Cisco C240 M5 2U Rack-mountable Server - 2 x Intel Xeon Silver 4110 2.10 GHz - 96 GB RAM - 12Gb/s SAS Controller

Name: Cisco C240 M5 2U Rack-mountable Server - 2 x Intel Xeon Silver 4110 2.10 GHz - 96 GB RAM - 12Gb/s SAS Controller
Brand: CISCO
SKU: 5RQ636
Price: 8049.39 USD
Availability: InStock

CISCO

PCN#

5RQ636

MFG#

UCS-SP-C240M5-S3

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$8,049.39

Extended & Accidental Damage Protection Plans Available Details

2-Year $462.99

3-Year $582.99

Free Shipping

Estimated Shipment:

Product Highlights:

2 Processor Support
9 TB RAM Support
0, 1, 5, 6, 10, 50, 60, JBOD RAID Levels
ASPEED Pilot 4 Up to 16 MB Graphic Card
10 Gigabit Ethernet
26 x SFF Bay(s)
Hot Swappable Bays
2 x 1600 W
Redundant Power Supply
Intel Optane Memory Ready

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 1 lbs.

Cisco C240 M5 2U Rack-mountable Server - 2 x Intel Xeon Silver 4110 2.10 GHz - 96 GB RAM - 12Gb/s SAS Controller

Overview

Tech Specs

Specifications

Manufacturer	Cisco Systems, Inc
Manufacturer Part Number	UCS-SP-C240M5-S3
Manufacturer Website Address	http://www.cisco.com
Brand Name	Cisco
Product Series	C240 M5
Product Name	UCS C240 M5 Server
Marketing Information	UCS C240 M5 SFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 2U form factor with the addition of the Intel® Xeon® Processor Scalable Family, 24 DIMM slots for 2666 MHz DDR4 DIMMs and capacity points up to 128GB, up to 6 PCI Express (PCIe) 3.0 slots, and up to 26 internal SFF drives. The C240 M5 SFF server also includes one dedicated internal slot for a 12G SAS storage controller card. The latest update includes support for 2933 MHz DDR4 memory that is used with the latest 2nd Generation Intel® Xeon® Processor. With this combination and the new 512GB Intel® OptaneTM DC Persistent Memory (DCPMM - Data Center Persistent Memory Module), up to 9 TB of memory is possible (12x256GB DDR4 DIMMs1 and 12x512GB DCPMMs). The C240 M5 server includes a dedicated internal modular LAN on motherboard (mLOM) slot for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC), without consuming a PCI slot, in addition to 2 x 10Gbase-T Intel x550 embedded (on the motherboard) LOM ports. The Cisco UCS C240 M5 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.
Product Type	Server

Processor

Number of Processors Supported	2
Number of Processors Installed	2
Processor Manufacturer	Intel
Processor Type	Xeon Silver
Processor Model	4110
Processor Core	Octa-core (8 Core)
Processor Speed	2.10 GHz

Memory

Standard Memory	96 GB
Maximum Memory Supported	9 TB
Memory Technology	DDR4 SDRAM
Number of Total Memory Slots	24
Number of Occupied Memory Slots	6
Intel Optane Memory Ready	Yes

Storage

Total Hard Drive Capacity	No
Optical Drive Type	No

Controllers

Controller Type	12Gb/s SAS
RAID Supported	Yes
RAID Levels	0, 1, 5, 6, 10, 50, 60, JBOD

I/O Expansions

Number of Total Expansion Bays	26
Number of Internal 2.5" Bays	26
Hot Swappable Bays	Yes

Display & Graphics

Graphics Controller Manufacturer	ASPEED
Graphics Controller Model	Pilot 4
Graphics Memory Capacity	16 MB

Network & Communication

Ethernet Technology

10 Gigabit Ethernet

Operating System

Power Description

Input Voltage	120 V AC 230 V AC
Number of Power Supplies Supported	2
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	1600 W
Redundant Power Supply	Yes

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	2U
Height	3.4"
Width	19"
Depth	30.2"
Weight (Approximate)	57.50 lb

Warranty

Limited Warranty

3 Year
