CyberPower PR1500ELCDRTXL2U Smart App Sinewave UPS Systems

Name: CyberPower PR1500ELCDRTXL2U Smart App Sinewave UPS Systems
Brand: CYBERPOWER
SKU: 9GM035
Price: 1008.09 USD
Availability: InStock

CYBERPOWER

PCN#

9GM035

MFG#

PR1500ELCDRTXL2U

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$1,008.09

Extended & Accidental Damage Protection Plans Available Details

3-Year $143.99

2-Year $107.99

Estimated Shipment:

Product Highlights:

1500VA/1125W, 230 VAC, IEC
320 C14, 2U, Rack / Tower, Sine Wave, 10 Outlets, LCD, PowerPanel® Business, $400000 CEG, 3YR Warranty

Product Condition: New and Factory Fresh

Limited WarrantyCertifications & StandardsCEEnergy StarNoCountry of OriginChinaEnvironmentally FriendlyYesEnvironmental ComplianceRestriction of Hazardous Substances (RoHS)Warranty

Shipping Weight: 88 lbs.

CyberPower PR1500ELCDRTXL2U Smart App Sinewave UPS Systems

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	PR1500ELCDRTXL2U
Manufacturer Website Address	https://www.cyberpowersystems.com
Brand Name	CyberPower
Product Series	Smart App Sinewave UPS
Product Model	PR1500ELCDRTXL2U
Product Name	PR1500ELCDRTXL2U Smart App Sinewave UPS Systems
Product Type	Line-interactive UPS

Technical Information

AVR	Yes
Plug/Connector Type	IEC 320-C14
Receptacle Type	IEC 60320 C13
Receptacle Detail	10 x IEC 60320 C13
Number of Battery & Surge Outlets	10
Number of Critical Load Outlets	4
Transfer Time	4 ms
Dataline Protection	RJ-11 RJ-45
Overload Protection	Yes
EMI/RFI Noise Filter	Yes
Energy Saving	GreenPower UPS™ Bypass Technology
Application/Usage	Server Storage Device Network Device Telecommunication
Cord Length	72"
Circuit Breaker Current Rating	15 A

Power Description

Load Capacity (VA)	1500 VA
Load Capacity (Watt)	1125 W
Input Voltage	220 V AC 230 V AC 240 V AC
Input Voltage Range	160 V AC - 280 V AC
Output Voltage	220 V AC 230 V AC 240 V AC
Input Frequency	47 Hz 63 Hz
Output Frequency	50 Hz 60 Hz
Waveform Type	Sine Wave
Surge Energy Rating	810 J
Output Power Factor	0.8

Display & Graphics

Display

LCD

Management

Network Management	SNMP/HTTP Remote Monitoring
Alarm	Battery Mode

Controls/Indicators

Status Indicators

LED Indicators: Power On

Interfaces/Ports

Serial Port	Yes
USB	Yes
USB (HID Compliant) Port	Yes
EPO Port	Yes

Battery Information

Number of Batteries	1
Battery Characteristics	Sealed
Battery Chemistry	Lead Acid
Battery Size	12V
Battery Capacity	9000 mAh
Backup/Run Time (Full Load)	9 Minute
Backup/Run Time (Half Load)	24 Minute
Typical Battery Recharge Time	6 Hour
Replaceable Battery	Yes

Environmental Conditions

Maximum Operating Temperature	104°F (40°C)
Storage Temperature	5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation	10000 ft
Maximum Storage Elevation	50000 ft
Sound Emission (A-Weighted)	34.5 dB(A)
Thermal Dissipation	49.82 W

Physical Characteristics

Color Family	Black
Product Color	Black
Form Factor	Rack/Tower
Rack Height	2U
Height	3.5"
Width	17.1"
Depth	18.9"
Weight (Approximate)	76.06 lb

