CyberPower Smart App Sinewave PRL3000RT2UC 3000VA Tower/rack convertible UPS

Name: CyberPower Smart App Sinewave PRL3000RT2UC 3000VA Tower/rack convertible UPS
Brand: CYBERPOWER
SKU: JM0750
Price: 3688.95 USD
Availability: InStock

CYBERPOWER

PCN#

JM0750

MFG#

PRL3000RT2UC

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$3,688.95

Extended & Accidental Damage Protection Plans Available Details

3-Year $332.99

2-Year $265.99

Free Shipping

Estimated Shipment:

Product Highlights:

Lithium, 3000VA/3000W, 100
120 VAC, NEMA L5
30P, 2U, Rack / Tower, Sine Wave, 9 Outlets, LCD, PowerPanel® Business, $400000.00 CEG, 5YR Warranty

Product Condition: New and Factory Fresh

Limited Warranty5 YearAdditional Warranty Information5 years (Including Battery) and 400,000 connected equipment guarantee.Directly Connected Equipment Guarantee400000 Lifetime

Shipping Weight: 80 lbs.

CyberPower PRL3000RT2UC Smart App Sinewave UPS Systems

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	PRL3000RT2UC
Manufacturer Website Address	https://www.cyberpowersystems.com
Brand Name	CyberPower
Product Line	Smart App Sinewave
Product Model	PRL3000RT2UC
Product Name	PRL3000RT2UC Smart App Sinewave UPS Systems
Marketing Information	The lithium PRL3000RT2UC is a Smart App Sinewave rack/tower convertible UPS with line-interactive topology, surge protection, and battery backup. CyberPower's Smart App Sinewave series has sine wave output to eliminate power gaps that can be detected by sensitive equipment and cause unexpected shutdowns. The Smart App Sinewave PRL3000RT2UC improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel, captive screws for battery panel access, and color-coded rear panel make battery changes and installations simple and fast. The PRL3000RT2UC also has an innovative LCD panel that rotates 90°,and provides information on 47 different settings including UPS stats, UPS setup and control management, and testing options. Lithium battery chemistry is a maintenance free premium battery technology with a longer lifespan and higher efficiency. This model has built-in Cloud monitoring, and accepts the RMCARD205 network management card for remote management and control via a standard web browser or network management system. With a 400,000 connected equipment guarantee and a five-year warranty, you can trust CyberPower's commitment to the quality of the PRL3000RT2UC.
Product Type	Line-interactive UPS

Technical Information

AVR	Yes
Plug/Connector Type	NEMA L5-30P
Receptacle Type	NEMA 5-20R
Receptacle Detail	8 x NEMA 5-20R
Number of Battery & Surge Outlets	9
Number of Critical Load Outlets	4
Overload Protection	Yes
Cord Length	10 ft
Transfer Time	6 ms
EMI/RFI Noise Filter	Yes
Energy Saving	GreenPower UPS™ Bypass Technology
Application/Usage	Corporate Server Network Device Storage Device Telecommunication VoIP
Features	Audible Alarm

Power Description

Load Capacity (VA)	3000 VA
Load Capacity (Watt)	3000 W
Input Voltage	120 V AC
Input Voltage Range	100 V AC - 120 V AC 70 V AC - 155 V AC
Output Voltage	100 V AC 110 V AC 120 V AC
Input Frequency	50 Hz 60 Hz
Output Frequency	50 Hz 60 Hz
Waveform Type	Sine Wave
Surge Energy Rating	2430 J
Circuit Breaker	Yes
Output Power Factor	1

Display & Graphics

Display

LCD

Management

Network Management	SNMP/HTTP Remote Monitoring
Alarm	Battery Mode

Controls/Indicators

Status Indicators

Power On

Interfaces/Ports

Serial Port	Yes
USB	Yes
EPO Port	Yes
USB (HID Compliant) Port	Yes

Battery Information

Number of Batteries	4
Battery Characteristics	Sealed
Battery Chemistry	Lithium Ion (Li-Ion)
Battery Size	12V
Battery Capacity	9000 mAh
Backup/Run Time (Full Load)	4 Minute
Backup/Run Time (Half Load)	13.60 Minute
Typical Battery Recharge Time	2 Hour
Hot Swappable	Yes
Replaceable Battery	Yes

Environmental Conditions

Minimum Operating Temperature	32°F (0°C)
Maximum Operating Temperature	104°F (40°C)
Storage Temperature	5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation	9843 ft
Maximum Storage Elevation	49213 ft
Operating Humidity	0% - 95%
Storage Relative Humidity	0% - 95%
Thermal Dissipation	56.42 W

Physical Characteristics

Color Family	Dual Color
Product Color	Black Silver
Height	3.40"
Width	17.10"
Depth	19.70"
Rack Height	2U
Form Factor	Rack/Tower
Weight (Approximate)	65.30 lb

Miscellaneous

Additional Information	Automatic Voltage Regulation: Double Boost Management Cable: USB Cable Material of Construction: Metal Overload Protection: Internal Circuitry Limiting Plug Style: Straight Serial Port: 1 RS232 Software (Free Download): PowerPanel® Business USB Charge Port: No
Certifications & Standards	UL1778
Software Included	PowerPanel® Business Edition
Energy Star	Yes
Environmentally Friendly	Yes
Energy Efficiency Certification	ENERGY STAR 6.0
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty	5 Year
Additional Warranty Information	5 years (Including Battery) and 400,000 connected equipment guarantee.
Directly Connected Equipment Guarantee	400000 Lifetime
