C2G Video Extender Transmitter/Receiver

Name: C2G Video Extender Transmitter/Receiver
Brand: C2G
SKU: 9HN231
Price: 671.99 USD
Availability: InStock

C2G

PCN#

9HN231

MFG#

C2G30026

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$671.99

Extended & Accidental Damage Protection Plans Available Details

2-Year $66.99

3-Year $89.99

Free Shipping

Estimated Shipment:

Product Highlights:

1 Input Device
1 Output Device
328 ft Range
2 x Network (RJ
45)
1 x HDMI In
1 x HDMI Out
4K
Twisted Pair
Category 7
Commercial
Yes

Product Condition: New and Factory Fresh

Limited Warranty5 Year

Shipping Weight: 4 lbs.

C2G HDMI HDBaseT + RS232 and IR over Cat Extender Box Transmitter to Box Receiver (18Gbps) - 4K 60Hz

Overview

Tech Specs

Specifications

Manufacturer	C2G
Manufacturer Part Number	C2G30026
Manufacturer Website Address	http://www.cablestogo.com
Brand Name	C2G
Product Name	HDMI HDBaseT + RS232 and IR over Cat Extender Box Transmitter to Box Receiver (18Gbps) - 4K 60Hz
Marketing Information	The HDMI HDBaseT + RS232 and IR over Cat Extender Box Transmitter to Box Receiver (18Gbps) - 4K 60Hz allows a 4K HDMI source to be extended up to 328ft to a 4K display using a single Cat6a Ethernet cable. This is an ideal solution where HDMI video and audio in conference rooms, classrooms, lecture halls, and many other installation needs are far beyond the length limitations of standard HDMI cabling. Extend 4K HDMI up to 230 feet and 1080p up to 328 feet using a Cat5e or Cat6 cable. For longer 4K distances, extend 4K HDMI or up to 328 feet using a Cat6a cable. This HDMI HDBaseT receiver supports Visual Lossless Compression (VLC), which means the compressed data will appear identical to the uncompressed data. The receiver is also HDCP 2.2 compliant, making sure that the connection from the source is secure. With bi-directional Power over Cable (PoC) support, one power adapter at either transmitter or receiver side can power both units, so no additional power adapter is required, allowing for greater flexibility in installations. Advanced users can control bi-directional IR and device control through the RS232 port. Note: Ensure a solid, reliable connection between the 4K HDMI HDBaseT Extender and critical equipment. We suggest using HDMI Cables with gripping connectors that provide greater port retention than standard HDMI connectors.
Product Type	Video Extender Transmitter/Receiver

Technical Information

Connectivity Technology	Wired
Number of Input Devices Supported	1
Number of Output Devices Supported	1
Maximum Operating Distance	328 ft
HDBase-T	Yes

Video

Graphics Modes

Interfaces/Ports

Network (RJ-45)	Yes
HDMI In	Yes
HDMI Out	Yes
Number of Network (RJ-45) Ports	2
Number of HDMI Inputs	1
Number of HDMI Outputs	1

Media & Performance

Media Type Supported	Twisted Pair
Twisted Pair Cable Standard	Category 7

Physical Characteristics

Color Family	Multicolor
Product Color	Black
Transmitter Height	0.60"
Transmitter Width	5.37"
Transmitter Depth	2.92"
Receiver Height	0.60"
Receiver Width	5.37"
Receiver Depth	2.92"
Transmitter Weight (Approximate)	9.17 oz
Receiver Weight (Approximate)	9.17 oz

Miscellaneous

Package Contents	1 x Transmitter 1 x Receiver
Application/Usage	Commercial
Environmentally Friendly	Yes
Environmental Certification	REACH
Country of Origin	China

Warranty

Limited Warranty

5 Year
