CyberPower PR750LCDRT1U Smart App Sinewave UPS Systems

Name: CyberPower PR750LCDRT1U Smart App Sinewave UPS Systems
Brand: CYBERPOWER
SKU: 9GM137
Price: 724.95 USD
Availability: InStock

CYBERPOWER

PCN#

9GM137

MFG#

PR750LCDRT1U

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$724.95

Extended & Accidental Damage Protection Plans Available Details

2-Year $66.99

3-Year $89.99

Free Shipping

Estimated Shipment:

Product Highlights:

750VA/600W, 120 VAC, NEMA 5
15P, 1U, Rack / Tower, Sine Wave, 7 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty

Product Condition: New and Factory Fresh

Limited WarrantyCertifications & StandardsUL1778 4thcUL CSA C22.2 No 107.3-05FCC DOC Class ASoftware IncludedPowerPanel Business EditionEnergy StarNoCountry of OriginChinaEnvironmentally FriendlyYesEnvironmental ComplianceRestriction of Hazardous Substances (RoHS)Warranty

Shipping Weight: 37 lbs.

CyberPower PR750LCDRT1U Smart App Sinewave UPS Systems

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	PR750LCDRT1U
Manufacturer Website Address	https://www.cyberpowersystems.com
Brand Name	CyberPower
Product Series	Smart App Sinewave UPS
Product Model	PR750LCDRT1U
Product Name	PR750LCDRT1U Smart App Sinewave UPS Systems
Marketing Information	A rack/tower convertible UPS with line interactive topology, the CyberPower Smart App Sinewave PR750LCDRT1U provides battery backup, power protection (using sine wave output), and surge protection for corporate servers, department servers, storage appliances, network devices, and telecom installations requiring Active PFC power source compatibility. The PR750LCDRT1U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The PR750LCDRT1U comes with a three-year warranty (including coverage of batteries) and a 400,000 Connected Equipment Guarantee.
Product Type	Line-interactive UPS

Technical Information

AVR	Yes
AVR Range	Boost +30% / Buck -12%
Plug/Connector Type	NEMA 5-15P
Receptacle Type	NEMA 5-15R
Receptacle Detail	7 x NEMA 5-15R
Number of Battery & Surge Outlets	6
Number of Surge-only Outlets	1
Number of Critical Load Outlets	3
Transfer Time	10 ms
Overload Protection	Yes
EMI/RFI Noise Filter	Yes
Energy Saving	GreenPower UPS™ Bypass
Application/Usage	Server Storage Device VoIP Device Network Device Telecommunication
Cord Length	10 ft
Circuit Breaker Current Rating	15 A

Power Description

Load Capacity (VA)	750 VA
Load Capacity (Watt)	600 W
Input Voltage	120 V AC
Input Voltage Range	80 V AC - 150 V AC
Output Voltage	120 V AC
Input Frequency	50 Hz 60 Hz
Output Frequency	60 Hz
Waveform Type	Sine Wave
Surge Energy Rating	1030 J
Output Power Factor	0.8

Display & Graphics

Display

LCD

Management

Network Management	SNMP/HTTP Remote Monitoring
Alarm	Battery Mode

Controls/Indicators

Status Indicators

Power On
Wiring Fault

Interfaces/Ports

Serial Port	Yes
USB	Yes
USB (HID Compliant) Port	Yes
EPO Port	Yes

Battery Information

Number of Batteries	4
Battery Characteristics	Sealed
Battery Chemistry	Lead Acid
Battery Size	6V
Battery Capacity	7000 mAh
Backup/Run Time (Full Load)	3 Minute
Backup/Run Time (Half Load)	10 Minute
Typical Battery Recharge Time	6 Hour
Replaceable Battery	Yes

Environmental Conditions

Maximum Operating Temperature	104°F (40°C)
Storage Temperature	5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation	10000 ft
Maximum Storage Elevation	50000 ft
Operating Humidity	0% - 95%
Thermal Dissipation	13.36 W

Physical Characteristics

Color Family	Black
Product Color	Black
Form Factor	Rack/Tower
Rack Height	1U
Height	1.8"
Width	17.3"
Depth	15.8"
Weight (Approximate)	30.70 lb

