CYBERPOWER PDU41116 PDU 100-120V/15A 16 OUTLETS 0U RM

Name: CYBERPOWER PDU41116 PDU 100-120V/15A 16 OUTLETS 0U RM
Brand: CYBERPOWER
SKU: JU1410
Price: 949.95 USD
Availability: InStock

CYBERPOWER

PCN#

JU1410

MFG#

PDU41116

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$949.95

Extended & Accidental Damage Protection Plans Available Details

2-Year $89.99

3-Year $120.99

Free Shipping

Estimated Shipment:

Product Highlights:

16 Outlets, 10 ft, NEMA 5
15P, Vertical, 0U, SNMP, 3YR Warranty

Product Condition: New and Factory Fresh

Limited WarrantyCertifications & StandardsUL 62368-1Environmentally FriendlyYesEnvironmental ComplianceRestriction of Hazardous Substances (RoHS)UL ListedYesWarranty

Shipping Weight: 15 lbs.

CyberPower PDU41116 Single Phase 100 - 120 VAC 15A Switched PDU

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	PDU41116
Manufacturer Website Address	https://www.cyberpowersystems.com/
Brand Name	CyberPower
Product Series	Switched PDU
Product Model	PDU41116
Product Name	PDU41116
Marketing Information	The CyberPower PDU41116, a 16-outlet, 0U rackmount switched power distribution unit (PDU), provides 120V 15A output. It distributes power to 16 NEMA 5-15R receptacles from a single NEMA 5-15P plug with unfiltered electrical pass-through. The switched outlet receptacles can be managed individually or collectively over the network, using the CyberPower Management Console, web browser, and the RJ45 Ethernet port for network connection, or locally by using the LCD controls.
Product Condition	New
Product Type	PDU

Technical Information

PDU Type	Switched
Phase	Single Phase
Plug/Connector Type	NEMA 5-15P
Receptacle Type	NEMA 5-15R
Receptacle Detail	16 x NEMA 5-15R
Locking Receptacles	Cord Retention Tray
Features	LCD Display

Power Description

Output Voltage	120 V AC
Output Voltage Range	100 V AC - 120 V AC
Input Current	15 A
Input Frequency	60 Hz

Management

SNMP
TCP/IP
UDP
DHCP
HTTP

Interfaces/Ports

Network (RJ-45)

Yes

Physical Characteristics

Color Family	Black
Product Color	Black
Product Material	Metal
Mounting Orientation	Horizontal/Vertical
Mount Type	Rack-mountable Wall-mountable
Form Factor	Rack
Rack Height	0U
Cord Length	10 ft
Height	53.1"
Width	1.9"
Depth	2.2"
Weight (Approximate)	11.90 lb

Environmental Conditions

Minimum Operating Temperature	32°F (0°C)
Maximum Operating Temperature	140°F (60°C)
Minimum Storage Temperature	5°F (-15°C)
Maximum Storage Temperature	149°F (65°C)
Minimum Operating Humidity	0%
Maximum Operating Humidity	95%

Miscellaneous

Additional Information	Physical Dimensions - (WxHxD) (cm) : 4.83 x 134.87 x 5.59 (cm) Physical Dimensions - (WxHxD) (in) : 1.9 x 53.1 x 2.2 (in) Physical Dimensions - (WxHxD) (mm) : 48 x 1349 x 56 (mm) Weight (kg) : 5.4 Weight (lb) : 11.9 Shipping Dimensions - (WxHxD) (cm) : 11.43 x 157.99 x 18.54 (cm) Shipping - Dimensions (WxHxD, in) : 4.5 x 62.2 x 7.3 (in) Shipping - Dimensions (WxHxD, mm) : 114.3 x 1579.88 x 185.42 (mm) Shipping - Weight (kg) : 7.57 Shipping - Weight (lb) : 16.7 Cord Length : 10 ft (3.0 m) Input Frequency Range : 50 Hz - 60 Hz Input Plug Type : NEMA 5-15P Maximum Input Current : 15A (Derated to 12A) Phase : Single Phase Plug Style : Straight Meter Readout : Kilowatts Nominal Output Voltage : 100 - 120 VAC Outlets - Front : 16 Outlets - Rear : 0 Outlets - Total : 16 Outlet Type COMPUTED : 16 - NEMA 5-15R Overload Protection : None USB Charge Port : No Hardware Connection Port : RJ45 LED Indicators : Load SNMP / HTTP Remote Monitoring : TCP/IP, UDP, DHCP, SNMP, HTTP Adjustable Mounting Brackets : 1 set Color : Black Cord Retention Tray/Cord Organizers : Yes External Site Ground Pin : Yes Form Factors Supported : Horizontal or Vertical Wallmount Material of Construction : Metal Rack Height : 0U Style : Vertical Rackmount Operating Elevation : 0 - 11482 ft (0 - 3500 m) Operating Relative Humidity : 0 - 95 % (non-condensing) Operating Temperature : 32 - 140 °F (0 - 60 °C) Storage Elevation : 0 - 49212 ft (0 - 14999 m) Storage Temperature : 5 - 149 °F (-15 - 65 °C) Environmental : RoHS Compliant Safety : UL 62368-1 Extended Warranty Option : WEXT5YR-PDU1B Product Warranty : 3 Year Limited Warranty
Certifications & Standards	UL 62368-1
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
UL Listed	Yes

Warranty

Limited Warranty

3 Year
