CYBERPOWER PR2200RT2UCN UPS 2U 8X5-20R 10FT CORD CLOUD 3YR WTY

Name: CYBERPOWER PR2200RT2UCN UPS 2U 8X5-20R 10FT CORD CLOUD 3YR WTY
Brand: CYBERPOWER
SKU: NM1688
Price: 1729.95 USD
Availability: InStock

CYBERPOWER

PCN#

NM1688

MFG#

PR2200RT2UCN

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$1,729.95

Extended & Accidental Damage Protection Plans Available Details

2-Year $145.99

3-Year $194.99

Free Shipping

Estimated Shipment:

Product Highlights:

2U Tower/Rack Convertible
AVR
3 Hour Recharge
3.20 Minute Stand
by
120 V AC Input
100 V AC, 120 V AC, 110 V AC Output
Sine Wave
Serial Port
USB
LCD Display
8 x NEMA 5
20R
8 x Battery/Surge Outlet
SNMP/HTTP Remote Monitoring, Dry Contact, Relay
MS Card

Product Condition: New and Factory Fresh

Limited Warranty3 YearDirectly Connected Equipment Guarantee400000 Lifetime

Shipping Weight: 76 lbs.

CyberPower New Smart App Sinewave UPS PR2200RT2UCN 2200VA Tower/rack convertible UPS

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	PR2200RT2UCN
Manufacturer Website Address	https://www.cyberpowersystems.com/
Brand Name	CyberPower
Product Series	New Smart App Sinewave UPS
Product Model	PR2200RT2UCN
Product Name	New Smart App Sinewave UPS PR2200RT2UCN 2200VA Tower/rack convertible UPS
Marketing Information	The PR2200RT2UCN is a Smart App Sinewave rack/tower convertible UPS with line-interactive topology, surge protection, and battery backup. CyberPower's Smart App Sinewave series creates a sine wave output devoid of power gaps which could cause unexpected shutdowns of sensitive equipment. The Smart App Sinewave PR2200RT2UCN improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel, captive screws for battery panel access, and color-coded rear panel make battery changes and installations simple and fast. The PR2200RT2UCN also has an innovative LCD panel that rotates 90°, tilts for a better viewing angle, and provides information on 47 different settings including UPS stats, UPS setup and control management, and testing options. This model includes pre-installed RMCARD205 network management card for remote management and control via a standard web browser or network management system and built-in cloud monitoring. With a 400,000 connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to the quality of the PR2200RT2UCN.
Product Type	Line-interactive UPS

Technical Information

AVR	Yes
Plug/Connector Type	NEMA L5-30P
Receptacle Type	NEMA 5-20R
Receptacle Detail	8 x NEMA 5-20R
Number of Battery & Surge Outlets	8
Number of Critical Load Outlets	4
Overload Protection	Yes
Cord Length	10 ft
Transfer Time	13 ms
EMI/RFI Noise Filter	Yes
Energy Saving	GreenPower UPS Bypass Technology
Application/Usage	Server Storage Device VoIP Network Device Corporate Telecommunication Equipment
Surge Suppression	Yes
Features	Audible Alarm

Power Description

Load Capacity (VA)	2200 VA
Load Capacity (Watt)	2200 W
Input Voltage	120 V AC
Input Voltage Range	69 V AC - 155 V AC 75 V AC - 149 V AC
Output Voltage	100 V AC 120 V AC 110 V AC
Input Frequency	47 Hz 63 Hz
Output Frequency	50 Hz 60 Hz
Waveform Type	Sine Wave
Surge Energy Rating	2430 J
Circuit Breaker	Yes
Output Power Factor	1

Display & Graphics

Display

LCD

Management

Network Management	SNMP/HTTP Remote Monitoring Dry Contact Relay-MS Card
Alarm	Battery Mode Low Battery Overload Over-charge Fault

Controls/Indicators

Status Indicators

LCD Indicators:

UPS Stats
UPS Setup
Control Management
Testing Options

LED Indicators:

Power On
Line Mode
Battery Mode
Fault
UPS Fault

Interfaces/Ports

Serial Port	Yes
Network (RJ-45)	Yes
USB	Yes
EPO Port	Yes
USB (HID Compliant) Port	Yes

Battery Information

Number of Batteries	4
Battery Characteristics	Sealed
Battery Chemistry	Lead Acid
Battery Size	12V
Battery Capacity	9000 mAh
Backup/Run Time (Full Load)	3.20 Minute
Backup/Run Time (Half Load)	11.80 Minute
Typical Battery Recharge Time	3 Hour
Hot Swappable	Yes
Replaceable Battery	Yes

Environmental Conditions

Minimum Operating Temperature	32°F (0°C)
Maximum Operating Temperature	104°F (40°C)
Storage Temperature	5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation	9843 ft
Maximum Storage Elevation	49213 ft
Operating Humidity	0% - 95%
Storage Relative Humidity	0% - 95%
Sound Emission (A-Weighted)	52.5 dB(A)
Thermal Dissipation	39.56 W

Physical Characteristics

Color Family	Black
Product Color	Black
Height	3.4"
Width	17.1"
Depth	16.2"
Rack Height	2U
Form Factor	Tower/Rack Convertible
Weight (Approximate)	59.79 lb

Miscellaneous

Certifications & Standards	UL 1778 VCCI FCC Class A CSA C22.2 No 107.3
Energy Star	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty	3 Year
Directly Connected Equipment Guarantee	400000 Lifetime