Miscellaneous

Package Contents	Smart App Sinewave PR750LCDRT1U 750VA Pure Sine Wave 1U RT LCD UPS User's Manual for UPS 2 x Rack Mount Brackets 2 x Wall Mount Brackets 2 x Stands Emergency Power Off Cable (gray PowerPanel® Business Edition Software CD Serial Interface Cable (RJ45/DB-9) USB A+B type cable Warranty Registration Card
Additional Information	Active PFC Compatible : Yes Energy Saving : GreenPower UPS™ Bypass Technology UPS Topology : Line Interactive Battery Quantity : 4 Battery Size : 6 V / 7 Ah Battery Type : Sealed Lead-Acid Battery Hot Swappable : Yes Replacement Battery Cartridge : RB0670X4A Replacement Battery Cartridge Quantity : 1 Runtime at Full Load : 3 min Runtime at Half Load : 10 min Typical Recharge Time : 6 Hours (0% to 90% charged) User Replaceable Battery : Yes Physical Dimensions - (WxHxD) (cm) : 43.82 x 4.45 x 40.13 (cm) Physical Dimensions - (WxHxD) (in) : 17.25 x 1.75 x 15.8 (in) Physical Dimensions - (WxHxD) (mm) : 438 x 44 x 401 (mm) Weight (kg) : 13.93 Weight (lb) : 30.7 Shipping Dimensions - (WxHxD) (cm) : 49.53 x 15.24 x 52.71 (cm) Shipping - Dimensions (WxHxD, in) : 19.5 x 6.0 x 20.75 (in) Shipping - Dimensions (WxHxD, mm) : 495.3 x 152.4 x 527.05 (mm) Shipping - Weight (kg) : 16.92 Shipping - Weight (lb) : 37.30 Circuit Breaker : 15 A Cord Length : 10 ft (3.0 m) Input Frequency Range : 57 Hz - 63 Hz Input Plug Type : NEMA 5-15P Input Voltage Range : 80 VAC - 150 VAC Nominal Input Voltage : 120 VAC Plug Style : Right Angle - 45° Offset Automatic Voltage Regulation : Double Boost On AC WaveForm : Sine Wave On Battery Frequency : 60 Hz ± 1% On Battery Voltage : 120 VAC ± 5% On Battery Waveform : Sine Wave Outlets - Battery & Surge Protected : 6 Outlets - Critical Load : 3 Outlets - Surge-Only Protected : 1 Outlets - Total : 7 Outlet Type COMPUTED : 7 - NEMA 5-15R Output Power Factor : 0.8 Overload Protection : Internal Circuitry Limiting Typical Transfer Time : 10 ms Under/Over-Voltage Correction : +30% USB Charge Port : No VA : 750 VA Watts : 600 W EMI/RFI Filtration COMPUTED : Yes Surge Suppression (Joules) : 1030 J EMI/RFI Filtration COMPUTED : Yes Surge Suppression (Joules) : 1030 J Audible Alarms : Battery Mode Contact Closure : No Emergency Power Off (EPO) Port : Yes HID Compliant USB Port : Yes LCD : Multifunction LCD LED Indicators : Power On Management Cable : USB Cable Serial Port : 1 Serial SNMP / HTTP Remote Monitoring : Yes - with optional RMCARD205 Software (Free Download) : PowerPanel® Business Color : Black Form Factor : Rack / Tower Material of Construction : Metal Rack Height : 1U AC Mode Thermal Dissipation : 45.6 BTU/hr Operating Elevation : 0 - 10000 ft (0 - 3048 m) Operating Relative Humidity : 0 - 95 % (non-condensing) Operating Temperature : 32 - 104 °F (0 - 40 °C) Storage Elevation : 0 - 50000 ft (0 - 15239 m) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Environmental : RoHS Compliant Safety : UL1778 CEG Amount : 400000 Connected Equipment Guarantee : Lifetime Extended Warranty Option : WEXT5YR-U2A Product Warranty : 3 Year Limited Warranty
Certifications & Standards	UL1778 4th cUL CSA C22.2 No 107.3-05 FCC DOC Class A
Software Included	PowerPanel Business Edition
Energy Star	No
Country of Origin	China
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty	3 Year
Directly Connected Equipment Guarantee	400000 Lifetime
