Cisco C220 M5 1U Rack Server - 2 x Intel Xeon Silver 4110 2.10 GHz - 32 GB RAM - 12Gb/s SAS Controller

Name: Cisco C220 M5 1U Rack Server - 2 x Intel Xeon Silver 4110 2.10 GHz - 32 GB RAM - 12Gb/s SAS Controller
Brand: CISCO
SKU: 5KX765
Price: 3138.06 USD
Availability: InStock

CISCO

PCN#

5KX765

MFG#

UCS-SPR-C220M5-S3

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$3,138.06

Extended & Accidental Damage Protection Plans Available Details

3-Year $332.99

2-Year $265.99

Free Shipping

Estimated Shipment:

Product Highlights:

2 Processor Support
3 TB RAM Support
Matrox G200e Up to 8 MB Graphic Card
10 Gigabit Ethernet
10 x SFF Bay(s)
Hot Swappable Bays

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 40 lbs.

Cisco C220 M5 1U Rack Server - 2 x Intel Xeon Silver 4110 2.10 GHz - 32 GB RAM - 12Gb/s SAS Controller

Overview

Tech Specs

Specifications

Manufacturer	Cisco Systems, Inc
Manufacturer Part Number	UCS-SPR-C220M5-S3
Manufacturer Website Address	http://www.cisco.com
Brand Name	Cisco
Product Series	C220 M5
Product Name	UCS C220 M5 Server
Marketing Information	The UCS C220 M5 SFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 1U form factor with the addition of the Intel® Xeon® Processor Scalable Family, 24 DIMM slots for 2666MHz DIMMs and up to 128GB capacities, two 2 PCI Express (PCIe) 3.0 slots, and up to 10 SAS/SATA hard disk drives (HDDs) or solid state drives (SSDs). The C220 M5 SFF server also includes one dedicated internal slot for a 12G SAS storage controller card. The C220 M5 server included one dedicated internal modular LAN on motherboard (mLOM) slot for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC), without consuming a PCI slot, in addition to 2 x 10Gbase-T Intel x550 embedded (on the motherboard) LOM ports. The Cisco UCS C220 M5 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.
Product Type	Server

Processor

Number of Processors Supported	2
Number of Processors Installed	2
Processor Manufacturer	Intel
Processor Type	Xeon Silver
Processor Model	4110
Processor Core	Octa-core (8 Core)
Processor Speed	2.10 GHz

Memory

Standard Memory	32 GB
Maximum Memory Supported	3 TB
Memory Technology	DDR4 SDRAM
Number of Total Memory Slots	24
Number of Occupied Memory Slots	2

Controllers

Controller Type	12Gb/s SAS
RAID Supported	Yes

I/O Expansions

Number of Total Expansion Bays	10
Number of Internal 2.5" Bays	10
Hot Swappable Bays	Yes

Display & Graphics

Graphics Controller Manufacturer	Matrox
Graphics Controller Model	G200e
Graphics Memory Capacity	8 MB

Network & Communication

Ethernet Technology

10 Gigabit Ethernet

Power Description

Input Voltage	120 V AC 230 V AC
Number of Power Supplies Supported	2

Physical Characteristics

Form Factor	Rack
Rack Height	1U
Height	1.7"
Width	19"
Depth	31"
Weight (Approximate)	37.50 lb

Warranty

Limited Warranty

3 Year
