CyberPower PDU83103 3 Phase 200 - 240 VAC 20A Switched Metered-by-Outlet PDU

Name: CyberPower PDU83103 3 Phase 200 - 240 VAC 20A Switched Metered-by-Outlet PDU
Brand: CYBERPOWER
SKU: 9GM207
Price: 1453.68 USD
Availability: InStock

CYBERPOWER

PCN#

9GM207

MFG#

PDU83103

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$1,453.68

Extended & Accidental Damage Protection Plans Available Details

3-Year $143.99

2-Year $107.99

Free Shipping

Estimated Shipment:

Product Highlights:

30 Outlets, 10 ft, NEMA L15
20P, Vertical, 0U, LCD, 3YR Warranty

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 22 lbs.

CyberPower PDU83103 3 Phase 200 - 240 VAC 20A Switched Metered-by-Outlet PDU

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	PDU83103
Manufacturer Website Address	http://www.cyberpowersystems.com
Brand Name	CyberPower
Product Series	Switched Metered-by-Outlet PDU
Product Model	PDU83103
Product Name	PDU83103 30-Outlets PDU
Marketing Information	Streamline capacity planning and power management with the CyberPower PDU83103 switched metered-by-outlet 3-Phase PDU. Ideal for data centers and network closets, this unit provides outlet-level power monitoring in real time, along with individual outlet control for remote reboots, load shedding, controlled power-cycling, and more. The PDU83103 supports inputs between 200-240V and includes 30 IEC-320 outlets. Other features include ultra-low power consumption, multi-color outlet LEDs, an interactive digital display with selectable background color, high operating temperature range, built-in web interface, and power event notifications. The CyberPower PDU83103 is protected by a three-year limited warranty.
Product Condition	New
Product Type	PDU

Technical Information

PDU Type	Switched with Metered-by-Outlet
Phase	Three Phase
Plug/Connector Type	NEMA L15-20P
Receptacle Type	IEC 60320 C13 IEC 60320 C19
Receptacle Detail	24 x IEC 60320 C13 6 x IEC 60320 C19

Power Description

Input Voltage	230 V AC
Input Voltage Range	200 V AC - 240 V AC
Output Voltage Range	200 V AC - 240 V AC
Input Current	20 A

Management

Management	IPv4 TCP/IP UDP SNMPv1 HTTP NTP DNS Telnet DHCP SMTP FTP IPv6 SNMPv3 HTTPs SSH SSL TLS LDAP(S) RADIUS Syslog CLI Windows AD
Remote Outlet Switching	Yes

Interfaces/Ports

Network (RJ-45)

Yes

Physical Characteristics

Product Color	Black
Mounting Orientation	Vertical
Mount Type	Rack-mountable
Rack Height	0U
Cord Length	10 ft
Height	70.5"
Width	2.2"
Depth	2.2"
Weight (Approximate)	13.90 lb

Miscellaneous

Additional Information	Derated Input Current \| 16 A Input Frequency Range \| 50 Hz - 60 Hz Overload Protection \| 20A x 2 Environmental Sensor \| Optional, via RJ45 Hardware Connection Port \| Ethernet (RJ45) LCD \| Multifunction LCD LED Indicators \| Tx/Rx Modular Expandability (Cascading) \| Yes, via RJ45 Monitoring Level \| Input Outlet switching \| Yes Software (Free Download) \| PowerPanel® Business Upgradeable firmware \| Yes Adjustable Mounting Brackets \| 1 set Cord Retention Tray/Cord Organizers \| Yes Material of Construction \| Metal Operating Elevation \| 0 - 11480 ft (0 - 3499 m) Operating Relative Humidity \| 0 - 95 % (non-condensing) Operating Temperature \| 23 - 140 °F (-5 - 60 °C) Storage Elevation \| 0 - 50000 ft (0 - 15239 m) Storage Temperature \| -4 - 113 °F (-20 - 45 °C)
Certifications & Standards	UL60950-1 UL62368-1 FCC Class A
Country of Origin	Philippines

Warranty

Limited Warranty

3 Year
