Elo 1002L 10" Class LCD Touchscreen Monitor - 16:10 - 29 ms

Name: Elo 1002L 10" Class LCD Touchscreen Monitor - 16:10 - 29 ms
Brand: ELO
SKU: 7WC527
Price: 369.61 USD
Availability: InStock

ELO

PCN#

7WC527

MFG#

E155834

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$369.61

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

10.1" Viewable
TouchPro Projected Capacitive
10 Point(s) Multi
touch Screen
1280 x 800
WXGA
Thin Film Transistor (TFT)
262,000 Colors
350 Nit
LED Backlight
Speakers
HDMI
USB
VGA
Black
3 Year
USB Hub

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 5 lbs.

Elo 1002L 10" Class LCD Touchscreen Monitor - 16:10 - 29 ms

Overview

Tech Specs

Specifications

Manufacturer	Elo Touch Solutions, Inc
Manufacturer Part Number	E155834
Manufacturer Website Address	http://www.elotouch.com
Brand Name	Elo
Product Series	02
Product Model	1002L
Product Name	1002L Touchscreen Monitor
Marketing Information	The Elo 1002L Touchscreen Monitor is designed with the same seamless style that spans across the entire line up of 02-Series Monitors. With a compact form factor and clean design for easy integration, the 1002L offers the flexibility to install as a traditional POS terminal or a customer facing point of interaction - making it well-suited for point-of-sale, self-service, signage and hospitality applications. And with a variety of peripherals, the monitor can be transformed to meet the demands of almost any blueprint. Single Cable Connection The 1002L provides a USB Type-C interface that provides touch, video and power. By reducing the number of cables required for any set up from 3 to 1, installation and servicing is a breeze. In case your PC isn't equipped with USB Type-C yet, you can still use traditional HDMI or VGA to connect to your PC. One for You. One for Your Customers. The 02-Series offers dual functionality. Use it as a traditional POS terminal or customer facing display - or BOTH! Start increasing brand loyalty and customer satisfaction by offering your customers a point of interaction to review transactions, participate in loyalty programs or see the latest promotion. Well-Suited for... Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.
Packaged Quantity	1
Product Type	LCD Touchscreen Monitor

Technical Information

Screen Size Class	10"
Viewable Screen Size	10.1"
Screen Mode	WXGA
Screen Surface	Anti-glare
Panel Technology	Thin Film Transistor (TFT)
Response Time	29 ms
Aspect Ratio	16:10
Horizontal Viewing Angle	170°
Vertical Viewing Angle	170°
Mount Type	Rear Mount
Placement	Tabletop
Backlight Technology	LED
Features	Anti-glare On-screen Display (OSD) Cable Lock Slot
Horizontal Frequency	31.50 kHz to 80 kHz
Vertical Frequency	60 Hz
Curved Screen	No

Video

Maximum Resolution	1280 x 800
Standard Refresh Rate	60 Hz
Color Supported	262,000 Colors
Native Contrast Ratio	800:1
Brightness	350 Nit

Audio

Speakers	Yes
Number of Speakers	2
Speaker Output Power	4 W

Touchscreen Information

Touchscreen	Yes
Touchscreen Type	TouchPro Projected Capacitive
Multi-touch Screen	Yes
Number of Simultaneous Touchpoints	10

Interfaces/Ports

HDMI	Yes
USB	Yes
VGA	Yes
USB Type-C	Yes
Number of USB Ports	4
Total Number of USB Type-C Ports	1

Built-in Devices

USB Hub

Power Description

Operating Power Consumption	7.43 W
Standby Power Consumption	1.26 W
Off-Mode Power Consumption	200 mW

Physical Characteristics

VESA Mount Compatible	Yes
VESA Mount Standard	75 x 75
Product Color	Black
Height	7"
Width	10"
Depth	1.1"
Weight (Approximate)	1.95 lb

Miscellaneous

Package Contents	1002L Touchscreen Monitor HDMI cable USB Cable (USB Type-A to Type-C) Quick Install Guide EEI Label Power brick NA Power cable EU Power cable 2 x Cable clamps 2 x Tie wraps 3 x Screws (M3x8mm) for cable clamps 2 x Screws (M3x10mm) for cable doors
Mean Time Between Failures (MTBF)	5.7 Year
Country of Origin	China
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS) China Restriction of Hazardous Substances (China RoHS) Waste Electrical and Electronic Equipment Directive (WEEE) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)

Warranty

Limited Warranty

3 Year
