CyberPower CP685AVRG AVR UPS Systems

Name: CyberPower CP685AVRG AVR UPS Systems
Brand: CYBERPOWER
SKU: 9GM188
Price: 108.95 USD
Availability: InStock

CYBERPOWER

PCN#

9GM188

MFG#

CP685AVRG

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$108.95

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $32.99

1-Year $24.99

Free Shipping

Estimated Shipment:

Product Highlights:

685VA/390W, 120 VAC, NEMA 5
15P, Compact, 8 Outlets, PowerPanel® Personal, $125000 CEG, 3YR Warranty

Product Condition: New and Factory Fresh

Limited WarrantyEnergy StarYesCountry of OriginChinaEnvironmentally FriendlyYesEnvironmental ComplianceRestriction of Hazardous Substances (RoHS)Warranty

Shipping Weight: 13 lbs.

CyberPower CP685AVRG AVR UPS Systems

Overview

Tech Specs

Specifications

Manufacturer	CyberPower Systems, Inc
Manufacturer Part Number	CP685AVRG
Manufacturer Website Address	https://www.cyberpowersystems.com
Brand Name	CyberPower
Product Series	AVR UPS
Product Model	CP685AVRG
Product Name	CP685AVRG AVR UPS Systems
Marketing Information	The CyberPower CP685AVRG uninterruptible power supply (UPS) system provides battery backup and surge protection for lightning-induced surges and other power events that can damage electronic equipment. This UPS, with line-interactive topology, uses simulated sine wave output to deliver battery backup to power connected electronics during a utility power failure. The unit has enough runtime to perform a graceful shutdown to protect against the loss of data and damage to valuable desktop computers, workstations, networking devices, and home entertainment systems. The CP685AVRG uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power. AVR is essential in areas where power fluctuations occur frequently, and it helps to extend the unit's battery life. CyberPower designed the CP685AVRG to minimize noise for a quieter work environment and run efficiently to reduce power consumption. With a 125,000 lifetime connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to the quality of this battery backup with surge protection.
Packaged Quantity	1 / Each
Product Type	Line-interactive UPS

Technical Information

Plug/Connector Type	NEMA 5-15P
Receptacle Type	NEMA 5-15R
Receptacle Detail	8 x NEMA 5-15R
Transfer Time	4 ms
Application/Usage	Desktop Computer Network Device Home Theater Router Modem VoIP Phone System Workstation

Power Description

Load Capacity (VA)	685 VA
Load Capacity (Watt)	390 W
Input Voltage	120 V AC
Input Voltage Range	90 V AC - 140 V AC
Output Voltage	120 V AC
Waveform Type	Simulated Sine Wave

Interfaces/Ports

Network (RJ-45)

Yes

Battery Information

Backup/Run Time (Full Load)	2 Minute
Typical Battery Recharge Time	8 Hour

Physical Characteristics

Height	6.80"
Width	11"
Depth	3.50"
Form Factor	Compact
Weight (Approximate)	12 lb

Miscellaneous

Package Contents	CP685AVRG AVR UPS Series User's Manual USB Device Cable PowerPanel Personal Software CD or Free Download Card
Additional Information	Energy Saving : GreenPower UPS™ Bypass Technology Energy Star Certified : Yes UPS Topology : Line Interactive Battery Quantity : 1 Battery Size : 12 V / 7 Ah Battery Type : Sealed Lead-Acid Battery Hot Swappable : No Replacement Battery Cartridge : RB1270B (for serial numbers that with "CXA") Replacement Battery Cartridge Quantity : 1 Runtime at Full Load : 2 min Runtime at Half Load : 11 min Typical Recharge Time : 8 Hours User Replaceable Battery : Yes Physical Dimensions - (WxHxD) (cm) : 27.94 x 17.27 x 8.89 (cm) Physical Dimensions - (WxHxD) (in) : 11 x 6.8 x 3.5 (in) Physical Dimensions - (WxHxD) (mm) : 279 x 173 x 89 (mm) Weight (kg) : 5.27 Weight (lb) : 11.62 Shipping Dimensions - (WxHxD) (cm) : 25.4 x 13.97 x 36.83 (cm) Shipping - Dimensions (WxHxD, in) : 10.0 x 5.5 x 14.5 (in) Shipping - Dimensions (WxHxD, mm) : 254.0 x 139.7 x 368.3 (mm) Shipping - Weight (kg) : 5.67 Shipping - Weight (lb) : 12.5 Circuit Breaker : 15 A Cord Length : 6 ft (1.8 m) Input Frequency Range : 57 Hz - 63 Hz Input Plug Type : NEMA 5-15P Input Voltage Range : 90 VAC - 140 VAC Nominal Input Voltage : 120 VAC Automatic Voltage Regulation : Single Boost On AC WaveForm : Sine Wave On Battery Frequency : 60 Hz ± 1% On Battery Voltage : 120 VAC ± 5% On Battery Waveform : Simulated Sine Wave Outlets - Battery & Surge Protected : 4 Outlets - Surge-Only Protected : 4 Outlets - Total : 8 Outlets - Widely Spaced : 4 Outlet Type COMPUTED : 8 - NEMA 5-15R Output Power Factor : 0.6 Overload Protection : Internal Circuitry Limiting Typical Transfer Time : 4 ms USB Charge Port : No VA : 685 VA Watts : 390 W Coax Protection RG6 COMPUTED : None EMI/RFI Filtration COMPUTED : Yes Surge Suppression (Joules) : 1030 J Coax Protection RG6 COMPUTED : None EMI/RFI Filtration COMPUTED : Yes Surge Suppression (Joules) : 1030 J Audible Alarms : Battery Mode HID Compliant USB Port : Yes LED Indicators : Power On Management Cable : USB Cable Serial Port : 1 Serial Software (Free Download) : PowerPanel® Personal Color : Black Form Factor : Compact Keyhole Mounting Slots : Yes Material of Construction : Plastic Operating Relative Humidity : 0 - 90 % (non-condensing) Operating Temperature : 32 - 95 °F (0 - 35 °C) Storage Temperature : 5 - 113 °F (-15 - 45 °C) Environmental : RoHS Compliant Safety : UL1778 CEG Amount : 125000 Connected Equipment Guarantee : Lifetime Extended Warranty Option : WEXT5YR-U1B Product Warranty : 3 Year Limited Warranty
Energy Star	Yes
Country of Origin	China
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

3 Year
