Cisco Barebone System - 4U Rack-mountable - 4 x Processor Support

Name: Cisco Barebone System - 4U Rack-mountable - 4 x Processor Support
Brand: CISCO
SKU: 5RT306
Price: 9694.56 USD
Availability: InStock

CISCO

PCN#

5RT306

MFG#

UCSC-C480-M5-CH

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$9,694.56

Extended & Accidental Damage Protection Plans Available Details

2-Year $507.99

3-Year $627.99

Free Shipping

Estimated Shipment:

Product Highlights:

Intel C620 Chip
18 TB DDR4 SDRAM DDR4
2666/PC4
21300 Maximum RAM Support
48.0 Total Memory Slots
12Gb/s SAS RAID Supported, Serial ATA Controller
256 MB Graphic(s)
Processor Support (Xeon Gold, Xeon Platinum, Xeon Silver, Xeon Bronze)
10 Gigabit Ethernet
Intel Optane Memory Ready
3 USB 3.0 Port(s)
1600 W

Product Condition: New and Factory Fresh

Shipping Weight: 1 lbs.

Cisco Barebone System - 4U Rack-mountable - 4 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Cisco Systems, Inc
Manufacturer Part Number	UCSC-C480-M5-CH
Manufacturer Website Address	http://www.cisco.com
Brand Name	Cisco
Product Series	C480 M5
Product Name	UCS C480 M5 Barebone System
Marketing Information	The Cisco UCS C480 M5 High-Performance Rack Server is a four-rack-unit (4RU) server supporting the Intel® Xeon® processor scalable family CPUs, with up to 6 terabytes (TB) of double-data-rate 4 (DDR4) memory in 48 slots, and up to 32 small form factor (SFF), hot-swappable SAS/SATA/PCIe NVMe disk drives. The latest update includes support for 2933 MHz DDR4 memory that is used with the latest 2nd Generation Intel® Xeon® Scalable Processors. With this combination and the new 512GB Intel® OptaneTM DC Persistent Memory (DCPMM - Data Center Persistent Memory Module), up to 18 TB of memory is possible (24x256GB DDR4 DIMMs and 24x512GB DCPMMs). 12 PCI Express (PCIe) expansion slots support Cisco UCS C-Series network adapters storage controllers, and up to 6 GPUs, with additional I/O provided by two 10GBase-T LOM ports and one 1GbE dedicated out-of-band (OOB) management port. A separate PCIe slot is reserved inside the chassis for a RAID controller card.
Product Type	Barebone System

Processor

Number of Processors Supported	4
Processor Supported	Xeon Gold Xeon Platinum Xeon Silver Xeon Bronze
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	C620

Memory

Maximum Memory Supported	18 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2666/PC4-21300
Total Number of Memory Slots	48.0
Intel Optane Memory Ready	Yes

Controllers

Controller Type	12Gb/s SAS Serial ATA
RAID Supported	Yes

Display & Graphics

Graphics Memory Capacity

256 MB

Network & Communication

Ethernet Technology

10 Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	32
Total Number of Expansion Slots	12.0
Number of PCI Express x8 Slots	6
Number of PCI Express x16 Slots	6

Interfaces/Ports

Total Number of USB Ports	4
Number of USB 3.0 Ports	3

Power Description

Input Voltage	120 V AC 230 V AC
Maximum Power Supply Wattage	1600 W

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	4U
Height	6.9"
Width	19"
Depth	32.7"
Weight (Approximate)	146.17 lb

Miscellaneous

Country of Origin

China
