CyberPower CP685AVRLCD Intelligent LCD UPS Systems

Name: CyberPower CP685AVRLCD Intelligent LCD UPS Systems
Brand: CYBERPOWER
SKU: 9GM227
Price: 128.01 USD
Availability: InStock

CYBERPOWER

PCN#

9GM227

MFG#

CP685AVRLCD

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$128.01

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $32.99

1-Year $24.99

Free Shipping

Estimated Shipment:

Product Highlights:

685VA/390W, 120 VAC, NEMA 5
15P, Compact, 8 Outlets, LCD, PowerPanel® Personal, $125000 CEG, 3YR Warranty

Product Condition: New and Factory Fresh

Limited WarrantyCertifications & StandardsUL1778cUL 107.1FCC DOC Class BSoftware IncludedPowerPanel Personal Edition SoftwareEnergy StarYesEnvironmentally FriendlyYesEnvironmental ComplianceRestriction of Hazardous Substances (RoHS)Warranty

Shipping Weight: 13 lbs.

CyberPower CP685AVRLCD Intelligent LCD UPS Systems

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	CP685AVRLCD
Manufacturer Website Address	https://www.cyberpowersystems.com
Brand Name	CyberPower
Product Series	Intelligent LCD UPS
Product Model	CP685AVRLCD
Product Name	CP685AVRLCD Intelligent LCD UPS Systems
Marketing Information	A compact UPS with line-interactive topology, the CyberPower Intelligent LCD CP685AVRLCD provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. The CP685AVRLCD uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. Features include a multifunction LCD panel to provide visibility into power conditions and UPS vitals. The CP685AVRLCD comes with a three-year warranty (including coverage of batteries) and a 125,000 Connected Equipment Guarantee.
Product Type	Line-interactive UPS

Technical Information

Plug/Connector Type	NEMA 5-15P
Receptacle Type	NEMA 5-15R
Receptacle Detail	8 x NEMA 5-15R
Dataline Protection	RJ-45 RG-6 RJ-11
Emergency Power OFF	No
Cord Length	6 ft
Transfer Time	4 ms

Power Description

Load Capacity (VA)	685 VA
Load Capacity (Watt)	390 W
Input Voltage	110 V AC
Output Voltage	120 V AC

Interfaces/Ports

USB

Yes

Battery Information

Number of Batteries	1
Battery Chemistry	Lead Acid
Backup/Run Time (Full Load)	2 Minute
Backup/Run Time (Half Load)	11 Minute
Typical Battery Recharge Time	8 Hour
Hot Swappable	Yes

Physical Characteristics

Height	6.50"
Width	11"
Depth	3.50"
Form Factor	Desktop
Weight (Approximate)	14 lb

Miscellaneous

Package Contents	Intelligent LCD CP685AVRLCD 685VA Desktop UPS User Manual USB A+B Type Cable Serial Cable Warranty Registration Card
Additional Information	Energy Saving : GreenPower UPS™ Bypass Technology Energy Star Certified : Yes UPS Topology : Line Interactive Battery Quantity : 1 Battery Size : 12 V / 7 Ah Battery Type : Sealed Lead-Acid Battery Hot Swappable : Yes Replacement Battery Cartridge : RB1270B (for serial numbers that begin with "CT8") Replacement Battery Cartridge Quantity : 1 Runtime at Full Load : 2 min Runtime at Half Load : 11 min Typical Recharge Time : 8 Hours User Replaceable Battery : Yes Physical Dimensions - (WxHxD) (cm) : 27.94 x 17.27 x 8.89 (cm) Physical Dimensions - (WxHxD) (in) : 11 x 6.8 x 3.5 (in) Physical Dimensions - (WxHxD) (mm) : 279 x 173 x 89 (mm) Weight (kg) : 5.27 Weight (lb) : 11.62 Shipping Dimensions - (WxHxD) (cm) : 12.7 x 24.89 x 36.32 (cm) Shipping - Dimensions (WxHxD, in) : 5.0 x 9.8 x 14.3 (in) Shipping - Dimensions (WxHxD, mm) : 127.0 x 248.92 x 363.22 (mm) Shipping - Weight (kg) : 5.94 Shipping - Weight (lb) : 13.1 Circuit Breaker : 15 A Cord Length : 6 ft (1.8 m) Input Frequency Range : 57 Hz - 63 Hz Input Plug Type : NEMA 5-15P Nominal Input Voltage : 120 VAC Plug Style : Right Angle - 45° Offset Automatic Voltage Regulation : Single Boost On AC WaveForm : Sine Wave On Battery Frequency : 60 Hz ± 1% On Battery Voltage : 120 VAC ± 5% On Battery Waveform : Simulated Sine Wave Outlets - Battery & Surge Protected : 4 Outlets - Surge-Only Protected : 4 Outlets - Total : 8 Outlets - Widely Spaced : 4 Outlet Type COMPUTED : 8 - NEMA 5-15R Output Power Factor : 0.6 Overload Protection : Internal Circuitry Limiting Typical Transfer Time : 4 ms USB Charge Port : No VA : 685 VA Watts : 390 W Coax Protection RG6 COMPUTED : None EMI/RFI Filtration COMPUTED : Yes Surge Suppression (Joules) : 1030 J Coax Protection RG6 COMPUTED : None EMI/RFI Filtration COMPUTED : Yes Surge Suppression (Joules) : 1030 J Audible Alarms : Battery Mode HID Compliant USB Port : Yes LCD : Multifunction LCD LED Indicators : Power On Management Cable : USB Cable Software (Free Download) : PowerPanel® Personal Color : Black Form Factor : Compact Keyhole Mounting Slots : Yes Material of Construction : Plastic Operating Elevation : 0 - 10000 ft (0 - 3048 m) Operating Relative Humidity : 0 - 90 % (non-condensing) Operating Temperature : 32 - 95 °F (0 - 35 °C) Storage Elevation : 0 - 50000 ft (0 - 15239 m) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Environmental : RoHS Compliant Safety : UL1778 CEG Amount : 125000 Connected Equipment Guarantee : Lifetime Extended Warranty Option : WEXT5YR-U1B Product Warranty : 3 Year Limited Warranty
Certifications & Standards	UL1778 cUL 107.1 FCC DOC Class B
Software Included	PowerPanel Personal Edition Software
Energy Star	Yes
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

3 Year
