Cisco Barebone System - 2U Rack-mountable - 2 x Processor Support

Name: Cisco Barebone System - 2U Rack-mountable - 2 x Processor Support
Brand: CISCO
SKU: 9BA386
Price: 3230.69 USD
Availability: InStock

CISCO

PCN#

9BA386

MFG#

UCSC-C245-M6SX

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$3,230.69

Extended & Accidental Damage Protection Plans Available Details

3-Year $332.99

2-Year $265.99

Free Shipping

Estimated Shipment:

Product Highlights:

AMD Chip
8 TB DDR4 SDRAM DDR4
3200/PC4
25600 Maximum RAM Support
32.0 Total Memory Slots
12Gb/s SAS RAID Supported, Serial ATA/600 Controller
Matrox G200e 8 MB Graphic(s)
Processor Support (EPYC)
Gigabit Ethernet
Intel Optane Memory Ready
2 USB 3.0 Port(s)
3 Year

Product Condition: New and Factory Fresh

Limited Warranty3 YearAdditional Warranty Information Three-year parts coverage. Next business day (NBD) parts replacement eight hours a day, five days a week. 90-day software warranty on media.

Shipping Weight: 40 lbs.

Cisco Barebone System - 2U Rack-mountable - 2 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Cisco Systems, Inc
Manufacturer Part Number	UCSC-C245-M6SX
Manufacturer Website Address	http://www.cisco.com
Brand Name	Cisco
Product Series	C245 M6
Product Name	UCS C245 M6 Barebone System
Marketing Information	The UCS C245 M6 SFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the addition of the AMD CPUs, 16 DIMM slots per CPU for 3200-MHz DDR4 DIMMs with individual DIMM capacity points up to 256 GB. The maximum memory capacity for 2 CPUs is 8 TB (for 32 x 256 GB DDR4 DIMMs). The C245 M6 SFF server has: Up to 24 front SFF SAS/SATA HDDs or SSDs (optionally up to 4 of the drives can be NVMe) I/O-centric option provides up to 8 PCie slots using three rear risers, or Storage-centric option provides three rear risers with a total of up to 4 NVMe SFF drives and 3 PCIe slots The server provides internal slots for the following: One Cisco 12G SAS RAID controllers with 4 GB cache backup to control SAS/SATA drives, or Cisco 12G SAS HBAs to control SAS/SATA drives The UCS C245 M6 server has a single 1 GbE management port. A modular LAN on motherboard (mLOM)/OCP 3.0 module provides up to two 100 GbE ports. A connector on the front of the chassis provides KVM functionality. The Cisco UCS C245 M6 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.
Product Type	Barebone System

Processor

Number of Processors Supported	2
Processor Supported	EPYC
64-bit Processing	Yes

Chipset

Chipset Manufacturer

AMD

Memory

Maximum Memory Supported	8 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-3200/PC4-25600
Total Number of Memory Slots	32.0
Intel Optane Memory Ready	Yes

Storage

Supported Storage Drive Interfaces	SAS-3 Serial ATA III
Supported Storage Drive Types	SSD HDD

Controllers

Controller Type	12Gb/s SAS Serial ATA/600
RAID Supported	Yes

Display & Graphics

Graphics Controller Manufacturer	Matrox
Graphics Controller Model	G200e
Graphics Memory Capacity	8 MB

Network & Communication

Ethernet Technology

Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays

Interfaces/Ports

Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of VGA Ports	1

Power Description

Input Voltage	120 V AC 230 V AC
Frequency	50 Hz 60 Hz

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	2U
Height	3.4"
Width	16.9"
Depth	30"
Weight (Approximate)	61.73 lb

Warranty

Limited Warranty	3 Year
Additional Warranty Information	Three-year parts coverage. Next business day (NBD) parts replacement eight hours a day, five days a week. 90-day software warranty on media.
