CyberPower PDU83104 3 Phase 200 - 240 VAC 30A Switched Metered-by-Outlet PDU

Name: CyberPower PDU83104 3 Phase 200 - 240 VAC 30A Switched Metered-by-Outlet PDU
Brand: CYBERPOWER
SKU: 9MF711
Price: 1608.51 USD
Availability: OutOfStock

CYBERPOWER

PCN#

9MF711

MFG#

PDU83104

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

Estimated Shipment:

Product Highlights:

30 Outlets, 10 ft, NEMA L21
30P, Vertical, 0U, LCD, 3YR Warranty

Product Condition: New and Factory Fresh

Limited WarrantyCertifications & Standards UL60950-1 UL62368-1 FCC Class A Country of OriginPhilippinesEnvironmentally FriendlyYesEnvironmental ComplianceRestriction of Hazardous Substances (RoHS)Warranty

Shipping Weight: 25 lbs.

CyberPower PDU83104 3 Phase 200 - 240 VAC 30A Switched Metered-by-Outlet

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	PDU83104
Manufacturer Website Address	https://www.cyberpowersystems.com/
Brand Name	CyberPower
Product Series	Switched Metered-by-Outlet PDU
Product Model	PDU83104
Product Name	PDU83104 3 Phase 200 - 240 VAC 30A Switched Metered-by-Outlet
Marketing Information	Streamline capacity planning and power management with the CyberPower PDU83104 switched metered-by-outlet 3-Phase PDU. Ideal for data centers and network closets, this unit provides outlet-level power monitoring in real time, along with individual outlet control for remote reboots, load shedding, controlled power-cycling, and more. The PDU83104 supports inputs between 200-240V and includes 30 IEC-320 outlets. Other features include ultra-low power consumption, multi-color outlet LEDs, an interactive digital display with selectable background color, high operating temperature range, built-in web interface, and power event notifications. The CyberPower PDU83104 is protected by a three-year limited warranty.
Product Condition	New
Product Type	PDU

Technical Information

PDU Type	Switched with Metered-by-Outlet
Phase	Three Phase
Plug/Connector Type	NEMA L21-30P
Receptacle Type	IEC 60320 C13 IEC 60320 C19
Receptacle Detail	24 x IEC 60320 C13 6 x IEC 60320 C19
Protection Type	Overload Protection

Power Description

Input Voltage	230 V AC
Input Voltage Range	200 V AC - 240 V AC
Output Voltage Range	200 V AC - 240 V AC
Input Current	30 A

Management

Management	IPv4 TCP/IP UDP SNMPv1 HTTP NTP DNS Telnet DHCP SMTP FTP IPv6 SNMPv3 HTTPs SSH SSL TLS LDAP(S) RADIUS Syslog CLI Windows AD
Remote Outlet Switching	Yes

Interfaces/Ports

Network (RJ-45)

Yes

Physical Characteristics

Color Family	Black
Product Color	Black
Mounting Orientation	Vertical
Mount Type	Rack-mountable
Rack Height	0U
Cord Length	10 ft
Height	70.5"
Width	2.2"
Depth	2.2"
Weight (Approximate)	17 lb

Miscellaneous

Additional Information	Physical Dimensions - (WxHxD) (cm) : 5.59 x 179.07 x 5.59 (cm) Physical Dimensions - (WxHxD) (in) : 2.2 x 70.5 x 2.2 (in) Physical Dimensions - (WxHxD) (mm) : 56 x 1791 x 56 (mm) Weight (kg) : 7.71 Weight (lb) : 17 Shipping Dimensions - (WxHxD) (cm) : 17.15 x 15.24 x 205.74 (cm) Shipping - Dimensions (WxHxD, in) : 6.75 x 6.0 x 81.0 (in) Shipping - Dimensions (WxHxD, mm) : 171.45 x 152.4 x 2057.4 (mm) Shipping - Weight (kg) : 11.11 Shipping - Weight (lb) : 24.5 Cord Length : 10 ft (3.0 m) Derated Input Current : 24 A Input Frequency Range : 50 Hz - 60 Hz Input Plug Type : NEMA L21-30P Maximum Input Current : 30A Nominal Input Voltage : 200 - 240 VAC Phase : 3 Phase Nominal Output Voltage : 200 - 240 VAC Outlets - # of Banks : 3 Outlets - Total : 30 Outlet Type COMPUTED : 24 - IEC-320 C13 Overload Protection : 20A X 3 USB Charge Port : No Environmental Sensor : Optional, via RJ45 Hardware Connection Port : Ethernet (RJ45) LCD : Multifunction LCD LED Indicators : Tx/Rx Modular Expandability (Cascading) : Yes, via RJ45 Monitoring Level : Input Outlet switching : Yes Protocols : IPv4, TCP/IP, UDP, SNMPv1, HTTP, NTP, DNS, Telnet, DHCP, SMTP, FTP, IPv6, SNMPv3, HTTPs, SSH, SSL, TLS, LDAP(S), RADIUS, Syslog, CLI, Windows AD Software (Free Download) : PowerPanel® Business Upgradeable firmware : Yes Adjustable Mounting Brackets : 1 set Color : Black Cord Retention Tray/Cord Organizers : Yes Form Factors Supported : 0U Vertical Rackmount Material of Construction : Metal Rack Height : 0U Operating Elevation : 0 - 11480 ft (0 - 3499 m) Operating Relative Humidity : 0 - 95 % (non-condensing) Operating Temperature : 23 - 140 °F (-5 - 60 °C) Storage Elevation : 0 - 50000 ft (0 - 15239 m) Storage Temperature : -4 - 113 °F (-20 - 45 °C) Environmental : RoHS Compliant Safety : UL60950-1\|UL62368-1\|FCC Class A Extended Warranty Option : WEXT5YR-PDU1B Product Warranty : 3 Year Limited Warranty
Certifications & Standards	UL60950-1 UL62368-1 FCC Class A
Country of Origin	Philippines
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

3 Year