Miscellaneous

Package Contents	1500 VA Line Interactive UPS 4x IEC C13-C14 Power Cords Manual USB cable
Additional Information	Energy Saving : GreenPower UPS™ Bypass Technology UPS Topology : Line Interactive Battery Size : 12 V / 9 Ah Battery Type : Sealed Lead-Acid Battery Extended Battery Module : BP48VP2U02 Hot Swappable : Yes Replacement Battery Cartridge : RBP0040 Replacement Battery Cartridge Quantity : 1 Runtime at Full Load : 9 min Runtime at Half Load : 24 min Typical Recharge Time : 6 Hours User Replaceable Battery : Yes Physical Dimensions - (WxHxD) (cm) : 43.31 x 8.79 x 47.96 (cm) Physical Dimensions - (WxHxD) (in) : 17.05 x 3.46 x 18.88 (in) Physical Dimensions - (WxHxD) (mm) : 433 x 88 x 480 (mm) Weight (kg) : 34.5 Weight (lb) : 76.06 Shipping Dimensions - (WxHxD) (cm) : 55.88 x 27.31 x 62.23 (cm) Shipping - Dimensions (WxHxD, in) : 22.0 x 10.75 x 24.5 (in) Shipping - Dimensions (WxHxD, mm) : 558.8 x 273.05 x 622.3 (mm) Shipping - Weight (kg) : 40.64 Shipping - Weight (lb) : 89.6 Adjustable Voltage Range : 150 - 300 VAC Circuit Breaker : 15 A Cord Length : 6 ft (1.8 m) Input Frequency Range : 47 Hz - 63 Hz Input Plug Type : IEC-320 C14 Input Voltage Range : 160 VAC - 288 VAC Nominal Input Voltage : 230 VAC Automatic Voltage Regulation : Double Boost On AC WaveForm : Sine Wave On Battery Frequency : 50/60 Hz ± 0.1Hz On Battery Voltage : 220/230/240 VAC ± 5% On Battery Waveform : Sine Wave Outlets - Battery & Surge Protected : 10 Outlets - Critical Load : 4 Outlets - Total : 10 Outlet Type COMPUTED : 10 - IEC-320 C13 Output Power Factor : 0.8 Overload Protection : Internal Circuitry Limiting Typical Transfer Time : 4 ms USB Charge Port : No VA : 1500 VA Watts : 1125 W EMI/RFI Filtration COMPUTED : Yes Phone / Network Protection RJ11/RJ45 : 1-In / 1-Out (Combo) Surge Suppression (Joules) : 810 J EMI/RFI Filtration COMPUTED : Yes Phone / Network Protection RJ11/RJ45 : 1-In / 1-Out (Combo) Surge Suppression (Joules) : 810 J Audible Alarms : Battery Mode Emergency Power Off (EPO) Port : Yes HID Compliant USB Port : Yes LCD : Multifunction LCD LED Indicators : Power On Management Cable : USB Cable Serial Port : 1 Serial SNMP / HTTP Remote Monitoring : Yes - with optional RMCARD205 Software (Free Download) : PowerPanel® Business Color : Black Form Factor : Rack / Tower Material of Construction : Metal Rack Height : 2U Audible noise at 1.5M from surface of unit : 34.5 dBA Online Thermal Dissipation : 170 BTU/hr Operating Elevation : 0 - 10000 ft (0 - 3048 m) Operating Relative Humidity : 0 - 95 % (non-condensing) Operating Temperature : 32 - 104 °F (0 - 40 °C) Storage Elevation : 0 - 50000 ft (0 - 15239 m) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Environmental : RoHS Compliant Safety : CE CEG Amount : 400000 Connected Equipment Guarantee : Lifetime Extended Warranty Option : WEXT5YR-U4A Product Warranty : 3 Year Limited Warranty
Certifications & Standards	CE
Energy Star	No
Country of Origin	China
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty	3 Year
Directly Connected Equipment Guarantee	400000 Lifetime
