Cisco Barebone System - 2U Rack-mountable - 2 x Processor Support

Name: Cisco Barebone System - 2U Rack-mountable - 2 x Processor Support
Brand: CISCO
SKU: 3BG857
Price: 2572.62 USD
Availability: InStock

CISCO

PCN#

3BG857

MFG#

UCSC-C240-M5SX=

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$2,572.62

Extended & Accidental Damage Protection Plans Available Details

2-Year $197.99

3-Year $263.99

Free Shipping

Estimated Shipment:

Product Highlights:

Intel C620 Chip
3 TB DDR4 SDRAM DDR4
2666/PC4
21300 Maximum RAM Support
24 Total Memory Slots
12Gb/s SAS RAID Supported Controller
ASPEED Pilot 4 16 MB Graphic(s)
26 2.5" Bay(s)
Processor Support (Xeon)
10 Gigabit Ethernet, Gigabit Ethernet
2 USB 3.0 Port(s)
3 Year

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 40 lbs.

Cisco Barebone System - 2U Rack-mountable - 2 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Cisco Systems, Inc
Manufacturer Part Number	UCSC-C240-M5SX
Manufacturer Website Address	http://www.cisco.com
Brand Name	Cisco
Product Series	C240 M5
Product Name	UCS C240 M5 Barebone System
Marketing Information	UCS C240 M5 SFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the addition of the Intel® Xeon® Processor Scalable Family, 24 DIMM slots for 2666 MHz DDR4 DIMMs and up to 128GB capacity points, up to 6 PCI Express (PCIe) 3.0 slots, and up to 26 internal SFF drives. The C240 M5 SFF server also includes one dedicated internal slot for a 12G SAS storage controller card. The C240 M5 server includes a dedicated internal modular LAN on motherboard (mLOM) slot for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC), without consuming a PCI slot, in addition to 2 x 10Gbase-T Intel x550 embedded(on the motherboard) LOM ports. The Cisco UCS C240 M5 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.
Product Type	Barebone System

Processor

Number of Processors Supported	2
Processor Supported	Xeon
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	C620

Memory

Maximum Memory Supported	3 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2666/PC4-21300
Number of Total Memory Slots	24

Controllers

Controller Type	12Gb/s SAS
RAID Supported	Yes

Display & Graphics

Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	Pilot 4
Graphics Memory Capacity	16 MB

Network & Communication

Ethernet Technology

10 Gigabit Ethernet
Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	26
Number of Internal 2.5" Bays	26

Interfaces/Ports

Total Number of USB Ports	2
Number of USB 3.0 Ports	2

Power Description

Input Voltage

120 V AC
230 V AC

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	2U
Height	3.4"
Width	19"
Depth	30.2"
Weight (Approximate)	57.50 lb

Warranty

Limited Warranty

3 Year
