brand Name	Elo
Product Model	1291L
Product Name	1291L 12" Open Frame Touchscreen (Rev B)
Marketing Information	The Elo 1291L 12-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions thanks to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact display is designed for touch with proven Elo expertise and reliability built in. The 1291L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Featuring a brilliant wide viewing angle panel, the open-frame touchscreen instantly grabs and holds the users' attention for kiosks, casino and amusement, retail self-service, and industrial automation environments. Easily integrated. The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected, as well as backwards compatibility, helping to minimize enclosure costs. Touch ready. Available with a choice of industry-leading single-touch or multi-touch technologies, including IntelliTouch® single-touch surface acoustic wave (SAW) touchscreen technology, and Elo's latest TouchPro™ PCAP two glass solution (2GS) 10-touch with Zero-bezel, offering pristine optical clarity and touch durability. Commercial-grade. The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution, with touch integrated from the start. Using our touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life testing processes. All our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF. Other features. Viewing angle of 178° (h) x 178° (v), for sharp colors and graphics in both portrait and landscape modes 10-touch TouchPro projected capacitive (PCAP) with two-touch thru-glass capabilities Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing Display Port and VGA video interfaces
Product Type	Open-frame LCD Touchscreen Monitor

Technical Information

Viewable Screen Size	12.1"
Screen Mode	SVGA
Response Time	25 ms
Aspect Ratio	4:3
Mount Type	Rear Mount
Backlight Technology	LED

Video

Maximum Resolution	800 x 600
Color Supported	16.2 Million Colors
Contrast Ratio	1,500:1
Brightness	450 Nit

Touchscreen Information

Touchscreen Type

IntelliTouch Surface Wave

Interfaces/Ports

HDMI	Yes
USB	Yes
VGA	Yes
DisplayPort	Yes

Power Description

Operating Power Consumption

12.20 W

Physical Characteristics

VESA Mount Compatible	Yes
Product Color	Black
Height	9.5"
Width	11.9"
Depth	2"
Weight (Approximate)	5.80 lb

Miscellaneous

Package Contents	1291L 12" Open Frame Touchscreen (Rev B) HDMI cable VGA Cable RJ45 OSD Remote Touch USB Cable User Manual CD Quick Install Guide "L" (Side Mount) Brackets and w/Screws EEI Label Japan Class-B TM info sheet
Certifications & Standards	TÜV
Environmentally Friendly	Yes

Warranty

Limited Warranty

3 Year
