CyberPower PDU13104 36-Outlets PDU

by
CYBERPOWER
PCN#
08HQ68
MFG#
PDU13104
main product photo
fotorama-image
CYBERPOWER Authorized Dealer
$905.79
cps

Extended & Accidental Damage Protection Plans Available Details

  Free Shipping
Estimated Shipment:

Calculating Shipping

Product Highlights:
  • 36 Outlets, 10 ft, Hubbell CS8365C, Vertical, 0U, 3YR Warranty
Product Condition: New and Factory Fresh
Limited WarrantyEnvironmentally FriendlyYesEnvironmental ComplianceRestriction of Hazardous Substances (RoHS)Warranty
Shipping Weight: 22 lbs.
CyberPower PDU13104 3 Phase 200 - 240 VAC 50A Basic PDU
Overview
Tech Specs
Specifications

Manufacturer

CyberPower Systems, Inc

Manufacturer Part Number

PDU13104

Manufacturer Website Address

https://www.cyberpowersystems.com

Brand Name

CyberPower

Product Model

PDU13104

Product Name

PDU13104 3 Phase 200 - 240 VAC 50A Basic

Marketing Information

Deliver reliable unfiltered power to connected equipment with the CyberPower PDU13104 basic 3-Phase PDU. Designed for data centers and other electrically demanding applications, this unit features rugged, industrial-grade metal housing, network-grade outlets and operates in high temperatures up to 140°F (60°C).

The PDU13104 supports a 200V-240V 50A input, includes 36 IEC outlets, and provides a maximum output load of 14.5kW. The CyberPower PDU13104 is protected by a three-year limited warranty.

Product Type

PDU
Technical Information

PDU Type

Basic

Phase

Three Phase

Plug/Connector Type

Hubbell CS8365C

Receptacle Type

  • NEMA 5-20R
  • NEMA L6-20R

Receptacle Detail

  • 30 x IEC 60320 C13
  • 6 x NEMA L6-20R
Power Description

Input Voltage

230 V AC

Input Voltage Range

200 V AC - 240 V AC

Output Voltage

  • 200 V AC
  • 240 V AC

Output Voltage Range

200 V AC - 240 V AC

Power Rating (Watt)

5700 W

Input Current

50 A
Physical Characteristics

Color Family

Black

Product Color

Black

Mounting Orientation

Vertical

Mount Type

Rack-mountable

Rack Height

0U

Height

70.5"

Width

2.2"

Depth

2.2"

Weight (Approximate)

13.89 lb
Miscellaneous

Package Contents

  • PDU13104 36-Outlets PDU
  • Adjustable Mounting Brackets

Additional Information

  • Physical Dimensions - (WxHxD) (cm) : 5.59 x 179.07 x 5.59 (cm)
  • Physical Dimensions - (WxHxD) (in) : 2.2 x 70.5 x 2.2 (in)
  • Physical Dimensions - (WxHxD) (mm) : 56 x 1791 x 56 (mm)
  • Weight (kg) : 6.3
  • Weight (lb) : 13.9
  • Shipping Dimensions - (WxHxD) (cm) : 21.59 x 16.0 x 203.45 (cm)
  • Shipping - Dimensions (WxHxD, in) : 8.5 x 6.3 x 80.1 (in)
  • Shipping - Dimensions (WxHxD, mm) : 215.9 x 160.02 x 2034.54 (mm)
  • Shipping - Weight (kg) : 9.71
  • Shipping - Weight (lb) : 21.4
  • Cord Length : 10 ft (3.0 m)
  • Derated Input Current : 35 A
  • Input Frequency Range : 50 Hz - 60 Hz
  • Input Plug Type : Hubbell CS8365C
  • Maximum Input Current : 50A
  • Nominal Input Voltage : 200 - 240 VAC
  • Phase : 3 Phase
  • Nominal Output Voltage : 200 - 240 VAC
  • Outlets - # of Banks : 3
  • Outlets - Total : 36
  • Outlet Type COMPUTED : 30 - IEC-320 C13
  • Overload Protection : 20A X 3
  • Adjustable Mounting Brackets : 1 set
  • Color : Black
  • Cord Retention Tray/Cord Organizers : Yes
  • Form Factors Supported : 0U Vertical Rackmount
  • Material of Construction : Metal
  • Rack Height : 0U
  • Operating Elevation : 0 - 11480 ft (0 - 3499 m)
  • Operating Relative Humidity : 0 - 95 % (non-condensing)
  • Operating Temperature : 23 - 140 °F (-5 - 60 °C)
  • Environmental : RoHS Compliant
  • Safety : UL60950-1|FCC Class A|CB
  • Product Warranty : 3 Year Limited Warranty

    • Environmentally Friendly

    		Yes

    Environmental Compliance

    		Restriction of Hazardous Substances (RoHS)
    Warranty

    Limited Warranty

    		3 Year
